超音速侵彻混凝土过程中装药安定性结构设计的动摩擦理论分析

张旭; 曹仁义; 谭多望

doi:10.11858/gywlxb.2012.01.009

超音速侵彻混凝土过程中装药安定性结构设计的动摩擦理论分析

doi: 10.11858/gywlxb.2012.01.009

中国工程物理研究院流体物理研究所冲击波物理与爆轰物理实验室，四川绵阳 621900

详细信息

通讯作者:
张旭 E-mail:caepzx@sohu.com

计量
- 文章访问数: 7539
- HTML全文浏览量: 291
- PDF下载量: 601
出版历程
- 收稿日期: 2010-06-09
- 修回日期: 2011-01-11
- 发布日期: 2012-02-15

A Dynamic Friction Analysis Method of Charge Survivability during Supersonic Penetration of Concrete Targets

National Key Laboratory of Shock Wave and Detonation Physics, Institute of Fluid Physics, CAEP, Mianyang 621900, China

摘要

摘要: 根据侵彻过程中弹体内部装药的弹性变形假设，利用弹体结构与内部装药的相对位移、摩擦功、热力学原理和热点理论，提出了装药热安定性设计的弹性理论分析方法。计算中，侵彻弹体的响应函数从空穴膨胀理论出发；利用弹塑性材料中应力波Hugoniot跳跃条件以及流体力学动量和质量守恒方程，分析了弹体侵彻混凝土过程中的弹体表面径向应力；结合牛顿第二定律，采用有限差分技术，获得了弹体侵彻过程的轴向阻力。通过弹性理论分析，得到了弹体侵彻过程中影响装药安定性的重要设计参数，为装药安定性设计提供了理论依据。
- 侵彻 /
- 装药安定性 /
- 动摩擦 /
- 最大装药长度
Abstract: Based on the assumption of elastic deformation of charge, a novel theoretical analysis method for charge survivability in the process of penetration is proposed by using relative displacement between projectile body and internal charge, friction work, hot spot theory, and principle of thermal dynamics. The resistance function during penetration is based upon the cavity expansion theory in the analysis. The radial stress on the projectile surface is obtained utilizing mass and momentum conservation equation and Hugoniot jump condition. In addition, the resistance forces in the supersonic penetration of concrete targets are calculated with finite difference method and Newton's Second Law. The important design parameters of charge affecting the charge survivability in the penetration are revealed from the elastic theoretical analysis, which provide a theoretical basis for the survivability design of housing explosive.
- penetration /
- charge stability /
- dynamic friction /
- maximum length of charge

HTML全文

参考文献(17)

Woolf A F. Conventional warheads for long-range ballistic missiles: Background and issues for congress [R]. USA: Congressional Research Service, 2007.

Bishop R F, Hill R, Mott N F. The theory of indentation and hardness tests [J]. Proc Phys Soc, 1945, 57(3): 147-159.

Hopkins H G. Dynamic expansion of spherical cavities in metals [A]//Sneddon I, Hill R. Progress in Solid Mechanics [C]. Oxford, UK: Pergamon Press, 1960, 84-164.

Tate A. A theory for the deceleration of long rods after impact [J]. J Mech Phys Solids, 1967, 15(6): 387-399.

Forrestal M J, Luk V K. Dynamic spherical cavity-expansion in a compressible elastic-plastic solid [J]. J Appl Mech, 1988, 55(2): 275-279.

Rosenberg Z, Marmor E, Mayseless M. On the hydrodynamic theory of long-rod penetration [J]. Int J Impact Eng, 1990, 10(1-4): 483-486.

Martineau R L, Prime M B, Duffey T. Penetration of HSLA-100 steel with tungsten carbide spheres at striking velocities between 0. 8 and 2. 5 km/s [J]. Int J Impact Eng, 2004, 30(5): 505-520.

Zhou N, Ren H Q, Shen Z W, et al. Experimental study on overload characteristics of projectile penetrating reinforced concrete [J]. Journal of Experimental Mechanics, 2006, 21(5): 572-578. (in Chinese)

周宁, 任辉启, 沈兆武, 等. 侵彻钢筋混凝土过程中弹丸过载特性的实验研究 [J]. 实验力学, 2006, 21(5): 572-578.

Zhou N, Ren H Q, Shen Z W, et al. Study on penetration of concrete targets by ogive-nose steel projectile [J]. Chinese Journal of High Pressure Physics, 2007, 21(3): 242-248. (in Chinese)

周宁, 任辉启, 沈兆武, 等. 卵形头部弹丸侵彻混凝土的研究 [J]. 高压物理学报, 2007, 21(3): 242-248.

Wang C H, Chen P Y, Xu X C. Filtering of penetration deceleration data and determining of penetration deceleration on the rigid-body [J]. Explosion and Shock Waves, 2007, 27(5): 416-419. (in Chinese)

王成华, 陈佩银, 徐孝诚. 侵彻过载实测数据的滤波及弹体侵彻刚体过载的确定 [J]. 爆炸与冲击, 2007, 27(5): 416-419.

Pi A G, Huang F L. Dynamic behavior of a slender projectile on oblique penetrating into concrete target [J]. Explosion and Shock Waves, 2007, 27(4): 331-337. (in Chinese)

皮爱国, 黄风雷. 大长细比弹体斜侵彻混凝土靶的动力学响应 [J]. 爆炸与冲击, 2007, 27(4): 331-337.

Song S C, Wang T H, Cai H N, et al. Numerical calculations of adiabatic shearing localization of steel projectile impacting concrete [J]. Explosion and Shock Waves, 2007, 27(3): 246-250. (in Chinese)

宋顺成, 王庭辉, 才鸿年, 等. 钢制弹丸冲击混凝土时绝热剪切局部化的数值计算 [J]. 爆炸与冲击, 2007, 27(3): 246-250.
