多点起爆下药型罩表面压力分布规律研究

赵长啸; 龙源; 纪冲; 李裕春; 谢全民; 路亮

doi:10.11858/gywlxb.2013.01.012

多点起爆下药型罩表面压力分布规律研究

doi: 10.11858/gywlxb.2013.01.012

赵长啸^1,2, ,,
龙源¹,
纪冲¹,
李裕春¹,
谢全民³,
路亮¹

1.
解放军理工大学，江苏南京 210007；
2.
北京理工大学爆炸科学与技术国家重点实验室，北京 100081；
3.
武汉军械士官学校，湖北武汉 430075

详细信息

通讯作者:
赵长啸 E-mail:blastingzhao@163.com

计量
- 文章访问数: 6754
- HTML全文浏览量: 266
- PDF下载量: 587
出版历程
- 收稿日期: 2011-12-08
- 修回日期: 2012-05-22
- 发布日期: 2013-02-15

Distribution Law of Pressure on Liner Surface under Multi-Point Initiation

1.
PLA University of Science and Technology, Nanjing 210007, China;
2.
State Key Laboratory of Explosion Science and Technology, Beijing Institute of Technology, Beijing 100081, China;
3.
Wuhan Ordnance N.C.O. Academy of PLA, Wuhan 430075, China

摘要

摘要: 为了掌握多点起爆下药型罩表面压力的分布规律以及起爆点参数对压力分布的影响，运用LS-DYNA 3D有限元软件，对多点起爆时爆轰波相互碰撞并作用于药型罩的过程进行数值仿真研究。仿真结果与实验结果吻合较好。研究结果表明：多点起爆时，爆轰波在起爆点的对称平面处发生碰撞，碰撞位置出现超压现象，导致作用于药型罩表面的爆轰载荷分布不均匀，爆轰波碰撞区域的压力高于非碰撞区域；随着起爆点间距的增大，爆轰波作用于药型罩顶部的压力逐渐增大，而边缘部位的压力则逐渐减小，当间距为50 mm时压力发生突降，即起爆点间距存在上限值；随着起爆点数的增加，药型罩表面微元的压力逐渐增大，但增加幅度逐渐减小，压力的总体分布规律相似。研究结果为带尾翼爆炸成形弹丸战斗部中起爆点参数等关键技术设计提供了理论依据。
- 爆炸成形弹丸 /
- 爆轰波碰撞 /
- 多点起爆 /
- 压力分布 /
- 药型罩
Abstract: In order to investigate the distribution law of pressure on the liner surface and the effect of initiation point parameter on the pressure distribution, the interaction of detonation waves with each other and with the liner is simulated by LS-DYNA software. The simulation results coincide well with the experimental data. The results of the study indicate that detonation waves collide with each other on the symmetry plane of the initiation points, and the pressure of collision position increases, which make the pressure distribution of liner uneven. While the distance between initiation points is bigger, the pressure of tip liner increases quickly, but the pressure of edge region of liner decreases gradually. When the distance is 50 mm, the pressure drops suddenly, namely the distance has a maximum value. The pressure of liner increases with the number of initiation point, but the increase rate reduces gradually, and the pressure distribution laws on the liner surface with different initiation numbers are similar. The conclusions can supply a theoretical basis for choosing appropriate initiation point parameters of the explosively formed projectile with star shaped tail.
- explosively formed projectile /
- collision of detonation waves /
- multi-point initiation /
- pressure distribution /
- liner

HTML全文

参考文献(16)

Bouet T H, Tarayre P, Guillon J P, et al. Study of a multi-point ignition EFP [C]//Proceedings of the 15th International Symposium on Ballistics, Jerusalem, Israel, 1995: 159-166.

Bender D, Chhouk B, Fong R, et al. Explosively formed penetrators (EFP) with canted fins [C]//Proceedings of the 19th International Symposium on Ballistics, Interlaken, Switzerland, 2001: 755-761.

Li W B, Wang X M, Li W B. The effect of annular multi-point initiation on the formation and penetration of an explosively formed penetrator [J]. Int J Impact Eng, 2010, 37(4): 414-424.

Qi X Q, Long Y, Wan W Q, et al. Numerical simulation of effect of blasting wave on EFP performance [J]. Journal of Projectiles, Rockets, Missiles and Guidance, 2008, 28(3): 115-117. (in Chinese)

亓秀泉, 龙源, 万文乾, 等. 爆轰波形对EFP性能影响的数值模拟 [J]. 弹箭与制导学报, 2008, 28(3): 115-117.

Yu C, Dong Q D, Sun C W, et al. The experimental studies of explosively formed projectile with star shaped tail [J]. Explosion and Shock Waves, 2003, 23(6): 561-564. (in Chinese)

于川, 董庆东, 孙承纬, 等. 带尾翼翻转型爆炸成形弹丸试验研究 [J]. 爆炸与冲击, 2003, 23(6): 561-564.

Gui Y L, Yu C, Liu C L, et al. 3D simulation of over-turned explosively formed projectile (EFP) with star-shaped fins [J]. Explosion and Shock Waves, 2005, 25(4): 313-318. (in Chinese)

桂毓林, 于川, 刘仓理, 等. 带尾翼的翻转型爆炸成形弹丸的三维数值模拟 [J]. 爆炸与冲击, 2005, 25(4): 313-318.

Zhou X. Technological researches on explosive formed projectiles [D]. Nanjing: PLA University of Science and Technology, 2006. (in Chinese)

周翔. 爆炸成型弹丸战斗部的相关技术研究 [D]. 南京: 解放军理工大学, 2006.

Zhang B P, Zhang Q M, Huang F L. Detonation Physics [M]. Beijing: Weapon Industry Press, 2001: 180-182. (in Chinese)

张宝坪, 张庆明, 黄风雷. 爆轰物理学 [M]. 北京: 兵器工业出版社, 2001: 180-182.

Cao B, Yu Z Y, Chen H W. An experimental investigation on the loading performance and propagation law of detonation Mach waves [J]. Journal of Ballistics, 2000, 12(2): 78-83. (in Chinese)

曹兵, 宇志勇, 陈惠武. 爆轰马赫波载荷特性及传播规律实验研究 [J]. 弹道学报, 2000, 12(2): 78-83.

Bourne B, Curtis J P, Cowan K G, et al. Variable multiple point initiated chemical energy warheads [C]//Proceedings of the 18th International Symposium on Ballistics, San Antonio, USA, 1999: 426-433.
