横向VISAR及其在爆轰驱动楔形靶自由面横向速度测量中的应用

陈光华; 刘俊; 蒙建华; 彭其先; 袁树云; 王德田; 邓向阳

doi:10.11858/gywlxb.2013.04.007

横向VISAR及其在爆轰驱动楔形靶自由面横向速度测量中的应用

doi: 10.11858/gywlxb.2013.04.007

中国工程物理研究院流体物理研究所，四川绵阳 621900

详细信息

通讯作者:
陈光华 E-mail:chen_guanghua@sina.com

计量
- 文章访问数: 5768
- HTML全文浏览量: 262
- PDF下载量: 311
出版历程
- 收稿日期: 2012-05-21
- 修回日期: 2012-06-18
- 发布日期: 2013-08-15

A Transverse VISAR for Measuring Free Surface Transverse Velocity of Detonation-Driven Wedge Target

Institute of Fluid Physics, CAEP, Mianyang 621900, China

摘要

摘要: 利用多点双灵敏度VISAR（任意反射面速度干涉仪）和三探头装置，搭建了横向VISAR测量系统。在三探头装置中，一个探头发射并接收激光，另外两个探头从不同方向接收激光。根据三探头接收激光的多普勒频移，可推出测点的纵向和横向速度。开展了爆轰驱动楔形靶实验，利用平面波透镜和Т/Г炸药在10钢楔形靶中产生平面冲击波，采用横向VISAR测量系统，观测冲击波斜碰撞楔形靶自由面引起的自由面横向运动。测量得到的最大纵向速度约1 680 m/s，最大横向速度约140 m/s。对横向速度测量不确定度进行了分析，不确定度约为33 m/s。
- 横向VISAR /
- 横向速度 /
- 纵向速度 /
- 冲击波 /
- 楔形靶
Abstract: A transverse velocity interferometer system for any reflector (VISAR) has been developed by combination of a multipoint VISAR and a tri-probe device. One probe emits and receives laser, and the other two probes receive laser from different directions. The transverse and longitudinal velocities can be deduced from Doppler shift of laser received by the tri-probe. The transverse VISAR were applied to detonation driving wedge target experiments. Planar shock wave in a 10 wedge steel target was generated by plane-wave lens and T/ explosive. The free surface transverse velocities induced by oblique collision of shock wave were measured. The maximum measured longitudinal velocity is about 1 680 m/s, and the maximum measured transverse velocity is about 140 m/s. The uncertainty of the transverse velocity measurement was analyzed, and the uncertainty is estimated to be about 33 m/s in the experiments.
- transverse VISAR /
- transverse velocity /
- longitudinal velocity /
- shock wave /
- wedge target

HTML全文

参考文献(19)

Barker L M, Hollenbach R E. Laser interferometer for measuring high velocities of any reflecting surface [J]. J Appl Phys, 1972, 43(11): 4669-4675.

Chen G H, Li Z R, Liu Y K, et al. Flyer velocity measurement using double-sensitivity VISAR [J]. Chinese Journal of High Pressure Physics, 2001, 15(1): 70-74. (in Chinese)

陈光华, 李泽仁, 刘元坤, 等. 用双灵敏度VISAR测量铜飞片自由面速度 [J]. 高压物理学报, 2001, 15(1): 70-74.

Wang D T, Peng Q X, Liu J, et al. Application of laser velocity interferometry in interior ballistic projectile velocity measurement [J]. Chinese Journal of High Pressure Physics, 2011, 25(2): 133-137. (in Chinese)

王德田, 彭其先, 刘俊, 等. 激光干涉测速技术在内弹道弹丸速度测量中的应用研究 [J]. 高压物理学报, 2011, 25(2): 133-137.

Li Z R, Ma R C, Chen G H, et al. Multipoint velocity interferometer system for any reflector [J]. Rev Sci Instrum, 1999, 70(10): 3872-3876.

Hemsing W F, Mathews A R, Warnes R H, et al. VISAR: Line-imaging interferometer [C]//American Physical Society (APS) Conference on Shock Compression of Condensed Matter. Williamsburg, USA, 1991.

Liu S X, Li Z R, Peng Q X, et al. Line-imaging velocity interferometer for laser driven flyer diagnostics [J]. High Power Laser and Particle Beams, 2010, 22(10): 2281-2284. (in Chinese)

刘寿先, 李泽仁, 彭其先, 等. 用于激光驱动飞片诊断的线成像速度干涉仪 [J]. 强激光与粒子束, 2010, 22(10): 2281-2284.

Durand M, Laharrague P, Lalle P, et al. Interferometric laser technique for accurate velocity measurement in shock wave physics [J]. Rev Sci Instrum, 1977, 48(3): 275-278.

Chen G H, Liu S X, Li Z R, et al. Application analysis of angular dispersion Fabry-Perot velocity interferometry [J]. Explosion and Shock Waves, 2011, 31(6): 585-591. (in Chinese)

陈光华, 刘寿先, 李泽仁, 等. 角色散FP干涉测速技术应用与分析 [J]. 爆炸与冲击, 2011, 31(6): 585-591.

Chen G H, Li Z R, Liu J, et al. Angular dispersion-type Fabry-Perot interferometer with velocity spectral resolution [J]. Chinese Journal of High Pressure Physics, 2012, 26(4): 402-408. (in Chinese)

陈光华, 李泽仁, 刘俊, 等. 具有速度谱分辨能力的角色散FP干涉测量技术 [J]. 高压物理学报, 2012, 26(4): 402-408.

Strand O T, Goosman D R, Martinez C, et al. Compact system for high-speed velocimetry using heterodyne techniques [J]. Rev Sci Instrum, 2006, 77(8): 083108.

Kim K S, Clifton R J, Kumar P. A combined normal- and transverse-displacement interferometer with an application to impact of y-cut quartz [J]. J Appl Phys, 1977, 48(10): 4132-4139.

Espinosa H D, Mello M, Xu Y. A desensitized displacement interferometer applied to impact recovery experiments [J]. Appl Phys Lett, 1996, 69(21): 3161-3163.

Chhabildas L C, Sutherland H J, Asay J R. A velocity interferometer technique to determine shear-wave particle velocity in shock-loaded solids [J]. J Appl Phys, 1979, 50(8): 5196-5201.

Alexander C S, Asay J R, Haill T A. Magnetically applied pressure-shear: A new method for direct measurement of strength at high pressure [J]. J Appl Phys, 2010, 108(12): 126101.
