异型夹层结构复合靶板抗射流侵彻性能研究

张钟文; 黄正祥; 祖旭东; 贾鑫

doi:10.11858/gywlxb.2013.06.021

异型夹层结构复合靶板抗射流侵彻性能研究

doi: 10.11858/gywlxb.2013.06.021

南京理工大学智能弹药技术国防重点学科实验室，江苏南京 210094

基金项目: null

详细信息

通讯作者:
张钟文 E-mail:zhongwen22@126.com

计量
- 文章访问数: 6125
- HTML全文浏览量: 347
- PDF下载量: 442
出版历程
- 收稿日期: 2011-12-27
- 修回日期: 2012-03-02
- 发布日期: 2013-12-15

Study on the Effects of Composite Armor with Corrugated Sandwich against the Shaped Charge Jet Penetration

Minister Key Laboratory of ZNDY, Nanjing University of Science & Technology, Nanjing 210094, China

摘要

摘要: 研究了不同倾角时，折状夹芯倾角为45的复合靶板的抗射流侵彻性能。基于射流侵彻复合靶板过程中的能量损失、后效靶剩余穿深以及复合靶板质量防护系数，研究了无天然橡胶填充和有天然橡胶填充两种情况下的靶板性能，分析了具有橡胶填充靶板各组成部分的吸能特性。通过基准弹侵彻后效靶和射流以60侵彻具有橡胶填充靶板的实验研究，验证了仿真结论的可靠性。研究表明，具有45折状夹层结构的靶板有很好的抗射流侵彻能力，填充橡胶对提高靶板的防护性能是有利的，该结构复合靶板具有优异的防护性能，可以作为一种新型轻型防护装甲。
- 冲击力学 /
- 夹层结构 /
- 射流 /
- 抗侵彻性能 /
- 质量防护系数
Abstract: The anti-penetration property of the corrugated sandwich composite armor with the corrugation angle of 45 in different penetration angles was studied. The performance of the armors filled with rubber and without rubber was studied, based on the energy loss, DOP and quality protection factor considerations. The energy absorption characteristics of the armor filled with rubber was analyzed. The reliability of the simulation results was validated by 56 mm stander shaped charge penetrating the steel at 0 dip angle and the composite armor at 60 dip angle. The results showed that the protection capability of the corrugated sandwich composite armor with corrugation angle of 45 was effective. Its beneficial to fill the corrugation gaps with rubber. This kind of composite armor has excellent protection capability and can be used as a new kind of light armor.
- impact mechanics /
- corrugated sandwich /
- jet /
- anti-penetration property /
- quality protection factor

HTML全文

参考文献(12)

Zhang G P, Dai G C. Honeycomb sandwich panels of composites and their application [J]. Fiber Composites, 2000, 17(2): 25-27. (in Chinese)

张广平, 戴干策. 复合材料蜂窝夹芯板及其应用 [J]. 纤维复合材料, 2000, 17(2): 25-27.

Radford D D, Deshpande V S, Fleck N A. The use of metal foam projectiles to simulate shock loading on a structure [J]. Int J Impact Eng, 2005, 31(9): 1152-1171.

Mcshane G J, Radford D D, Deshpande V S, et al. The response of clamped sandwish plates with lattice cores subjected to shock loading [J]. Eur J Mech A/Solids, 2006, 25: 215-229.

Zhao G P, Lu T J. Dynamic response of cellular metallic sandwich plates under impact loading [J]. Chinese Journal of Theoretical and Applied Mechanics, 2008, 40(2): 194-206. (in Chinese)

赵桂平, 卢天健. 多孔金属夹层板在冲击载荷作用下的动态响应 [J]. 力学学报, 2008, 40(2): 194-206.

Tian P P, Zhao G P, Lu T J. Numerical analysis for dynamic response of sandwich plates with lattice and filling under impact loading [J]. Chinese Journal of Applied Mechanics, 2009, 26(4): 788-792. (in Chinese)

田培培, 赵桂平, 卢天健. 具有填充材料的金属格栅夹层板在高速冲击下动态响应的数值分析 [J]. 应用力学学报, 2009, 26(4): 788-792.

Zu X D, Huang Z X, Gu X H. Simulation analysis on poly-rubber resisted jet penetrating [J]. Journal of System Simulation, 2010, 22(1): 56-59. (in Chinese)

祖旭东, 黄正祥, 顾晓辉. 聚乙烯橡胶抗射流侵彻数值仿真研究 [J]. 系统仿真学报, 2010, 22(1): 56-59.

Dorfmann A, Ogden R W. A pseudo-elastic model for loading, partial unloading and reloading of particle-reforced rubber [J]. Int J Solids Struct, 2003, 40(11): 2699-2714.

Helte A, Liden E. The role of Kelvin-helmholtz instabilities on shaped charge jet interaction with reactive armours plates [C]//25th International Symposium on Ballistics. Beijing, 2010: 1547-1553.
