变截面杆共轴撞击数值分析及其应用前景

罗鑫; 许金余; 李为民; 白二雷

doi:10.11858/gywlxb.2012.06.018

变截面杆共轴撞击数值分析及其应用前景

doi: 10.11858/gywlxb.2012.06.018

罗鑫¹,
许金余^1,2, ,,
李为民³,
白二雷¹

1.
空军工程大学工程学院机场建筑工程系，陕西西安 710038；
2.
西北工业大学力学与土木建筑学院，陕西西安 710072；
3.
中南航空港建设公司合同预算科，广东广州 510403

详细信息

通讯作者:
许金余 E-mail:jinyuxu@263.net

计量
- 文章访问数: 7586
- HTML全文浏览量: 426
- PDF下载量: 483
出版历程
- 收稿日期: 2011-03-17
- 修回日期: 2011-05-06
- 发布日期: 2012-12-15

Numerical Analysis on the Coaxial Collision of Variable Section Bar and Application Prospect

LUO Xin¹,
XU Jin-Yu^{1,2
, ,},
LI Wei-Min³,
BAI Er-Lei¹

1.
Department of Airfield and Building Engineering, Engineering College, Air Force Engineering University, Xi'an 710038, China;
2.
College of Mechanics and Civil Architecture, Northwest Polytechnic University, Xi'an 710072, China;
3.
Department of Budget, Central South Airport Construction Company, Guangzhou 510403, China

摘要

摘要: 为对弹性杆共轴撞击这一应力波基础问题进行扩展研究，基于非线性动力学软件LS-DYNA建立了有限元模型，分析了共轴撞击的变截面杆的形态参数对波形的影响规律，探讨了应力波产生的机理，并对其应用前景进行了展望。结果表明,由于变截面效应，一定形态参数的变截面杆共轴撞击可以得到具备波阵面平滑上升，较长的前沿升时和消除了波形振荡等特性的应力波；该特性是变截面杆撞击这一过程的内在属性，主要由变截面段的最小半径控制，变截面段长度仅对局部形态产生影响，对加载速度的变化不敏感；半无限长的变截面杆共轴撞击规律可在应力波加工等领域应用。由此可见，该规律对基础性理论进行了扩展，应用前景广阔。
- 固体力学 /
- 应力波 /
- 变截面杆 /
- 数值分析 /
- 霍普金森压杆
Abstract: In order to perform extensive research on the coaxial collision of elastic bar, finite element model was established based on LS-DYNA, the influences of the shape parameters of variable section bar on the stress wave were analyzed, producing mechanism of stress wave was discussed, and its application and development prospect in this field were also explored. The results show that, because of the variable section effect, the coaxial collision of variable section bar under conditions of some shape parameters can create the stress wave, which has the following characteristics: wave front rising is in the form of smooth concave curve, the rising time is longer and there is no waveform oscillations phenomenon. The characteristics are the intrinsic attributes of the coaxial collision of variable section bar, controlled mainly by minimum radius of variable section scope in bar, and length of variable section scope in bar exerts an influence on the partial difference; besides, the characteristics are not sensitive to the change of the loading speed. The laws obtained by the coaxial collision of variable section bar can be applied to many fields such as waveform shaping. Thus it can be seen, these laws extend the foundational theories, which can be of great theoretical and realistic significance, and moreover, its application prospect is wonderful.
- solid mechanics /
- stress wave /
- variable section bar /
- numerical analysis /
- split Hopkinson pressure bar(SHPB)

HTML全文

参考文献(24)

Wang L L, Zhu Z X. Foundation of Stress Waves [M]. Beijing: National Defense Industry Press, 2005. (in Chinese)

王礼立, 朱兆祥. 应力波基础 [M]. 北京: 国防工业出版社, 2005.

Kolsky H. An investigation of the mechanical properties of materials at very high rates of loading [J]. Proc Phys Soc London, 1949, 62(Ⅱ-B): 676-700.

