切割式双模战斗部毁伤元成型及侵彻钢靶特性研究

纪冲; 龙源; 余道强; 周翔; 张洋溢

doi:10.11858/gywlxb.2012.05.005

切割式双模战斗部毁伤元成型及侵彻钢靶特性研究

doi: 10.11858/gywlxb.2012.05.005

纪冲^1,2, ,,
龙源¹,
余道强³,
周翔¹,
张洋溢⁴

1.
解放军理工大学，江苏南京 210007；
2.
北京理工大学爆炸科学与技术国家重点实验室，北京 100081；
3.
总装工程兵科研一所，江苏无锡 214035；
4.
广州军区工程科研设计所，广东广州 510515

详细信息

通讯作者:
纪冲 E-mail:blastingcaptain@163.com

计量
- 文章访问数: 7294
- HTML全文浏览量: 410
- PDF下载量: 517
出版历程
- 收稿日期: 2011-04-07
- 修回日期: 2011-09-19
- 发布日期: 2012-10-15

Experimental and Numerical Study on the Formation and Penetration Properties of Dual-Mode Warhead

1.
PLA University of Science and Technology, Nanjing 210007, China;
2.
State Key Laboratory of Explosion Science and Technology, Beijing Institute of Technology, Beijing 100081, China;
3.
The First Research Institute of the Corps of Engineers, Wuxi 214035, China;
4.
Engineering Research and Design Institute of Guangzhou Military Region, Guangzhou 510515, China

摘要

摘要: 基于60 mm弧锥结合罩爆炸成型弹丸（EFP）装药，设计了一种在药型罩前适当位置安装可抛掷的十字形网栅的切割式双模战斗部结构，其具有生成单个EFP或者多爆炸成型弹丸（MEFP）的功能；根据目标属性，可选择性地改变战斗部的毁伤元成型模式，实施最有效的打击。利用LS-DYNA程序，对两种模式毁伤元成型及侵彻45钢靶过程特性进行了数值模拟，模拟结果与地面静爆实验结果吻合较好。研究表明，该战斗部形成的单个EFP能贯穿25 mm厚45钢靶，可有效打击重装甲目标；经网栅切割后能形成5片具有一定质量和方向性、可贯穿6 mm厚45钢靶的EFP破片，显著提高了对轻装甲目标的毁伤概率。
- 双模式战斗部 /
- 切割网栅 /
- 侵彻 /
- 数值模拟
Abstract: We studied an optional/dual-mode warhead with an ejectable cross-shaped cutting reseau fixed at a proper place before the liner to realize multi-function of ammunition based on 60 mm arc-cone liner Explosive Formed Projectile (EFP) charge configuration. The optional/dual-mode warhead can change the kill elements mode according to the target properties (heavily or lightly armored targets), and can form single EFP or MEFP (Multiple Explosively Formed Projectile) to provide the most effective attack. The whole process of formation, flying and penetration of single EFP and MEFP was simulated using LS-DYNA3D. The simulation results are in good agreement with the experimental data. This study indicates that the single EFP has a good aerodynamic stability at a velocity of 1 508 m/s and it can penetrate through the 45 steel targets with a thickness of 30 mm; While the MEFP has a velocity between 1 500 and 1 750 m/s with an even distribution and can penetrate through the 45 steel targets with a thickness of 6 mm. The obtained results provide important reference to the design of dual-mode warhead.
- dual-mode warhead /
- cutting reseau /
- penetration /
- numerical simulation

HTML全文

参考文献(16)

Wang M, Huang D W, Luo R M. Experiment and numerical simulation of integral multi-explosively formed warhead [J]. Acta Armamentarii, 2010, 31(4): 453-457. (in Chinese)

王猛, 黄德武, 罗荣梅. 整体多枚爆炸成型弹丸战斗部试验研究及数值模拟 [J]. 兵工学报, 2010, 31(4): 453-457.

Zhou X, Long Y, Yu D Q, et al. Numerical simulation and effect analysis for radial dispersion of MEFP [J]. Acta Armamentarii, 2006, 27(1): 23-26. (in Chinese)

周翔, 龙源, 余道强, 等. 多弹头爆炸成型弹丸数值仿真及发散角影响因素 [J]. 兵工学报, 2006, 27(1): 23-26.

Fong R, Ng W. Multiple explosively formed penetrator (MEFP) warhead technology development [A]//19th International Symposium of Ballistics [C]. Interlaken, Switzerland: International Ballistics Committee, 2001: 563-568.

Bender D, Fong R, Ng W. Dual-mode warhead technology for future smart munitions [A]//19th International Symposium of Ballistics [C]. Interlaken, Switzerland: International Ballistics Committee, 2001: 679-684．

Yu D Q. Technical research on optional attack/multi-mode warhead [J]. Engineer Equipment Research, 2006, 25(4): 26-28. (in Chinese)

余道强. 可选择作用/多模战斗部技术研究 [J]. 工兵装备研究, 2006, 25(4): 26-28．

Cao B. Experimental study on EFP penetrating 45 steel plate [J]. Chinese Journal of Explosives Propellants, 2007, 30(3): 19-21. (in Chinese)

曹兵. EFP 对有限厚45碳钢板侵彻实验研究 [J]. 火炸药学报, 2007, 30(3): 19-21.

Zhou X. Technological researches on explosively formed projectiles [D]. Nanjing: PLA University of Science and Technology, 2006. (in Chinese)

周翔. 爆炸成型弹丸战斗部的相关技术研究 [D]. 南京: 解放军理工大学, 2006.

Johnson G R, Cook W H. Fracture characteristics of three metals subjected to various strains, strain rates, temperatures and pressures [J]. Eng Fract Mech, 1985, 21(1): 31-48．

Wu J, Liu J B, Du Y X. Experimental and numerical study on the flight and penetration properties of explosively-formed projectile [J]. Int J Impact Eng, 2007, 34: 1147-1162.

Zhang Y Y. Technological researches on multimode explosively formed projectiles warhead [D]. Nanjing: PLA University of Science and Technology, 2011. (in Chinese)

张洋溢. 多模爆炸成型弹丸战斗部关键技术研究 [D]. 南京: 解放军理工大学, 2011.
