缺陷对金属蜂窝材料面内冲击性能的影响

张新春; 刘颖

doi:10.11858/gywlxb.2012.06.008

缺陷对金属蜂窝材料面内冲击性能的影响

doi: 10.11858/gywlxb.2012.06.008

张新春^1, ,,
刘颖²

1.
华北电力大学机械工程系，河北保定 071003；
2.
北京交通大学力学系，北京 100044

详细信息

通讯作者:
张新春 E-mail:zhangxinchun551@163.com

计量
- 文章访问数: 7436
- HTML全文浏览量: 331
- PDF下载量: 386
出版历程
- 收稿日期: 2011-04-15
- 修回日期: 2011-06-30
- 发布日期: 2012-12-15

Effect of Defects in-Plane of Metal Honeycomb on Its Dynamic Impact Properties

ZHANG Xin-Chun^{1
, ,},
LIU Ying²

1.
Department of Mechanical Engineering, North China Electric Power University, Baoding 071003, China;
2.
Department of Mechanics, Beijing Jiaotong University, Beijing 100044, China

摘要

摘要: 利用显式动力有限元ANSYS/LS-DYNA，数值研究了缺陷（胞元缺失）的分布位置及其尺寸对金属蜂窝材料面内冲击性能的影响。考虑到理想六边形蜂窝材料在不同冲击速度下的变形特征，将试件划分成9个子区域，讨论了缺陷集中位置、缺陷尺寸和冲击速度对蜂窝材料面内冲击变形模式和能量吸收性能的影响。研究发现，蜂窝材料的面内冲击性能依赖于缺陷的分布位置和缺陷尺寸，且在中低速时表现出较高的敏感性，但冲击速度的增加将弱化缺陷分布不均匀性的影响。由于缺陷的存在，蜂窝材料的能量吸收能力明显降低，但与缺陷分布位置相比，蜂窝材料单位体积所吸收的能量更敏感于缺陷尺寸。研究结果将为多胞材料的安全性评估及能量吸收设计提供理论指导和依据。
- 蜂窝材料 /
- 胞元缺失 /
- 变形机制 /
- 能量吸收 /
- 冲击
Abstract: The influence of defects on the dynamic performance of honeycomb is widely studied, but it is mainly focused on the effect of defect type and defect ratio, and the influence of defect distribution has not yet been fully developed. Effect of defect (the cell missing) distribution domain and its size on the in-plane dynamic impact properties of metal honeycomb was numerically investigated in this work based on explicit dynamic finite element simulation by ANSYS/LS-DYNA. Considering the deformation characteristics of perfect hexagonal honeycomb at different impact velocities, the specimen was divided into nine different sub-domains. Then, the influence of defect location, the size of single defect and the impact velocities on in-plane deformation modes and the energy absorption abilities of honeycomb were explored in detail. Results show that the in-plane dynamic impact properties of honeycomb depend on defect location as well as defect size. The dependence displays higher sensitivity especially at intermediate and lower impact velocities. With the increase of the impact velocity, the influence of defect location is weakened. Due to the existence of local defects, the in-plane energy absorption ability of honeycomb decreases obviously. However, comparing with the defect distribution, the absorbed energy per volume of honeycomb displays a higher sensitivity on the single defect size. The results potentially provide theoretical guides for the safety evaluation and energy absorption design of cellular materials.
- honeycomb /
- the cell missing /
- deformation mechanism /
- energy absorption /
- impact

HTML全文

参考文献(15)

Gibson L J, Ashby M F. Cellular Solids: Structure and Properties [M]. Cambridge: Cambridge University Press, 1997: 87-148

Lu T J, He D P, Chen C Q, et al. The multi-functionality of ultra-light porous metals and their applications [J]. Advances in Mechanics, 2006, 36(4): 517-535. (in Chinese)

卢天健, 何德坪, 陈常青, 等. 超轻多孔金属材料的多功能特性及应用 [J]. 力学进展, 2006, 36(4): 517-535.

Chen C, Lu T J, Fleck N A. Effect of imperfections on the yielding of two-dimensional foams [J]. J Mech Phys Solids, 1999, 47(11): 2235-2272.

Silva M J, Gibson L J. The effects of non-periodic microstructure and defects on the compressive strength of the two-dimensional cellular solids [J]. Int J Mech Sci, 1997, 39(5): 549-563.

Guo X E, Gibson L J. Behavior of intact and damaged honeycombs: A finite element study [J]. Int J Mech Sci, 1999, 41(1): 85-105.

Wang A J, McDowell D L. Effects of defects on in-plane properties of periodic metal honeycombs [J]. Int J Mech Sci, 2003, 45(11): 1799-1813.

Li K, Gao X L, Subhash G. Effects of cell shape and cell wall thickness variations on the elastic properties of two-dimensional cellular solids [J]. Int J Solids Struct, 2005, 42(5-6): 1777-1795.

Ajdari A, Nayeb-Hashemi H, Canavan P, et al. Effect of defects on elastic-plastic behavior of cellular materials [J]. Mater Sci Eng A, 2008, 487(1-2): 558-567.

Zheng Z J, Yu J L, Li J R. Dynamic crushing of 2D cellular structures: A finite element study [J]. Int J Impact Eng, 2005, 32(1-4): 650-664.

Zhu H X, Thorpe S M, Windle A H. The effect of cell irregularity on the high strain compression of 2D voronoi honeycomb [J]. Int J Solids Struct, 2006, 43(5): 1061-1078.

Li K, Gao X L, Wang J. Dynamic crushing behavior of honeycomb structures with irregular cell shapes and non-uniform cell wall thickness [J]. Int J Solids Struct, 2007, 44(14-15): 5003-5026.

Nakamoto H, Adachi T, Araki W. In-plane impact behavior of honeycomb structures randomly filed with rigid inclusions [J]. Int J Impact Eng, 2009, 36(1): 73-80.

Nakamoto H, Adachi T, Araki W. In-plane impact behavior of honeycomb structures filled with linearly arranged inclusions [J]. Int J Impact Eng, 2009, 36(8): 1019-1026.

Ruan D, Lu G, Wang B, et al. In-plane dynamic crushing of honeycombs-A finite element study [J]. Int J Impact Eng, 2003, 28(2): 161-182.
