Dynamic Responses of Alumina Microvoid Ceramics with High Porosity under Combined Pressure and Shear Impact Loading
-
摘要: 基于一级压剪轻气炮,对高孔隙率Al2O3微孔陶瓷(孔隙率47%~50%)进行冲击速度为68~201 m/s、倾斜角为0~15的平板撞击实验,研究了相关的动态压缩及剪切特性。结果表明,由于材料的气孔为直径小于5 m的微孔,其压缩过程是一个渐进的均匀发展的过程,并没有孔洞崩塌现象发生;其剪切行为表现出脆性材料的一般特性。基于Hoek-Brown准则和帽盖模型,建立了孔隙介质动态破坏模型和动态双重屈服面模型。结合压剪实验数据,对模型进行了初步分析,分析结果表明了此模型的适用性。Abstract: Based on one-stage light gas gun, series of experiments including oblique planar impact with inclination angles of 0~15 and impact velocity ranging from 68 to 201 m/s were carried out to investigate the responses of alumina microvoid ceramics with high porosity subjected to impact loading. Experimental results show that since the diameter of microvoid in sample is smaller than 5 m, the process of sample compression is gradually and evenly developed, and there is no porous collapse observed. The dynamic shear behaviors are similar to those of brittle materials. Based on the Hoek-Brown criteria and Cap-model, the dynamic model for the failure surface and the double yield surfaces of porous brittle materials was built. Based on the experimental data of compression and shear combined impact loading, the preliminary analyses were carried out and the results show the applicability of the model.
-
Gupta Y M. Measurement of compression and shear waves in an impact experiment: Role of gauge leads in particle-velocity measurement [J]. J Appl Phys, 1980, 51(3): 1835-1838. Abou-Sayed A S, Clifton R J. Pressure-shear waves in fused silica [J]. J Appl Phys, 1976, 47(5): 1762-1770. Munson D E, Lawrence R J. Dynamic deformation of polycrystalline alumina [J]. J Appl phys, 1979, 50(10): 6272-6282. Li P, Li D H, Ning J G, et al. Dynamic response of polycrystalline alumina under shock loading [J]. Chinese Journal of High Pressure Physics, 2002, 16(1): 22-28. (in Chinese) 李平, 李大红, 宁建国, 等. 冲击载荷下Al2O3陶瓷的动态响应 [J]. 高压物理学报, 2002, 16(1): 22-28. Espinosa H D, Raiser G, Clifton R J, et al. Experimental observations and numerical modeling of inelasticity in dynamically loaded ceramics [J]. J Hard Mater, 1992, 3(3-4): 285-313. Tang Z P, Xu S L, Dai X Y, et al. S-wave tracing technique to investigate the damage and failure behavior of brittle materials subjected to shock loading [J]. Int J Impact Engineering, 2005, 31(9): 1172-1191. Tang Z P, Hu X J, Liao X L, et al. An experimental facility for measuring longitudinal and shear waves with dual magnetic fields [J]. J Exp Mech, 2000, 15(1): 16-21. (in Chinese) 唐志平, 胡晓军, 廖香丽, 等. 双磁场IMPS粒子速度测试系统 [J]. 实验力学, 2000, 15(1): 16-21. Xu S L, Zhang K, Zheng W, et al. Experimental study of impact performance of Al2O3 microvoid ceramics with high porosity [J]. J Exp Mech, 2008, 23(6): 525-532. (in Chinese) 徐松林, 张侃, 郑文, 等. 高孔隙率Al2O3 微孔陶瓷冲击性能实验研究 [J]. 实验力学, 2008, 23(6): 525-532. Xu S L. Investigation on the S-wave tracing technique and the behavior of cementitious composites under combining compression and shear impact loading [R]. Hefei: University of Science and Technology of China, 2003. (in Chinese) 徐松林. S波跟踪技术与水泥基复合材料压剪动特性研究 [R]. 合肥: 中国科学技术大学, 2003. Xu S L, Tang Z P, Zhang X H. Dynamic shear properties of steel fiber reinforced cement under combined pressure and shear impact loading [J]. Engin Mech, 2006, 23(5): 139-146. (in Chinese) 徐松林, 唐志平, 张兴华. 钢纤维增强水泥砂浆压剪联合冲击下动态剪切性能 [J]. 工程力学, 2006, 23(5): 139-146. Xu S L, Tang Z P, Hu X J, et al. Experimental investigation on dynamic properties of the polypropylene micro-fiber reinforced cement(FCEM) under impact loading [J]. Explosion and Shock Waves, 2004, 24(3): 251-260. (in Chinese) 徐松林, 唐志平, 胡晓军, 等. 聚丙烯短微纤维增强水泥砂浆冲击特性研究 [J]. 爆炸与冲击, 2004, 24(3): 251-260. Xi D Y, Xu S L. Fundamental of Rock Physics [M]. Hefei: Publishing House of University of Science and Technology of China, 2012 (in Chinese) 席道瑛, 徐松林. 岩石物理学基础 [M]. 合肥: 中国科学技术大学出版社, 2012. Drucker D C, Prager W. Soil mechanics and plastic analysis or limit design [J]. Q Appl Math, 1952, 10(2): 157-165. Dimaggio F L, Sandler I S. Material models for granular soils [J]. J Eng Mech Div, 1971, 97: 935-950. Abduljauwad S N, Al-Buraim I M, Al-Ghamedy H N. Mixed hardening, three-invariants dependent cap model [J]. J Eng Mech, 1992, 118(3): 620-637. Aubertin M, Li L. A porosity-dependent inelastic criterion for engineering materials [J]. Int J Plast, 2004, 20(12): 2179-2208.
