Experimental Study on the Membraneless Heavy Gas Cylinder and Gas Curtain Interfaces Impacted by a Weak Shock Wave
-
摘要: 研制了一个改进的激波管设备,对马赫数为1.2的弱激波冲击作用下空气中SF6气柱和气帘界面的演变过程进行了初步的实验研究。通过设计激波管实验段、烟雾发生器、气体箱、进气吸气系统和激波管尾段,控制混合气体中SF6的峰值浓度和初始气流速度,建立了稳定、可重复的无膜气柱和气帘初始界面形成技术。利用高速摄影技术,在水平面内观测了气柱和气帘的初始界面图像,沿垂直方向观测了界面RM(Richtmyer-Meshkov)不稳定性的演变过程。气柱演变图像显示了典型的对涡结构,气帘演变图像显示了早期的多蘑菇形结构和后期的相邻波长干扰效应。图像后处理表明,气柱的高度和宽度、气帘的宽度均随时间单调增加,且宽度比高度增加快得多。从二维涡量动力学方程出发,对图像中涡的演变过程进行了初步解释。Abstract: A modified shock tube apparatus has been developed in order to experimentally investigate the evolution process of a sulfur hexafluoride gas cylinder and gas curtain surrounded by air when impacted by a shock wave with a Mach number of 1.2. By designing the test section, the fog generator, the gas chamber, the suction system and the end section, and controlling the sulfur hexafluoride peak concentration in the mixing gas and the initial vertical flow velocity, we developed a steady and repeatable technique to generate gas cylinder and gas curtain interfaces. Using high-speed camera, the initial interface images in the horizontal plane are obtained, and the developing photographs of dynamic Richtmyer-Meshkov (RM) instability in the vertical direction are also recorded. The gas cylinder evolution photographs exhibit typical vortex pair structure, and the gas curtain evolution images show multi-mushroom structure in the early stage and interfering with neighboring wavelength in the later stage. The height and width of the gas cylinder and the width of the gas curtain increase monotonically with time. Moreover the width increases faster than the height. The evolution mechanism of vortex is explained preliminarily, using two-dimensional vorticity dynamic equation.
-
Key words:
- membraneless interface /
- gas cylinder /
- gas curtain /
- RM instability /
- high-speed photography /
- shock tube
-
Richtmyer R D. Taylor Instability in Shock Acceleration of Compressible Fluids [J]. Commun Pur Appl Math, 1960, 13(2): 297-319. Meshkov E E. Instability of the Interface of Two Gases Accelerated by a Shock Wave [J]. Fluid Dyn, 1969, 4(5): 101-104. Lindl J D, McCrory R L, Campbell E. Progress toward Ignition and Burn Propagation in Inertial Confinement Fusion [J]. Phys Today, 1992, 45(9): 32-40. Yang J, Kubota T, Zukowski E E. Applications of Shock-Induced Mixing to Supersonic Combustion [J]. AIAA J, 1993, 31(5): 854-862. Brouillette M. The Richtmyer-Meshkov Instability [J]. Annu Rev Fluid Mech, 2002, 34: 445-468. Zabusky N J. Vortex Paradigm for Accelerated Inhomogeneous Flows: Visiometrics for the Rayleigh-Taylor and Richtmyer-Meshkov Environments [J]. Annu Rev Fluid Mech, 1999, 31: 495-536. Dimotakis P E. Turbulent Mixing [J]. Annu Rev Fluid Mech, 2005, 37: 329-356. Kumar S, Hornung H G, Sturtevant B. Growth of Shocked Gaseous Interfaces in a Conical Geometry [J]. Phys Fluids, 2003, 15(10): 3194-3208. Ranjan D, Niederhaus J H J, Oakley J G, et al. Shock-Bubble Interactions: Features of Divergent Shock-Refraction Geometry Observed in Experiments and Simulations [J]. Phys Fluids, 2008, 20(3): 036101. Hosseini S H, Takayama K. Experimental Study of Richtmyer-Meshkov Instability Induced by Cylindrical Shock Waves [J]. Phys Fluids, 2005, 17(8): 084101. Fontaine G, Mariani C, Martinez S, et al. An Attempt to Reduce the Membrane Effects in Richtmyer-Meshkov Instability Shock Tube Experiments [J]. Shock Waves, 2009: 19(4): 285-289. Erez L, Sadot O, Oron D, et al. Study of the Membrane Effect on Turbulent Mixing Measurements in Shock Tubes [J]. Shock Waves, 2000, 10(4): 241-251. Jacobs J W, Klein D L, Jenkins D G, et al. Instability Growth Patterns of a Shock-Accelerated Thin Fluid Layer [J]. Phys Rev Lett, 1993, 70(5): 583-586. Tomkins C, Kumar S, Orlicz G, et al. An Experimental Investigation of Mixing Mechanisms in Shock-Accelerated Flow [J]. J Fluid Mech, 2008, 611: 131-150. Orlicz G C, Balakumar B J, Tomkins C D, et al. A Mach Number Study of the Richtmyer-Meshkov Instability in a Varicose, Heavy-Gas Curtain [J]. Phys Fluids, 2009, 21(6): 064102. Huang J, Jia H Y, Luo X S, et al. Study on the Richtmyer-Meshkov Instability of Spherical Interface in Shock Tube [J]. Journal of Experiments in Fluid Mechanics. (in Chinese, to be published) 黄甲, 贾洪印, 罗喜胜, 等. 球形界面Richtmyer-Meshkov不稳定性的激波管研究 [J]. 实验流体力学. (待发表) Guo W C, Liu C L, Tan D W, et al. Experimental Investigation on Spherical Bubble Evolution Loaded by a Weak Planar Shock Wave [J]. Chinese Journal of High Pressure Physics, 2009, 23(6): 460-466. (in Chinese) 郭文灿, 刘仓理, 谭多望, 等. 平面弱激波加载下球形气泡演化的实验研究 [J]. 高压物理学报, 2009, 23(6): 460-466. Fishbine B. Code Validation Experiments-A Key to Predictive Science [J/OL]. Los Alamos Research Quarterly, 2002: 6-14.
