炸药枪击试验和数值模拟研究

伍俊英; 汪德武; 陈朗; 王树山; 韩秀凤

doi:10.11858/gywlxb.2010.06.001

炸药枪击试验和数值模拟研究

doi: 10.11858/gywlxb.2010.06.001

1.
北京理工大学爆炸科学与技术国家重点实验室，北京 100081；
2.
第二炮兵装备研究院，北京 100085

详细信息

通讯作者:
伍俊英

计量
- 文章访问数: 8828
- HTML全文浏览量: 537
- PDF下载量: 891
出版历程
- 收稿日期: 2010-03-16
- 修回日期: 2010-08-30
- 发布日期: 2010-12-15

Experiments and Numerical Simulations of Bullet Impact Tests for Explosives with Shell

1.
State Key Laboratory of Explosion Science and Technology, Beijing 100081, China;
2.
The Second Artillery Equipment Academy, Beijing 100085, China

More Information

Corresponding author: WU Jun-Ying

摘要

摘要: HL-10炸药是一种以RDX为基的含铝炸药，为了研究该炸药在子弹或金属破片撞击作用下的安全性，利用12.7 mm机枪法对钢壳包覆的柱形HL-10装药进行了枪击试验，试验结果表明，炸药没有发生燃烧或爆轰现象，由此可定义该炸药的枪击感度试验反应等级为1级。建立了炸药枪击试验的计算模型和数值计算方法，对子弹撞击和穿透炸药过程进行了三维数值模拟计算，计算结果与试验结果相符，分析了子弹速度对HL-10炸药枪击感度的影响，其结果可为炸药安全性评价分析提供理论根据。为了进一步验证计算模型和方法，对美国的PBX-9404炸药的枪击作用过程进行了计算分析，结果表明，PBX-9404炸药在枪击作用下发生了完全爆轰反应，与Neff等人的试验结果相吻合。
- 枪击试验 /
- 炸药 /
- 爆轰 /
- 数值模拟
Abstract: HL-10 explosive is an aluminized explosive based on RDX. In order to investigate the safety characteristics of HL-10 for bullet impact test, 12.7 mm bullet was used to impact HL-10 charge. Experimental results show that there is no significant reaction or burning resulted from these bullet impact tests, so the impact sensitive of HL-10 for bullet impact test is defined as the first grade. The calculation modes and methods of bullet impact tests were established. The three-dimensional numerical simulations of the bullet impact tests were conducted. Good agreement was found between the calculated results and the experimental results. In addition, the responses of HL-10 to different bullet impact velocities were analyzed. The calculated results can provide a theoretical basis for the analysis of explosives safety evaluation. To further verify the calculation model and method, the bullet impact test calculation for America PBX-9404 explosive was conducted. The results show that, PBX-9404 explosives would be detonated at 850 m/s impact velocity for the same calculation mode, which are consistent with Neff and others experimental results.
- bullet impact test /
- explosives /
- detonation /
- numerical simulation

HTML全文

参考文献(18)

Zhang G R, Chen D N. Agglomerate Explosive Initiation Physics [M]. Beijing: National Defense Industry Press, 1991: 258-259. (in Chinese)

章冠人, 陈大年. 凝聚炸药起爆动力学 [M]. 北京: 国防工业出版社, 1991, 258-259.

Corley J D, Stewart A. Fuzed Insensitive General Purpose Bomb Containing AFX-645-Final Report [R]. WL-TR-95-7019, 1995: 9-14.

Kimura E, Oyumi Y. Sensitivities of Azide Polymer Propellants in Fast Cook-off, Card Gap and Bullet Impact Tests [J]. J Energetic Mater, 1997, 15(2-3): 162-178.

Dagley I J, Sook-Ying H, Viector N. Effects of the Polymer Matrix Density on the Shock, Bullet Impact and High Strain-Rate Ignition Sensitivity of Polymer Bonded Explosives [J]. Propellants, Explosives, Pyrotechnics, 1997, 22: 296-300.

Li X Z, Pei Y W. Low Volnerability Experimental Study of Solid Rocket Engine under Popping Condition [J]. Journal of Projectiles Rockets Missiles and Guidance, 2000, 2: 39-42. (in Chinese)

李小柱, 裴养卫. 固体火简发动机枪击低易损性试验研究 [J]. 弹箭与制导学报, 2000, 2: 39-42.

Cliff M D, Smith M W. Insensitive Munitions Assessment of the 5/54 Naval Artillery Shell Filled With ARX 4024 [R]. DSTO-TR-1514, 2003: 9-11.

Department of Defense. Test Method Standard, Hazard Assessment Tests for Non-Nuclear Munitions [S]. MIL-STD-2105C, 2003.

Jones D A, Kemister G, Borg R A J. Numerical Simulation of Detonation in Condensed Phase Explosives [R]. AR-010-605, DSTO-TR-0705, 1999.

Dai X G, Shen C Y, L Z J, et al. Reaction Properties for Different Size PBX-2 Explosives in Bullet Impact Test [J]. Energetic Materials, 2008, 16(4): 432-435. (in Chinese)

代晓淦, 申春迎, 吕子剑, 等. 枪击试验中不同尺寸PBX-2炸药响应规律研究 [J]. 含能材料, 2008, 16(4): 432-435.

LS-DYNA Users' Manual. Nonlinear Dynamic Analysis of Structures in Three Dimensions [Z]. University of California, Lawrence Livermore National Laboratory, Version 971, 2007.

Bullet Manual Writing Group. Bullet Manual [Z]. Beijing: National Defense Industry Press, 1988: 12. (in Chinese)

枪弹手册编写组. 枪弹手册 [Z]. 北京: 国防工业出版社, 1988: 12.

Wu J Y, Wang C, Chen L, et al. Numerical Simulations of Sympathetic Detonation for Confined Explosive Charges [A]// Li S C, Wang Y J, Cao F X, et al. Theory and Practice of Energetic Material [C]. Beijing: Science Press, 2009, (Ⅷ): 542-547.

Neff G W. Rifle Bullet Test (MHSMP-72-28S) [R]. Amarillo, Texas: Mason and Hanger-Silas Mason Co, 1971: 4.

Neff G W. Rifle Bullet Test (MHSMP755Q) [R]. Amarillo, Texas: Mason and Hanger-Silas Mason Co, 1974: 16.
