高压下尼龙1010-单壁碳纳米管复合材料的结晶行为

王彪; 郑友进; 贾晓鹏; 马红安; 张学全

doi:10.11858/gywlxb.2012.01.005

高压下尼龙1010-单壁碳纳米管复合材料的结晶行为

doi: 10.11858/gywlxb.2012.01.005

1.
天津科技大学材料科学与化学工程学院，天津 300457；
2.
吉林大学超硬材料国家重点实验室，吉林长春 130012；
3.
中国科学院长春应用化学研究所，吉林长春 130022

详细信息

通讯作者:
王彪 E-mail:wb22@tust.edu.cn

计量
- 文章访问数: 7351
- HTML全文浏览量: 341
- PDF下载量: 589
出版历程
- 收稿日期: 2010-04-23
- 修回日期: 2010-09-01
- 发布日期: 2012-02-15

Crystallization Behavior of Polyamide 1010-Single-Walled Carbon Nanotube Nanocomposites under High Pressure

1.
College of Material Science and Chemical Engineering, Tianjin University of Science and Technology, Tianjin 300457, China;
2.
National Laboratory of Superhard Materials, Jilin University, Changchun 130012, China;
3.
Changchun Institute of Applied Chemistry, Chinese Academy of Science, Changchun 130022, China

摘要

摘要: 采用XKY-61200MN型六面顶压机，在不同温度、压力条件下处理30 min后制备了尼龙1010(PA1010)-单壁碳纳米管（SWCNT）复合材料的高压结晶样品，通过X射线衍射（XRD）、差热分析仪（DSC）、扫描电子显微镜（SEM）、透射电子显微镜（TEM），研究了高压处理样品的结晶行为、结构变化及形貌特征。结果表明：在1.0~2.5 GPa压力下，属于高压熔体结晶；在3.0和4.5 GPa压力下属于高压退火处理；高压结晶或高压退火均有助于聚合物片层晶体的增厚，并且高压熔体结晶的增厚效果优于高压退火处理。XRD结果表明，PA1010的三斜晶型在高压处理后保持不变，高压熔体结晶或高压退火都可以使(100)晶面和(010)晶面间距减小，即高压处理致使聚合物分子链紧密堆积。DSC结果表明：在高压熔体结晶过程中，升高压力和温度可以得到片层厚度较大的PA1010晶体；在2.0 GPa、350 ℃下获得的高压结晶样品的熔点和结晶度最高，分别达到208.5 ℃和64.6%。SEM和TEM结果表明：与常压结晶样品相比，高压结晶样品内部出现c轴厚度超过150 m的大尺寸晶体；SWCNT与PA1010基体之间形成相互穿插的网络结构，刚性的SWCNT作为高压成核剂促进PA1010晶体生长和增厚。
- 高压结晶 /
- 晶体增厚 /
- 尼龙1010 /
- 单壁碳纳米管
Abstract: The PA1010 (polyamide 1010)-SWCNT (single-walled carbon nanotube) nanocomposites crystallized at different temperatures and pressures for 30 min are prepared by an XKY-61200MN type high-pressure apparatus. The structure, crystallization behavior and morphological feature of high-pressure crystallized samples are studied by XRD (X-ray diffraction), DSC (differential scanning calorimetry), SEM (scanning electron microscope) and TEM (transmission electron microscope). The results show that high-pressure melt crystallization occurs in the pressure range of 1.0-2.5 GPa, while high-pressure annealing occurs in 3.0 and 4.5 GPa. Both melt crystallization and annealing under high pressure contribute to the thickening of polymer lamellar crystals, and moreover, the effect of high pressure melt crystallization is superior to that of high-pressure annealing. XRD results show that the triclinic form of PA1010 remains unchanged after high-pressure treatment, and both melt crystallization and annealing under high pressure can decrease (100) and (010) crystal plane spacing, and namely the high-pressure treatment results in close packing of polymer molecular chains. DSC results show that elevating the pressure and temperature during melt crystallization under high pressure can lead to the formation of crystals with larger lamella thickness, and the highest value of melting point and crystallinity obtained in the sample crystallized at 2.0 GPa and 350 ℃ are 208.5 ℃ and 64.6%, respectively. The large-sized crystals with c axis thickness exceeding 150 m are detected by SEM and TEM in the sample crystallized at high pressure. The interpenetrating network structure between the SWCNT and PA1010 matrix is formed, and the rigid SWCNT as high pressure nucleating agent can promote growth and thickening of PA1010 crystals under high pressure.
- high pressure crystallization /
- crystal thickening /
- polyamide 1010 /
- single-walled carbon nanotube

HTML全文

参考文献(22)

Maeda Y, Kanetsuna H. Crystallization and melting of polyethylene under high pressure. Ⅰ. Crystallization by slow cooling from the melt [J]. J Polym Sci B, 1974, 12(12): 2551-2565.

