导弹动爆对模拟船舱毁伤效果试验研究

杜红棉; 王燕; 祖静; 徐鹏; 马游春

doi:10.11858/gywlxb.2011.03.011

导弹动爆对模拟船舱毁伤效果试验研究

doi: 10.11858/gywlxb.2011.03.011

杜红棉^1,2,
王燕^1,2,
祖静^1,2,
徐鹏^1,2,
马游春^1,2,3,

1.
中北大学电子测试技术重点实验室，山西太原 030051；
2.
中北大学仪器科学与动态测试教育部重点实验室，山西太原 030051；
3.
北京航空航天大学光电技术研究所，北京 100191

详细信息

通讯作者:
马游春

计量
- 文章访问数: 7373
- HTML全文浏览量: 355
- PDF下载量: 652
出版历程
- 收稿日期: 2010-07-20
- 修回日期: 2010-11-29
- 发布日期: 2011-06-15

Experimental Study on Damage Effect of Simulated Ship Cabin Subjected to Missile Dynamic Explosion

DU Hong-Mian^1,2,
WANG Yan^1,2,
ZU Jing^1,2,
XU Peng^1,2,
MA You-Chun^{1,2,3
,}

1.
National Key Laboratory for Electronic Measurement Technology, North University of China, Taiyuan 030051, China;
2.
Science and Technology on Electronic Test & Measurement Laboratory, North University of China, Taiyuan 030051, China;
3.
Institute of Opt-electronics, Beihang University, Beijing 100191, China

More Information

Corresponding author: MA You-Chun

摘要

摘要: 设计了基于火箭橇的导弹动爆试验，介绍了模拟船舱的结构尺寸、测试点的布设情况及测试仪器性能。通过获取的断线、光、压力、加速度信号得出如下结论：测试方法有效；冲击波在舱室内传播不均匀，导弹运动方向反射冲击波很大，反方向较小，两者比例可达3.5∶1，舱室的角隅部位冲击波压力高于壁面正反射压力；导弹穿甲时舱壁的冲击振动高达10 000 g，且穿甲舱壁的冲击远大于其它舱壁，被破片击中会加大舱壁的振动幅值。
- 火箭橇 /
- 动爆 /
- 模拟船舱 /
- 冲击波 /
- 冲击振动
Abstract: An experiment of missile dynamic explosion carried by rocket sled was performed. The structure size of simulated cabin, layout of testing points and properties of used instruments were introduced. According to broken lines, acquired light, pressure and acceleration signals, three conclusions were made as follows: First, the designed testing method is effective; Second, the transmission of shock wave in cabin is uneven, while the reflection shock wave on the missile moving direction is about 3.5 times of the other side; The shock wave pressure on the cube corner of cabin is higher than normal reflection pressure on the wall; Finally, the impact vibration on the penetrating bulkhead is about 10 000 g, which is much higher than other points; The vibration amplitude of bulkhead will increases as hit by shell fragments.
- rocket sled /
- dynamic explosion /
- simulated cabin /
- shock wave /
- impact vibration

HTML全文

参考文献(23)

Zhang G Y, Zhou X, Huang Y Z, et al. Study of Analysis Method of the Shock-Wave Characteristic of Moving Explosive [A]//CSTM. The 4th National Symposium on Computable Explosion Force [C]. Hefei, 1990: 282-287. (in Chinese)

张光莹, 周旭, 黄咏政, 等. 动爆冲击波特性分析方法研究 [A]//中国力学学会. 第四届全国计算爆炸力学会议论文集 [C]. 合肥, 1990: 282-287.

Zhu W L, Huang X M, Dong S Q. Numerical Simulation of Damage Effect for Explosion in Building [J]. Journal of Projectiles Rockets Missiles and Guidance [J]. 2009, 29(5): 139-141. (in Chinese)

余文力, 黄显明, 董三强. 建筑物内爆炸毁伤效应的数值模拟 [J]. 弹箭与制导学报, 2009, 29(5): 139-141.

Zhu J F, Wang W L, Zeng L. Modeling and Simulation of Damage Effect of Ship Cabin Subject to Internal Explosion [J]. Journal of System Simulation, 2009, 21(22): 7066-7068. (in Chinese)

朱建方, 王伟力, 曾亮. 舰艇舱室内爆毁伤的建模与仿真分析 [J]. 系统仿真学报, 2009, 21(22): 7066-7068.

Jia X Z, Hu Y T, Dong M R, et al. Numerical Study on Influencing Factors of Dynamic Response of Cylindrical Shell Subjected to Deep Water Blast Wave [J]. Chinese Journal of High Pressure Physic, 2008, 22(2): 208-214. (in Chinese)

贾宪振, 胡毅亭, 董明荣, 等. 深水爆炸冲击波作用下圆柱壳动态响应影响因素的数值模拟研究 [J]. 高压物理学报, 2008, 22(2): 208-214.

Hou H L, Zhu X, Mei Z Y. Study on the Blast Load and Failure Mode of Ship Structure Subject to Internal Explosion [J]. Explosion and Shock Waves, 2007, 27(2): 151-158. (in Chinese)

侯海量, 朱锡, 梅志远. 舱内爆炸载荷及舱室板架结构的失效模式分析 [J]. 爆炸与冲击, 2007, 27(2): 151-158.

Gong M. Research on Dynamic Characteristics and Damage Effect of Multi-Layer Frame Structure under Blasting Shock [D]. Wuhan: Wuhan University of Technology, 2007. (in Chinese)

龚敏. 爆炸冲击作用下多层框架结构的动力特性与毁伤效应研究 [D]. 武汉: 武汉理工大学, 2007.

Yuen S C K, Nurick G N. Experimental and Numerical Studies on the Response of Quadrangular Stiffened Plates(Part Ⅰ): Subjected to Uniform Blast Load [J]. Int J Impact Eng, 2005, 31: 55-83.

Zhang Y, Xiong J J, Jiao X Q. Research on Measurement Technology of Ship Damage Effect Attacked by Missile [D]. Taiyuan: North University of China, 2008. (in Chinese)

张燕, 熊继军, 焦新泉. 导弹攻击舰船毁伤效果测试技术研究 [D]. 太原: 中北大学, 2008.

Fuze Design Drafting Group. Fuze Design Manual [M]. Beijing: National Defense Press, 1978: 53-326. (in Chinese)

引信设计手册编写组. 引信设计手册 [M]. 北京: 国防工业出版社, 1978: 53-326.

Sun Y B. Explosion Function and Charge Design [M]. Beijing: National Defense Press, 1987: 217-218. (in Chinese)

孙业斌. 爆炸作用与装药设计 [M]. 北京: 国防工业出版社, 1987: 217-218.

Huang S F, Zhana Z A. GJB 763. 4-89 Limits and Methods of Ship Noise and Vibration Acceleration Measurement of Ship Equipment [S]. Beijing: Commission on Science, Technology, and Industry for National Defense, 1989. (in Chinese)

黄书富, 张增安. GJB 763. 4-89 舰船噪声限值和测量方法舰船设备结构振动加速度测量 [S]. 北京: 国防科学技术工业委员会, 1989.

Ma J Z, Zhu X M, Jiang Y, et al. GJB 4058-2000 Ship Equipment Noise and Vibration Measurement [S]. Beijing: Commission on Science, Technology, and Industry for National Defense, 2000. (in Chinese)

马建忠, 朱显明, 蒋宜, 等. GJB 4058-2000 舰船设备噪声、振动测量方法 [S]. 北京: 国防科学技术工业委员会, 2000.
