Local Damage Effects of X70 Steel Pipe Subjected to Contact Explosion Loading
-
摘要: 对大直径X70钢油气管道在接触爆炸下的破坏效应进行了野外化爆实验，获得了不同装药量及不同壁厚条件下钢管道的接触爆炸破坏特征。实验结果表明：接触爆炸载荷作用下管壁迎爆面局部破坏明显，且呈花瓣形破口，同时产生具有较大质量和动能的爆炸破片，破片与对面管壁碰撞后形成凹坑，甚至发生贯穿现象。基于动力有限元程序LS-DYNA及Lagrangian-Eulerian耦合方法，对钢管在外接触爆炸载荷作用下的非线性动态响应过程进行三维数值模拟，得到管壁迎爆面的变形破坏及对面管壁在爆炸破片碰撞下的后效作用过程，计算结果与实验结果符合良好。研究结果为在役油气管道的抗爆能力分析及安全性评估提供了参考依据。Abstract: Field explosion experiments were carried out to investigate the contact explosion damage effects of large diameter X70 steel oil-gas pipes. The contact explosion damage characteristics of pipes with different pipe wall thickness under various charge were analyzed. The experimental results show that the local damage of the pipe wall facing explosion is predominant and there is a petal-shaped crevasse. In addition, the fragments with abundant kinetic energy are formed. The dent or perforation phenomenon will occur after the opposite pipe wall is impacted by the fragment. By means of an explicit nonlinear dynamic finite element computer code LS-DYNA, the nonlinear dynamic response process of the steel pipe under contact explosion loading was numerically simulated with Lagrangian-Eulerian coupling method. The damage process of the pipe wall facing explosion and the after effects of opposite pipe wall due to the impact of fragment were described. The numerical simulation results are in good agreement with experimental data. The results can provide important reference for the blast resistant properties analysis and safety assessment of oil-gas pipes.
-
Key words:
- contact explosion /
- steel pipe /
- local damage /
- after-effects
-
Zhang T G, Stronge W J. Rupture of thin ductile tubes by oblique impact of blunt missiles: Experiments [J]. Int J Impact Eng, 1998, 21(7): 571-587. Shen X J, Zhang P X, Sun T, et al. Research on thick barrel's damages due to impaction by fragments of high explosive projectile [J]. Acta Armamentarii, 2005, 26(4): 438-442. (in Chinese) 沈晓军, 张鹏翔, 孙韬, 等. 杀爆战斗部破片对厚壁钢管的毁伤效应研究 [J]. 兵工学报, 2005, 26(4): 438-442. Rushton N, Schleyer G K, Clayton A M, et al. Internal explosive loading of steel pipes [J]. Thin-Walled Struct, 2008, 46(7/8/9): 870-877. Lu S Z, Zhang B Y, Wang W, et al. Experimental research on dynamic response mechanism of thin cylindrical shell under blast loading [J]. Journal of Nanjing University of Science and Technology, 2011, 35(5): 621-626. (in Chinese) 路胜卓, 张博一, 王伟, 等. 爆炸作用下薄壁柱壳结构动力响应实验研究 [J]. 南京理工大学学报, 2011, 35(5): 621-626. Pan X H, Xu J, Jiang J C. Simulation analysis of dynamic response of thin-wall cylindrical tank to shock wave [J]. Journal of Chemical Industry and Engineering (China), 2008, 59(3): 798-801. (in Chinese) 潘旭海, 徐进, 蒋军成. 圆柱形薄壁储罐对爆炸冲击波动力学响应的模拟分析 [J]. 化工学报, 2008, 59(3): 798-801. Johnson G R, Cook W H. Fracture characteristics of three metals subjected to various strains, strain rates, temperatures and pressures [J]. Eng Fract Mech, 1985, 21(1): 31-48. Zhang G R, Chen D N. Condensed Explosives Detonation Dynamics [M]. Beijing: National Defence Industry Press, 1991. (in Chinese) 章冠人, 陈大年. 凝聚炸药起爆动力学 [M]. 北京: 国防工业出版社, 1991. Mu J L, Zhu X, Huang X M, et al. Crevasse computation for a clamped square plate subjected to near-field noncontact underwater explosion [J]. Journal of Vibration and Shock, 2011, 30(1): 37-39. (in Chinese) 牟金磊, 朱锡, 黄晓明, 等. 水下近场非接触爆炸作用下固支方板破口计算 [J]. 振动与冲击, 2011, 30(1): 37-39. -
