Dynamic Behavior of Void Growth in Aluminum with a Preexisting Flaw under Intense Impact Loading
-
摘要: 采用LS-DYNA瞬态动力学有限元程序,对平板撞击加载下含初始杂质的纯铝样品中微孔洞的成核与长大进行了数值模拟。结果表明:微孔洞首先在杂质与基体的边界处成核,随后在局部严重塑性变形驱动下快速线性增长;微孔洞半径的增长速率与冲击加载强度两者之间近似成线性关系;材料屈服强度和初始杂质的大小对微孔洞相对的增长速率有明显的影响;当微孔洞长大阈值取屈服强度的3.5倍时,数值仿真结果与理论分析结果基本一致,这有助于进一步认识孔洞长大的动力学行为。Abstract: By means of the explicit nonlinear dynamic finite element computer code LS-DYNA, the nucleation and growth of void in aluminum with a preexisting flaw under plate impact loading have been investigated. The results are as follows: firstly, the void nucleation occurs from the boundary of the preexisting flaw and the ductile matrix, and once the voids have been nucleated, they grow linearly through the localized plastic deformation; secondly, the growth rate of void radius increases linearly with the shock loading amplitude; thirdly, the yield strength and the size of the preexisting flaw have an obvious influence on the relative growth rate of void; finally, if the threshold stress of the void growth is set as 3.5 times of the yield strength, the simulation results agree reasonably well with the theoretical results, which is helpful for the further understanding of the void growth dynamic behavior.
-
Key words:
- solid mechanics /
- void growth /
- plate impact /
- aluminium
-
Curran D R, Seaman L, Shockey D A. Dynamic Failure of Solids [J]. Phys Rep, 1987, 147(5-6): 253-388. Seaman L, Curran D R, Shockey D A. Computational Models for Ductile and Brittle Fracture [J]. J Appl Phys, 1976, 47(11): 4814-4824. Ortiz M, Molinari A. Effect of Strain Hardening and Rate Sensitivity on the Dynamic Growth of a Void in a Plastic Material [J]. J Appl Mech, 1992, 59(1): 48-53. Thomason P F. Ductile Spallation Fracture and the Mechanics of Void Growth and Coalescence under Shock-Loading Conditions [J]. Acta Mater, 1999, 47(13): 3633-3646. Wu X Y, Ramesh K T, Wright T W. The Dynamic Growth of a Single Void in a Viscoplastic Material under Transient Hydrostatic Loading [J]. J Mech Phys Solids, 2003, 51(1): 1-26. Tszeng T C. Quasistatic and Dynamic Growth of Sub-Microscale Spherical Voids [J]. Mech Mater, 2009, 41(5): 584-598. Horstemeyer M F, Matalanis M M, Sieber A M, et al. Micromechanical Finite Element Calculations of Temperature and Void Configuration Effects on Void Growth and Coalescence [J]. Int J Plast, 2000, 16(7-8): 979-1015. Bandstra J P, Koss D A. Modeling the Ductile Fracture Process of Void Coalescence by Void-Sheet Formation [J]. Mater Sci Eng A, 2001, 319-321: 490-495. Seppala E T, Belak J, Rudd R E. Effect of Stress Triaxiality on Void Growth in Dynamic Fracture of Metals: A Molecular Dynamics Study [J]. Phys Rev B, 2004, 69: 134101. Seppala E T, Belak J, Rudd R E. Onset of Void Coalescence during Dynamic Fracture of Ductile Metals [J]. Phys Rev Lett, 2004, 93: 245503. Luo J, Zhu W J, Lin L B, et al. Molecular Dynamics Simulation of Void Growth in Single Crystal Copper under Uniaxial Impacting [J]. Acta Physica Sinica, 2005, 54(6): 2791-2798. (in Chinese) 罗晋, 祝文军, 林理彬, 等. 单晶铜在动态加载下空洞增长的分子动力学研究 [J]. 物理学报, 2005, 54(6): 2791-2798. Deng X L, Zhu W J, He H L, et al. Plasticity Mechanism Associated with Nano-Void Growth under Impact Loading along 〈111〉 Direction in Copper [J]. Chinese Journal of High Pressure Physics, 2007, 21(1): 59-65. (in Chinese) 邓小良, 祝文军, 贺红亮, 等. 沿〈111〉晶向冲击加载下铜中纳米孔洞增长的塑性机制研究 [J]. 高压物理学报, 2007, 21(1): 59-65. Deng X L, Zhu W J, He H L, et al. Initial Dynamic Behavior of Nano-Void Growth in Single-Crystal Copper under Shock Loading along 〈111〉 Direction [J]. Acta Physica Sinica, 2006, 55(9): 4767-4773. (in Chinese) 邓小良, 祝文军, 贺红亮, 等. 〈111〉晶向冲击加载下单晶铜中纳米孔洞增长的早期动力学行为 [J]. 物理学报, 2006, 55(9): 4767-4773. Tollier L, Fabbro R, Bartnicki E. Study of the Laser-Driven Spallation Process by the Velocity Interferometer System for Any Reflector Interferometry Technique. Ⅰ. Laser-Shock Characterization [J]. J Appl Phys, 1998, 83(3): 1224-1230. Cui X L, Li Y J, Zhu W J, et al. Micro-Analysis of the Void Growth of Aluminum under Shock Loading [J]. Chinese Journal of High Pressure Physics, 2009, 23(1): 37-41. (in Chinese) 崔新林, 李英俊, 祝文军, 等. 冲击加载下铝中孔洞长大的微观机理分析 [J]. 高压物理学报, 2009, 23(1): 37-41.