Li X B, Lok T S, Zhao J, et al. Oscillation elimination in the Hopkinson bar apparatus and resultant complete dynamic stress strain curves for rocks [J]. Int J Rock Mechan Min Sci, 2000, 37: 1055-1060.

Li W M, Xu J Y. Mechanical properties of basalt fiber reinforced geopolymeric concrete under impact loading [J]. Mater Sci Eng A, 2009, 505(1-2): 178-186.

Luo X, Xu J Y, Li W M. Early impact properties of fiber reinforced geopolymeric concretes [J]. Journal of Vibration and Shock, 2009, 28(10): 163-168. (in Chinese)

罗鑫, 许金余, 李为民. 纤维增强地质聚合物混凝土早期冲击力学性能的对比研究 [J]. 振动与冲击, 2009, 28(10): 163-168.

Johnson W. Impact Strength of Materials [M]. London: Edward Arnold, 1972.

Wang L L, Hu S S. The amplifying characteristic of wave propagation in cone bars [J]. Journal of Ningbo University, 1988, 1(2): 70-78. (in Chinese)

王礼立, 胡时胜. 锥杆中应力波传播的放大特性 [J]. 宁波大学学报, 1988, 1(2): 70-78.

Zhou G Q, Liu X M. Two-dimensional numerical analysis of stress-wave-amplifier [J]. Applied Mathematics and Mechanics, 1985, 6(9): 797-805. (in Chinese)

周光泉, 刘孝敏. 应力波放大器二维数值分析 [J]. 应用数学和力学, 1985, 6(9): 797-805.

Liu X M, Hu S S. Wave propagation characteristics in cone bars used for variable cross [J]. Explosion and Shock Waves, 2000, 20(6): 110-114. (in Chinese)

刘孝敏, 胡时胜. 应力脉冲在变截面SHPB锥杆中的传播特性 [J]. 爆炸与冲击, 2000, 20(6): 110-114.

Bai J Z. Theoretical Basis and Case Study of LS-DYNA3D [M]. Beijing: Science Press, 2005. (in Chinese)

白金泽. LS-DYNA3D理论基础与实例分析 [M]. 北京: 科学出版社, 2005.

Frew D J, Forrestal M J, Chen W. Pulse shaping techniques for testing brittle materials with a split Hopkinson pressure bar [J]. Exp Mech, 2002, 42(1): 93-106.

Zhou Z L, Li X B, Zuo Y J, et al. Fracture characteristics of rock fragmentation at strain rate of 100-102 s-1 [J]. Journal of Central South University of Technology, 2006, 13(3): 290-294.

Song B, Chen W, Antoun B R, et al. Determination of early flow stress for ductile specimens at high strain rates by using a SHPB [J]. Exp Mech, 2007, 47(5): 671-679.

Frew D J, Forrestal M J, Chen W. Pulse shaping techniques for testing brittle materials with a split Hopkinson pressure bar [J]. Exp Mech, 2002, 42(1): 93-106.

Li W M, Xu J Y. Impact characterization of basalt fiber reinforced geopolymeric concrete using a 100 mm-diameter split Hopkinson pressure bar [J]. Mater Sci Eng A, 2009, 513-514: 145-153.

Lok T S, Li X B, Liu D, et al. Testing and response of large diameter brittle materials subjected to high strain rate [J]. Journal of Materials in Civil Engineering, 2002, (14): 262-269.

Luo X, Xu J J, Li W M, et al. Numerical simulation and spectral analysis of dispersion effect of stress pulse in SHPB tests [J]. Journal of Experimental Mechanics, 2010, 25(4): 451-456. (in Chinese)

罗鑫, 许金余, 李为民, 等. 应力脉冲在SHPB试验中的弥散效应的数值模拟与频谱分析 [J]. 实验力学, 2010, 25(4): 451-456.
