单级脉冲感应线圈炮能量转换效率优化研究

刘文彪; 张媛; 曹延杰

doi:10.11858/gywlxb.2013.02.019

单级脉冲感应线圈炮能量转换效率优化研究

doi: 10.11858/gywlxb.2013.02.019

海军航空工程学院，山东烟台 264001

详细信息

通讯作者:
刘文彪 E-mail:lwb80314@sohu.com

计量
- 文章访问数: 7110
- HTML全文浏览量: 426
- PDF下载量: 425
出版历程
- 收稿日期: 2011-02-25
- 修回日期: 2012-08-23
- 发布日期: 2013-04-15

Optimization and Analysis of Energy Conversion Efficiency in Single Stage Pulse Induction Coilguns

Naval Aeronautical and Astronautical University, Yantai 264001, China

摘要

摘要: 以系统能量转换效率为目标函数，建立了单级脉冲感应线圈炮的数学模型，对电枢初始位置、电容器组放电电压和电容量进行了优化分析，获得了三者影响能量转换效率的规律。分析结果表明，要提高系统能量转换效率，弹丸穿越驱动线圈时加速行程的时间应当与驱动线圈中电流的上升时间相匹配，通常情况下电容器组采用高电压、小电容量的配置方式,系统可获得较大的能量转换效率。
- 单级脉冲感应线圈炮 /
- 能量转换效率 /
- 目标函数 /
- 优化
Abstract: In order to gain the rule between them, the mathematic model of single stage pulse induction coilguns is built, and the launch process is simulated and analyzed. The electrical-to-kinetic energy conversion efficiency of system is regarded as a target function, and the initial position of the armature, the discharge voltage and the capacitance of capacitor banks are regarded as variables. Results of analysis indicate that the time of projectile to be accelerated in the drive-coil should match the time of current rising in the drive-coil. As a rule, the high energy conversion efficiency can be gained in the system with capacitor banks of high voltage and low capacitance.
- single stage pulse induction coilguns /
- energy conversion efficiency /
- target function /
- ptimization

HTML全文

参考文献(17)

Subramanian R, Kaye R, van Reuth E, et al. Development and testing for an electromagnetic mortar [C]//2007 Mortars Conference. Morristown, NJ, USA, 2007.

Luo L Y, Xu X, Mao Y. Structural optimization design of electromagnetic coil launcher [J]. Electrical Engineering, 2010(sl): 31-37. (in Chinese)

罗凌雁, 徐晓, 毛勇. 线圈型电磁发射器结构优化设计 [J]. 电气技术, 2010(sl): 31-37．

Liu W B, Zhong P L, Zou P, et al. Simulation and analysis of muzzle velocity in single stage inductive coilgun [J]. Journal of Naval Aeronautical and Astronautical University, 2009, 24(1): 31-33. (in Chinese)

刘文彪, 钟佩琳, 邹平, 等. 单级感应线圈炮出口速度仿真 [J]. 海军航空工程学院学报, 2009, 24(1): 31-33.

Wang Y, Xiao F. Theory of Electric Gun [M]. Beijing: National Defense Industry Press, 1995: 93-97. (in Chinese)

王莹, 肖峰. 电炮原理 [M]. 北京: 国防工业出版社, 1995: 93-97.

Cheng J, Ren Z X. Mechanism analysis of single stage coil accelerating armature [J]. Journal of Electrician Technology, 1997(5): 29-31. (in Chinese)

程键, 任兆杏. 单级线圈加速电枢的机理分析 [J]. 电工技术杂志, 1997(5): 29-31.

Cao Y J, Liu W B, Zhang Y, et al. Simulation and analysis of single stage induction coilgun's best initial position [J]. Computer Simulation, 2006, 23(12): 9-11. (in Chinese)

曹延杰, 刘文彪, 张媛, 等. 单级感应线圈炮最佳初始位置仿真研究 [J]. 计算机仿真, 2006, 23(12): 9-11.

Zhao K Y, Li Z Y, Cheng S K. Dynamic simulation of working process of the single-stage induction coil-gun [J]. High Voltage Engineering, 2008, 34(8): 1667-1671. (in Chinese)

赵科义, 李治源, 程树康. 单级感应线圈炮工作过程的动态仿真 [J]. 高电压技术, 2008, 34(8): 1667-1671.

Zhang T, Su Z Z, Guo W, et al. Simulation of working process of single-stage induction coil-gun considering different projectile's structures [J]. Electrical Engineering, 2010(sl): 24-26. (in Chinese)

张涛, 苏子舟, 国伟, 等. 不同弹丸结构的单级感应线圈炮仿真研究 [J]. 电气技术, 2010(sl): 24-26.

Su Z Z, Guo W, Zhang T, et al. Effect of launch initial position on the performance of coil-gun by the pullback weight of the projectile [J]. Electrical Engineering, 2010(sl): 27-30. (in Chinese)

苏子舟, 国伟, 张涛, 等. 弹丸配重对线圈炮最佳初始位置影响研究 [J]. 电气技术, 2010(sl): 27-30．
