The Influences of Cool- and Hot-Pressure Treatment on the Phase Transition and Superconductivity of YBa2Cu3O7-
-
摘要: 本文研究了冷压(2.2~5.2 GPa)与热压(2.2 GPa,2.50~950 ℃)对YBa2Cu3O7-的正交四方相转变区和超导电性的影响。冷压保持其正交结构,但破坏了超导性,在98 K(失超点)到室温呈半导体特性,再在空气中烧结,可恢复液氮温区的零电阻状态。以Cu锅密封样品,热压处理至950 ℃,不发生Cu的析出。热压处理后,98 K(失超点)到室温呈半导体特性,再经通氧烧结,于86 K出现零电阻。热压处理过程,从450~950 ℃为正交四方转变区。950 ℃为转变结束温度,大大高于氧气、空气、氮气、真空状态的温度。400 ℃附近为起始转变温度,低于氮气、氧气气氛的温度。因此相变区加宽。T0-t结束温度升高,与Cu锅的抑制还原作用有密切关系。如降低高压淬火速率(102 ℃/s),或随后辅以氧气氛中的后处理,将有利于获得既有高密度又有高Tc的YBa2Cu3O7-超导体。Abstract: In this paper, the influence of cool- and hot-pressure treatment were studied on the phase transition region from or thorhombic to tetragonal and superconductivity in YBa2Cu3O7-. After the cool pressure treatment of 2.2~5.2 GPa, the samples remained the orthorhombic structure, but lost their superconductivities and kept up the semiconductivity in the region from 98 K to room temperature. If the samples are sintered in air, their zero resistance states will be regained. When the samples were sealed hermetically into a Cu bowl, there was no separation of Cu in the samples within the region of hot-pressure temperature from 250 ℃ up to 950 ℃. After the hot-pressure treatment (2.2 GPa, 250~950 ℃), the samples were in semiconductiviting state in the region of 98 K to room temperature. If the samples are followed by an after-treatment in oxygen, the zero resistance state can be observed (at about 86 K). In the process of hot-pressure treatment, it was found that the transition region of orthorhombic to tetragonal is in the 450~950 ℃, 950 ℃ is the end temperature of transition, which is higher than that of samples obtained by sintering in oxygen, air, nitrogen and vacuum. And about 400 ℃ is the onset temperature of transition, which is lower than that in nitrogen, air and oxygen. Therefore the phase transition region is widened, and the end temperature of T0-t raises. These are related to that the Cu bowl restrains the reduction role under high pressure. If the quenching rate under high pressure is slowed (102 ℃/s), or the samples are followed by an after-treatment in O2, the YBa2Cu3O7- both with high density and Tc can be obtained. The deficiency and hole of oxygen are also discussed here.
-
Fukuyama H, Voshida K. Jpn J Appl Phys, 1986, 26: L371. Ohkawa F J. Jpn J Appl Phys, 1987, 26: 652. Shirbir J E, Ginley D S,et al. Phys Rev B, 1987, 35: 8709. Yoshida H, Morita H, et al. Jpn J Appl Phys, 1987, 26: 867. Takahashi H, Marayama C, et al. Jpn J Appl Phys, 1987, 26: 1109. Victor J N, et al. Solid State Communications, 1988, 67: 51. Liu Xiaoxiang, Wang Yifcng, Liu Hongjian, et al. Chin J High Press Phys, 1987, (4): 107. 黄新明, 等. 高压物理学报, 1988, 2: 159. Su Wenhui, Jin Changqing, et al. Phys Statue Solidi A, 1989: 115. Su Wenhui, Zhou Jianshi. High Pressure Science and Technology. Proceedings Ⅺth AIRAPT International Conference. Naukova Dumka Kiev, 1989: 115; 中国稀土学报, 1988, 6(2): 57. 周建十, 苏文辉. 高压科学技术第三届全国高压学术论会论文集. 吉林大学出版社, 1987: 216. 张进龙, 周建十, 苏文辉. 高压物理学报, 1988, 2(1): 67. Schuller I, et al. Solid State Commun, 1987, 63: 385. 崔得良. 硕士论文. 长春: 吉林大学, 1988.
