甲烷-空气最小点火能与耦合系数的计算及应用

杨帆; 钟杰; 刘兴华; 何为

doi:10.11858/gywlxb.2015.05.010

甲烷-空气最小点火能与耦合系数的计算及应用

doi: 10.11858/gywlxb.2015.05.010

杨帆^1,,
钟杰^1,*,,
刘兴华²,
何为¹

1.
重庆大学输配电装备及系统安全与新技术国家重点实验室，重庆 400044
2.
山东电力公司淄博供电局，山东淄博 255032

基金项目: 国家自然科学基金青年基金(51007096);国家重点基础研究发展计划(2011CB209401)

详细信息

作者简介:
杨帆(1980—), 男, 博士, 副教授, 主要从事电气的设备放电仿真与测量研究.E-mail:yangfancqu@gmail.com

通讯作者:
钟杰(1988—), 男, 硕士研究生, 主要从事放电理论及放电安全研究.E-mail:zhongjie_2009@foxmail.com

中图分类号: TM206;TD685
计量
- 文章访问数: 6557
- HTML全文浏览量: 2481
- PDF下载量: 184
出版历程
- 收稿日期: 2013-03-06

Minimum Ignition Energy and Coupling Coefficient of Methane-Air Mixture and Its Application

YANG Fan^1
,,
ZHONG Jie^{1,*
,},
LIU Xing-Hua²,
HE Wei¹

1.
State Key Laboratory of Power Transmission Equipment & System Security and New Technology, College of Electrical Engineering, Chongqing University, Chongqing 400044, China
2.
Shandong Zibo Power Supply Bureau, Zibo 255032, China

摘要

摘要: 针对一种可以用于检测非金属制品在矿井下工作安全性的静电火花检测系统，研究了计算该系统中甲烷-空气引爆的最小点火能量的数学物理模型。并根据该检测系统的结构，提出了点火系统点火前后的电磁能量计算方法。通过计算系统点火前的电磁能量与最小点火能量，计算出检测样品被粉尘摩擦后的带电量，得出了点火能量耦合系数阈值与电荷阈值。结果表明, 点火能量耦合系数阈值随电压升高而减小，随电极间距的增大而增大。以静电检测系统为例，当电极间距由1 mm增大到5 mm时，耦合阈值从0.416 3增加到0.769 1。同时，电荷阈值亦随电极间距增大而增大。研究结果可为进一步检测材料摩擦起电属性以及制定相关安全标准提供参考。
- 最小点火能 /
- 点火能量耦合系数 /
- 火花点火 /
- 抗静电检测
Abstract: Testing non-metallic materials are of great value to mining industry.The MIE (Minimum Ignition Energy) characterize the danger of a kind of combustible gas and its ignition.We calculated the MIE of the ignition system which can be used to test the antistatic property of the mine using materials.According to the structure of the antistatic property testing system, a method to calculate the electromagnetic energy of the ignition system was presented, and according to the MIE and electromagnetic energy before ignition, the quantity of triboelectric charge was obtained, as well as the threshold value of ignition energy coupling coefficient and the threshold value of quantity of triboelectric charge.The results shows that the threshold value of ignition energy coupling coefficient decreases as voltage grows, grows as the electrode distance gets wider.Familiar to the variation of ignition energy coupling coefficient, the threshold value of quantity of triboelectric charge grows as the electrode distance gets wider.For the system described in this paper, the threshold increases from 0.416 3 to 0.769 1 when the distance increases from 1 mm to 5 mm.This study puts forward to the test way to non-metallic materials and provides reference to setting safty standard concerns.
- MIE /
- ignition energy coupling coefficient /
- spark ignition /
- antistatic property testing

HTML全文

图 1 静电放电爆炸系统结构示意图

Figure 1. Structure of antistatic property testing system

下载: 全尺寸图片幻灯片

图 2 爆炸室三维电场仿真模型示意图

Figure 2. Model for three dimensional electric field simulation

下载: 全尺寸图片幻灯片

图 3 三维甲烷-空气点火模型

Figure 3. Three dimensional model for ignition in methane-air mixture

下载: 全尺寸图片幻灯片

图 4 电极截面能量分布图

Figure 4. Energy distribution in electrode section

下载: 全尺寸图片幻灯片

图 5 不同电极间距下极间电压与爆炸室系统电场能量关系

Figure 5. Relationship between electric field energy and electrode distance in explosion room

下载: 全尺寸图片幻灯片

图 6 点火行为示意图

Figure 6. Ignition behavior

下载: 全尺寸图片幻灯片

图 7 水平截面温度分布图

Figure 7. Temperature distribution in horizontal section

下载: 全尺寸图片幻灯片

图 8 最小点火能与电极间距关系

Figure 8. Relationship between MIE and electrode distance

下载: 全尺寸图片幻灯片

图 9 不同电极间距耦合系数阈值随电压变化曲线

Figure 9. Threshold of energy coupling coefficient curves

下载: 全尺寸图片幻灯片

图 10 不同间距下系统内三导体的电荷量

Figure 10. Electricity quantity of conductor in explosion room

下载: 全尺寸图片幻灯片

表 1 点火电压阈值

Table 1. Threshold of ignition energy coupling coefficient

h/(mm)	U/(kV)	h/(mm)	U/(kV)
5	13.395 9	2	10.528 2
4	12.036 1	1	9.926 7
3	11.554 6

下载: 导出CSV

表 2 电容矩阵系数C₁₂、C₂₂、C₃₂的值

Table 2. Value for C₁₂, C₂₂, C₃₂

h/(mm)	C₁₂/(pF)	C₂₂/(pF)	C₃₂/(pF)
5	-0.740 60	5.459 5	-4.718 9
4	-0.799 53	5.526 7	-4.727 1
3	-0.887 32	5.622 0	-4.734 8
2	-1.044 30	5.786 1	-4.741 8
1	-1.458 70	6.027 6	-4.748 9

下载: 导出CSV

表 3 点火电荷阈值

Table 3. Threshold of electricity quantity of triboelectric charge

h/(mm)	Q_c/(μC)	h/(mm)	Q_c/(μC)
5	0.080 7	2	0.058 2
4	0.068 3	1	0.052 0
3	0.065 0

下载: 导出CSV