Rees D V, Bassett D C. Origin of extended-chain lamellae in polyethylene [J]. Nature, 1968, 219(5152): 368-370.

Gogolewski S. A possible mechanism of chain extension in nylon-6 during crystallization under pressure [J]. Polymer, 1977, 18(1): 63-68.

Gogolewski S, Pennings A J. Crystallization of polyamides under elevated pressure: 5. Pressure-induced crystallization from the melt and annealing of folded-chain crystals of nylon-11, poly (aminoundecaneamide) under pressure [J]. Polymer, 1977, 18(7): 660-666.

Stamhuis J E, Pennings A J. Crystallization of polyamides under elevated pressure: 6. Pressure-induced crystallization from the melt and annealing of folded-chain crystals of nylon-12, polylaurolactam under pressure [J]. Polymer, 1977, 18(7): 667-674.

Li L B, Li P, Hong S M. Sintering polymer nano-crystals at high pressure [J]. J Mater Sci Lett, 2001, 120(9): 807-809.

Lu J, Huang R, Li L B, et al. Growth of large polymer extended-chain single crystals in a poly (ethylene terephthalate)/bisphenol a polycarbonate blend under high pressure [J]. Macromol Rapid Commun, 2005, 26(18): 1478-1482.

Miyamoto Y, Nakafuku C, Takemura T. Crystallization of polychlorotrifluoroethylene [J]. Polym J, 1972, 3: 122-128.

Hattori T, Hikosaka M, Ohigashi H. The crystallization behaviour and phase diagram of extended-chain crystals of poly (vinylidene fluoride) under high pressure [J]. Polymer, 1996, 37(1): 85-91.

Price F P. The Meaning of Crystallinity in Polymers [M]. New York: Interscience, 1967: 33-50.

Wang B, Sun G P, Liu J J, et al. Crystallization behavior of carbon nanotubes-filled polyamide 1010 [J]. J Appl Polym Sci, 2006, 100(5): 3794-3800.

Yang J, Liu S, Guo X, et al. Annealing of nylon-1010 under high pressure [J]. Macromol Chem Phys, 2002, 203(8): 1081-1087.

Maeda Y, Kanetsuna H. Crystallization and melting of polyethylene under high pressure. Ⅲ. Mixed crystallization of two kinds of extended-chain crystals [J]. J Polym Sci B, 1976, 14(11): 2057-2072.

Zhang W, Kiran E. High-pressure crystallization and melting of polyethylene in n-pentane [J]. J Supercrit Fluids, 2006, 38(3): 406-419.

Balta Calleja F J, Bassett D C, Keller A. A study of X-ray long periods produced by annealing polyethylene crystals [J]. Polymer, 1963, 4: 269-279.

Geil P H, Anderson F R, Wunderlich B, et al. Morphology of polyethylene crystallized from the melt under pressure [J]. J Polym Sci A, 1964, 2(8): 3707-3720.

Gruner C L, Wunderlich B, Bopp R C. Extended-chain crystals. Ⅵ. Annealing of polyethylene under elevated pressure [J]. J Polym Sci A, 1969, 7(12): 2099-2113.

Gogolewski S, Pennings A J. Crystallization of polyamides under elevated pressure: 4. Annealing of nylon-6 (polycapramide) under pressure [J]. Polymer, 1977, 18(7): 654-659.

L J, Wang X L, Huang R, et al. Effect of transesterification on high-pressure crystallization behaviour of PET/PC blend system [J]. Chemical Journal of Chinese Universities, 2005, 26(8): 1556-1560. (in Chinese)

吕军, 王选伦, 黄锐, 等. PET/PC共混体系的酯交换反应对其高压结晶行为的影响 [J]. 高等学校化学学报, 2005, 26(8): 1556-1560.

L J, Wei G, Huang R, et al. Observation of novel spherulitic morphology formed in extended-chain crystals in high-pressure crystallized PET/PC blends [J]. Chemical Journal of Chinese Universities, 2005, 26(12): 2391-2393. (in Chinese)

吕军, 魏刚, 黄锐, 等. 高压结晶PET/PC共混体系中生长在伸直链晶体内部球晶形态的观察 [J]. 高等学校化学学报, 2005, 26(12): 2391-2393.
