Theoretical Considerations on the Temperature Rise of Shaped Charge Particle Jet
-
摘要: 在确定多孔材料状态方程的基础上,从多孔药型罩材料在与爆轰波相互作用中受到冲击波加载及随后卸载引起的温升、多孔药型罩在压合时的塑性变形引起的温升以及聚能粒子流伸展过程中的塑性变形引起的温升等3个方面,对聚能粒子流温升进行了估算。利用MATLAB软件对多孔铜和密实铜药型罩形成的聚能粒子流和聚能射流的温升进行计算,计算结果表明:由于多孔铜药型罩在与爆轰波相互作用中受冲击波加载及随后卸载引起的温升,使得聚能粒子流的温升明显高于密实铜聚能射流的温升。Abstract: To estimate theoretically the temperature rise of shaped charge particle jet, the temperature rise was calculated based on the equation of state of the porous material determined. The temperature rise includes heating due to the shock wave transferred into the porous liner by the explosive detonation wave and due to the plastic work performed during porous liner and shaped charge particle jet elongation. The temperature rises of the porous copper shaped charge particle jet and the solid copper shaped charge jet were calculated by the MATLAB software. The calculated results show that: the temperature rise of the porous copper shaped charge particles jet was significantly higher than that of the solid copper shaped charge jet, because of the contribution that the shock wave transferred to the porous liner by the explosive detonation wave.
-
Key words:
- shaped charge particle jet /
- temperature rise /
- shaped charge /
- porous materials
-
Li R J, Liu T S, Shen Z W, et al. On stability of jet produced by shaped charge with porous liner [J]. Explosion and Shock Waves, 2009, 29(2): 217-220. (in Chinese) 李如江, 刘天生, 沈兆武, 等.多孔药型罩聚能射流的稳定性 [J].爆炸与冲击, 2009, 29(2): 217-220. Wang T F, Zhu H R. Copper-tungsten shaped charge liner and its jet [J]. Propell Explos Pyrot, 1996, 21(4): 193-195. Zygmunt B, Wilk Z. Formation of jets by shaped charges with metal powder liners [J]. Propell Explos Pyrot, 2008, 33(6): 482-487. Li R J, Shen Z W, Wang F Y. Initial porosity effect on the jet behavior of shaped charge [J]. Chinese Journal of High Pressure Physics, 2008, 22(4): 445-448. (in Chinese) 李如江, 沈兆武, 王凤英.药型罩初始孔隙度对聚能射流行为的影响 [J].高压物理学报, 2008, 22(4): 445-448. Hirsch E, Mayseless M. Penetration of porous jets [J]. J Appl Mech, Transactions ASME, 2010, 77(5): 1-7. Wang F Y, Liu T S, Gou R J, et al. A study on tungsten-copper-nickel alloy as shaped charge liner [J]. Acta Armamentar, 2001, 22(1): 112-114. (in Chinese) 王凤英, 刘天生, 苟瑞君, 等.钨铜镍合金药型罩研究 [J].兵工学报, 2001, 22(1): 112-114. Li R J.Study on the jet mechanisms of shaped charge with porous liner and its applications [D].Hefei: University of Science and Technology of China, 2008: 1-117.(in Chinese) 李如江.多孔药型罩聚能射流机理及应用研究 [D].合肥: 中国科学技术大学, 2008: 1-117. Pfeffer G. Determination par simulations numeriques de l'etat et des lois de fragmentation des jet de charges creuses [C]//5e symposium international de halistique.Toulouse, 1980: 16-18. Racah E. Shaped charge jet heating [J]. Propell Explos Pyrot, 1988, 13(6): 178-182. McQueen R G, Marsh S P. Proceedings of Symposium on High Dynamic Pressures [C]. New York: Gordon and Breach, 1968: 207. Herrmann W. Constitutive equation for the dynamic compaction of ductile porous materials [J]. J Appl Phys, 1969, 40(6): 2490-2499. Oрленко Л П. Explosion Physics [M].3rd ed. Translated by Sun C W. Beijing: Science Press, 2011. 奥尔连科 Л П.爆炸物理学 [M].第3版.孙承纬, 译.北京: 科学出版社, 2011. Trishin Y, Kinelovskii S. Effect of porosity on shaped-charge flow [J]. Combustion, Explosion, and Shock Waves, 2000, 36(2): 272-281.
