矿用救生舱防爆门抗爆结构安全性数值分析

罗星娜; 黄平; 钱新明

doi:10.11858/gywlxb.2013.06.015

矿用救生舱防爆门抗爆结构安全性数值分析

doi: 10.11858/gywlxb.2013.06.015

北京理工大学爆炸科学与技术国家重点实验室，北京 100081

详细信息

通讯作者:
黄平 E-mail:ph6111@bit.edu.cn

计量
- 文章访问数: 6084
- HTML全文浏览量: 342
- PDF下载量: 415
出版历程
- 收稿日期: 2012-07-25
- 修回日期: 2012-10-10
- 发布日期: 2013-12-15

Simulation Analysis on Structure Safety of Refuge Chamber Door under Explosion Load

State Key Laboratory of Explosion Science & Technology, Beijing Institute of Technology, Beijing 100081, China

摘要

摘要: 为了保证矿用可移动式救生舱防爆门的结构安全性，采用非线性动力分析有限元软件ANSYS/LS-DYNA，分别建立了厚度为10、20和25 mm防爆门的有限元模型，模拟加载峰值压力0.6 MPa、持续时间300 ms的三角形爆炸冲击波，分析了防爆门的最大载荷和变形情况，并对20 mm厚防爆门增加加强筋结构前后的结构响应情况进行了对比。结果表明，防爆门承受爆炸载荷时的最大应力在门板与内表面加强筋的联接位置，最大位移在门板的中部位置，加强筋可以显著减小舱门的最大位移，增加加强筋的20 mm厚防爆门的最大位移由24.47 mm减少至5.25 mm。通过对比不同厚度救生舱防爆门的材料、重量和加工方式等因素，表明20 mm厚的防爆门增加加强筋后具有良好的结构安全性，满足矿用可移动式救生舱的要求。

Abstract: The door of coal mine mobile refuge chamber should keep strong structure during its life cycle. A basic structure of the door was designed. And finite element models of the door were established for numerical simulation, with thickness 10, 20, and 25 mm, respectively. Finite element software ANSYS/LS-DYNA was used in the numerical simulation. Deformation of the door under a triangle explosion shock wave with maximum value for 0.6 MPa and 300 ms duration was calculated. The maximum stress value appears in the connection position between the door plank and reinforced stiffeners. The maximum displacement value appears in the middle of the door plank. Stiffeners have significant effect on the maximum displacement. The maximum displacement of improved chamber door is reduced to 5.25 mm, having a decrease of 19.22 mm. According to the simulation analysis, the door with 20 mm thickness could fulfill the requirements of structure safety.

HTML全文

参考文献(21)

Sun J P. Research on emergency refuge system in underground mine [J]. Coal Science and Technology, 2011, 39(1): 69-71. (in Chinese)

孙继平. 煤矿井下紧急避险系统研究 [J]. 煤炭科学技术. 2011, 39(1): 69-71.

Sun J P. The key technologies of the refuge chamber and rescue capsule in the underground coal mine [J]. Coal Science and Technology, 2011, 36(5): 713-717. (in Chinese)

孙继平. 煤矿井下避难硐室与救生舱关键技术研究 [J]. 煤炭学报, 2011, 36(5): 713-717.

Wu Y T, Zhang Q M, Fu Y S. The safety of the blast-resistant doors using dynamic FEM analysis [J]. Journal of Projectiles, Rockets, Missiles and Guidance, 2007, 27(2): 245-247. (in Chinese)

吴义田, 张庆明, 付跃升. 某抗爆门结构防护性能的有限元分析 [J]. 箭弹与制导学报, 2007, 27(2): 245-247.

Lu X Z, Jiang J J. Dynamic numerical simulation of antiknock door under blast loads [J]. Proteciong Engineering, 2003, 37(4): 1-5. (in Chinese)

陆新征, 江见鲸. 抗爆门在爆炸载荷作用下有限元动力数值模拟 [J]. 防护工程, 2003, 37(4): 1-5.

Fang L Z. Analysis of protective obturator's valve structure [J]. Journal of Anhui University of Technology(Science), 2008, 28(1): 30-33. (in Chinese)

方林中. 防护密闭装置门扇结构分析 [J]. 安徽理工大学学报(自然科学版), 2008, 28(1): 30-33.

Lin J R. Engineering Material and Forming Technology [M]. Beijing: Higher Education Press, 2007: 82-86. (in Chinese).

林建榕. 工程材料及成型技术 [M]. 北京: 高等教育出版社, 2007: 82-86.

Cheng D X. Machinerys Handbook [M]. 5th ed. Beijing: Chemical Industry Press, 2002: 13-82.

成大先. 机械设计手册 [M]. 5版. 北京: 化学工业出版社, 2002: 13-82.

Beijing Institute of Technology ANSYS/LS-DYNA Technical Support Center. The foundation and method of use of algorithm for ANSYS/LS-DYNA [Z]. Beijing: Beijing Institute of Technology, 1999. (in Chinese)

北京理工大学ANSYS/LS-DYNA技术支持中心. ANSYS/LS-DYNA算法基础和使用方法 [Z]. 北京: 北京理工大学, 1999.

Ren T. The finite element analysis and design of blast resistant door [D]. Xian: Changan University, 2011: 20-21. (in Chinese)

任涛. 抗爆门有限元分析及优化设计 [D]. 西安: 长安大学, 2011: 20-21.

Zhao H J, Qian X M. Simulation analysis on structure safety of coal mine mobile refuge chamber under explosion load [J]. Safety Science, 2012, 50(4): 674-678.

Hu B Y, Liu D M, Bo J S, et al. Elastic response of spherical containment vessel to impulsive loads [J]. Journal of Vibration and Shock [J]. 1998, 17(3): 19-23, 87-88. (in Chinese)

胡八一, 刘大敏, 柏劲松, 等. 脉冲载荷下球形爆炸容器的弹性响应 [J]. 振动与冲击, 1998, 17(3): 19-23, 87-88.
