45钢板对半球形头弹的抗穿甲特性研究

邓云飞; 张伟; 曹宗胜

doi:10.11858/gywlxb.2013.06.019

45钢板对半球形头弹的抗穿甲特性研究

doi: 10.11858/gywlxb.2013.06.019

邓云飞^1,2,
张伟^2, ,,
曹宗胜²

1.
中国民航大学航空工程学院，天津 300300；
2.
哈尔滨工业大学空间碎片高速撞击研究中心，黑龙江哈尔滨 150080

详细信息

通讯作者:
张伟 E-mail:zhdawei@hit.edu.cn

计量
- 文章访问数: 6131
- HTML全文浏览量: 336
- PDF下载量: 234
出版历程
- 收稿日期: 2012-02-15
- 修回日期: 2012-04-17
- 发布日期: 2013-12-15

Experimental Investigation on the Ballistic Performance of 45 Steel Metal Plates Subjected to Impact by Hemispherical-Nosed Projectiles

1.
College of Aeronautical Engineering, Civil Aviation University of China, Tianjin 300300, China;
2.
Hypervelocity Impact Research Center, Harbin Institute of Technology, Harbin 150080, China

摘要

摘要: 利用轻气炮进行了38CrSi半球形头杆弹正撞击45钢板的撞击实验，研究了单层板、等厚接触式双层板和3层板对直径为12.7 mm弹体的抗穿甲性能。通过实验得到了这几种结构的初始-剩余速度曲线以及弹道极限，研究了分层数目对叠层靶抗侵彻性能和失效模式的影响。研究结果表明，多层板的弹道极限高于等厚单层板，单层板主要失效模式为剪切，而多层板的主要失效模式为整体的蝶形变形和局部的盘式隆起。对于多层板，靶板具体的失效模式与其在靶中位置相关。
- 弹体 /
- 穿甲 /
- 靶体 /
- 弹道极限
Abstract: A series of impact tests were conducted to investigate the ballistic performances of single, double- and three-layered 45 steel plates subjected to impact by hemispherical-nosed projectiles which were made from 38CrSi and diameter was 12.7 mm, the impact velocities ranged from 240 m/s to 600 m/s. The multi-layered plates arranged in various combinations of the same total thicknesses were normally impacted with the help of a gas gun. The initial and residual velocities of the projectiles were measured, and also the ballistic limit velocity for each configuration target was obtained and compared based on the investigation of the effect of the number of layers on the ballistic resistance. The results indicated that the ballistic limit velocity of multi-layered plate was higher than that of monolithic plate. The dominant failure model of monolithic plate was shearing, but the dominant failure models of multi-layered plate were global dishing and local bulging. Moreover, the failure models of plates of multi-layered plates were in relation to their order.
- projectile /
- perforation /
- target /
- ballistic limit

HTML全文

参考文献(13)

Teng X, Wierzbicki T, Huang M. Ballistic resistance of double-layered armor plates [J]. Int J Impact Eng, 2008, 35(8): 870-884.

Zhang W, Deng Y F, Cao Z S, et al. Experimental investigations on the ballistic performance of monolithic and layered metal plates subjected to impact by blunt rigid projectiles [J]. Int J Impact Eng, 2012, 49: 115-129.

Deng Y F, Zhang W, Cao Z S. Experimental investigation on the ballistic resistance of monolithic and multi-layered plates against ogival-nosed rigid projectiles impact [J]. Mater Design, 2013, 44: 228-239.

Deng Y F, Zhang W, Cao Z S. Experimental investigation on the ballistic resistance of monolithic and multi-layered plates against hemispherical-nosed projectiles impact [J]. Mater Design, 2012, 41: 266-281.

Gao G F, Li Y C, Huang R Y, et al. Study on effect mechanism of aspect ratio for vertical penetration of a long rod projectile [J]. Chinese Journal of High Pressure Physics, 2011, 25(4): 327-332. (in Chinese)

高光发, 李永池, 黄瑞源, 等. 长径比对长杆弹垂直侵彻能力影响机制的研究 [J]. 高压物理学报, 2011, 25(4): 327-332.

Deng Y F, Zhang W, Cao Z S, et al. Numerical investigation of penetration performance of segmented rods penetration into steel target [J]. Chinese Journal of High Pressure Physics, 2011, 25(3): 251-260. (in Chinese)

邓云飞, 张伟, 曹宗胜, 等. 分段弹侵彻效率的数值模拟研究 [J]. 高压物理学报, 2011, 25(3): 251-260.

Dey S, Bovik T, Teng X, et al. On the ballistic resistance of double-layered steel plates: An experimental and numerical investigation [J]. Int J Solids Struct, 2007, 44: 6701-6723.

Teng X, Wierzbicki T, Huang M. Ballistic resistance of double-layered armor plates [J]. Int J Impact Eng, 2008, 35: 870-884.

Nia A A, Hoseini G R. Experimental study of perforation of multi-layered targets by hemispherical-nosed projectiles [J]. Mater Design, 2011, 32(2): 1057-1065.

Gupta N K, Iqbal M A, Sekhon G S. Effect of projectile nose shape, impact velocity and target thickness on the deformation behavior of layered plates [J]. Int J Impact Eng, 2008, 35: 37-60.

Recht R F, Ipson T W. Ballistic perforation dynamics [J]. Int J Appl Mech(Trans ASME), 1963, 30: 384-390.
