多点激光干涉测速系统和电探针技术在飞片速度测量中的应用对比

金山; 陈永涛; 汤铁钢; 彭其先; 蒙建华

doi:10.11858/gywlxb.2012.05.014

多点激光干涉测速系统和电探针技术在飞片速度测量中的应用对比

doi: 10.11858/gywlxb.2012.05.014

中国工程物理研究院流体物理研究所，四川绵阳 621900

详细信息

通讯作者:
金山 E-mail:jin9835@163.com

计量
- 文章访问数: 7503
- HTML全文浏览量: 295
- PDF下载量: 538
出版历程
- 收稿日期: 2010-12-28
- 修回日期: 2012-02-14
- 发布日期: 2012-10-15

Comparison of Multi-Channel VISAR and Electric Probe Technology in Measuring Free-Surface Velocity of Metal Flyer

Institute of Fluid Physics, CAEP, Mianyang 621900, China

摘要

摘要: 多点激光干涉测速系统和电探针技术均可用于测量高速运动物体的运动参数，为了相互验证测试结果，分析测试系统各因素对测量精度的影响，在平面爆轰波驱动飞片的实验中，利用多点激光干涉测速系统和多组电探针，同时测量金属飞片的自由面速度。将多点激光干涉测速系统测得的飞片速度-时间曲线进行积分，得到飞片的位移-时间曲线，并与电探针测得的飞片到达预定位置的时刻进行对比。结果表明：多点激光干涉测速系统各测点测得的飞片自由面速度随时间的变化曲线一致，各测点测得的速度最大相对偏差为1.45%；对两套测试系统的零时及信号传输时间进行修正后得到，当飞片飞行至5、10、15 mm位置时，电探针测得的飞片到达时刻与多点激光干涉测速系统测试结果的最大偏差值分别为0.02、0.02、0.07 s；两套系统在同一测点的测试差值随飞片飞行距离的增加而增加，其原因可能是，炸药透镜的波形差对飞片运动的影响随着飞片飞行距离的增加而增大。
- 激光干涉测速 /
- 电探针 /
- 爆轰
Abstract: Parameters of high speed object are often measured by multi-channel velocity interferometer system for any reflector (VISAR) or electric probe technology. In order to validate experimental results, and analyze test system factors affecting measurement precision, the free-surface velocity history of metal flyer driven by detonation was measured by multi-channel VISAR and electric probes. The displacement-time curve of metal flyer was calculated from the measured velocity-time curve, and then contrasted with the results measured by electric probes. Experimental results show that all v-t curves measured by multi-channel VISAR are coincident well within the maximum difference of 1.45%. And the maximum difference of time at 5, 10, 15 mm standoff measured by VISAR and electric probe is respectively 0.02, 0.02, 0.07 s after modified. The difference between two sets of system at the same position increases with the movement distance of flyer, it could be resulted from the increased waveform difference of the explosive lens with the flight distance of flyer.
- velocity interferometer system for any reflector (VISAR) /
- electric probe /
- detonation

HTML全文

参考文献(18)

Barker L M, Hollenbach R E. Laser interferometer for measuring high velocities of any reflecting surface [J]. Appl Phys, 1972, 43(11): 4669-4675.

Amery B T. Wide range velocity interferometer [A]//The Proceedings of the 6th Symposium on Detonation [C]. Arlington, VA: Office of Naval Research, 1976: 673-681.

Hemsing W F. Velocity sensing interferometer (VISAR) modification [J]. Rev Sci Instrum, 1979, 50(1): 73-78.

Sweatt W C, Stanton P L, Crump O B. Simplified VISAR system [A]//The Proceedings of SPIE 1346, Ultrahigh- and High-Speed Photography, Videography, Photonics, and Velocimetry [C]. San Diego, CA, 1990.

Peng Q X, Ma R C, Li Z R, et al. A high sensitivity VISAR with multireflection etalon [J]. Explosion and Shock Waves, 2002, 22(4): 343-346. (in Chinese)

彭其先, 马如超, 李泽仁, 等. 高灵敏度VISAR研究与设计 [J]. 爆炸与冲击, 2002, 22(4): 343-346.

Chen Y J, Yang Y Y, Zhuo Y M, et al. A construction of double-sensitivity VISAR [J]. Optical Instruments, 2006, 28(2): 71-75. (in Chinese)

陈阳杰, 杨甬英, 卓永模, 等. 双灵敏度VISAR测量的一种结构计 [J]. 光学仪器, 2006, 28(2): 71-75.

Peng X S, Wang F, Liu S Y, et al. Development of an imaging velocity interferometer system for any reflector [J]. Acta Optica Sinica, 2009, 29(11): 3207-3211. (in Chinese)

彭晓世, 王峰, 刘慎业, 等. 成像型任意反射面速度干涉仪研制 [J]. 光学学报, 2009, 29(11): 3207-3211.

Yan Y D, Zhang F Q, He J H, et al. Design of VISAR optical system for Shen-Guang-Ⅲ prototype [J]. Optics and Precision Engineering, 2010, 18(11): 2355-2361. (in Chinese)

闫亚东, 张法全, 何俊华, 等. 神光-Ⅲ原型装置用速度干涉仪的光学系统设计 [J]. 光学精密工程, 2010, 18(11): 2355-2361.

Wang J, Wen S G. Experimental study on deflagration-to-detonation transition in two pressed high-density explosives [J]. Chinese Journal of High Pressure Physics, 2009, 23(6): 441-446. (in Chinese)

王建, 文尚刚. 以HMX为基的两种压装高密度炸药的燃烧转爆轰实验研究 [J]. 高压物理学报, 2009, 23(6): 441-446.

Li X M, Jin X G, Li D H, et al. Elementary measurement of free surface velocity of cylindrical metal tube under inward detonation [J]. Acta Armamentarii, 2007, 28(10): 1252-1255. (in Chinese)

李雪梅, 金孝刚, 李大红, 等. 内聚爆轰加载下金属圆管的自由面速度测量初探 [J]. 兵工学报, 2007, 28(10): 1252-1255.

Ming P M, Zhu D, Hu Y Y, et al. Fabrication of nickel soft contact microprobe based on UV-LIGA [J]. Optics and Precision Engineering, 2007, 15(5): 735-740. (in Chinese)

明平美, 朱荻, 胡洋洋, 等. UV-LIGA技术制备微型柔性镍接触探针 [J]. 光学精密工程, 2007, 15(5): 735-740.
