摘要: 在高温高压条件下,用hBN-LiH和hBN-Li3N-B为初始材料均可以合成出黑色cBN晶体。拉曼光谱测试结果表明,cBN晶体颜色变黑的原因是晶体中多余B原子的存在造成的。在hBN-Li3N-B体系中,晶体内部有明显的三角形阴影形成,表明从晶体表面的中心到顶角间B原子的含量较多,从表面中心到棱边B原子的含量逐渐减少。而在hBN-LiH体系中所得到的晶体颜色从黑色透明直接变成黑色不透明状态,晶体内部没有出现三角形阴影,表明晶体中作为杂质的B原子分布比较均匀。此两种情况说明,B作为杂质原子进入cBN晶体中可以有两种分布情况,一是居中对称分布,二是均匀分布,从晶体的生长环境和自身的排杂能力方面分析了晶体为什么会出现上述现象。Abstract: Using hBN-LiH or hBN-Li3N-B as starting materials, we synthesied black cBN crystals under high pressure and high temperature. The results of Raman spectrum show that the reason why cBN crystals become black is that the redundant B atoms get into them. The cBN crystal is synthesized in hBN-Li3N-B system, and then we observe a trigonal shadow is formed clearly. This phenomenon indicates that there are more B atoms from center to apex in cBN crystal, and the B atoms content gradually decrease from center to edge. However, the color of cBN crystal which is synthesized in hBN-LiH system was from transparent black to opaque black directly, and the trigonal shadow does not be formed. This phenomenon indicates that the B atoms as impurity diffuse equably in cBN crystals. The two circumstances illustrate that as an impurity atom, B has two kinds of distributions when it enter into cBN crystal: one is centeral symmetric distribution, the other is uniform distribution. In this paper, we analyze the reason why cBN crystals have different phenomenon above according to its growth environment and its ability of excluding impurity.
-
Key words:
- high pressure and high temperature /
- cBN /
- coloration process
-
Dou Q P, Ma H T, Jia G, et al. Light Emission from cBN Crystal Synthesized at High Pressure and High Temperature [J]. Appl Phys Lett, 2006, 88: 154102(1)-154102(3). Lian G, Zhang X, Zhu L L, et al. Inducing Effect of Halide Species in the Hydrothermal Synthesis of Cubic Boron Nitride [J]. Cryst Growth, 2009, 311: 1600-1606. Zhang T C, Xu X W, Guo W L, et al. Studies on Synthesis and Heat Resistant Chatacter of cBN Crystals with Different Colors [J]. Chinese Journal of High Pressure Physics, 1990, 4(4): 270-275. (in Chinese) 张铁臣, 徐晓伟, 郭伟力, 等. 不同颜色立方氮化硼的合成及耐热性的研究 [J]. 高压物理学报, 1990, 4(4): 270-275. Taniguchi T, Yamaoka S. Spontaneous Nucleation of Cubic Boron Nitride Single Crystal by Temperature Gradient Method under High Pressure [J]. Cryst Growth, 2001, 222: 549-557. Taniguchi T, Watanabe K. Synthesis of High-Purity Boron Nitride Single Crystals under High Pressure by Using Ba-BN Solvent [J]. Cryst Growth, 2007, 303: 525-529. Liu H B, Jia G, Chen G, et al. Study of Cubic Boron Nitride Crystal UV Absorption Spectroscopy [J]. Spectroscopy and Spectral Analysis, 2008, 28(7): 1569-1572. (in Chinese) 刘海波, 贾刚, 陈岗, 等. 立方氮化硼单晶紫外吸收光谱的研究 [J]. 光谱学与光谱分析, 2008, 28(7): 1569-1572. Du Y H, Su Z P, Yang D P, et al. Synthesis of Black cBN Single Crystal in hBN-Li3N-B System [J]. Mater Lett, 2007, 61: 3409-3412. Wang G Z. Synthesis of cBN with Various Catalyst and System [J]. Superhard Material Engneering, 2005, 17: 44-47. (in Chinese) 王光祖. 在不同触媒-hBN体系中cBN的合成 [J]. 超硬材料工程, 2005, 17: 44-47. Singhal S K, Park J K. Synthesis of Cubic Boron Nitride from Amorphous Boron Nitride Containing Oxide Impurity Using Mg-Al Alloy Catalyst Solvent [J]. Cryst Growth, 2004, 260: 217-222. Sachdev H. Influence of Impurities on the Morphology and Raman Spectra of Cubic Boron Nitride [J]. Diamond Relat Mater, 2003, 12: 1275-1286. Sachdev H, Strauss M. Investigation of the Chemical Reactivity and Stability of c-BNP [J]. Diamond Relat Mater, 1999, 8(2): 319-324. Luo G F. Introduce of Crystallography [M]. Zhangjiakou: Geological Press, 1985: 14. (in Chinese) 罗谷风. 结晶学导论 [M]. 张家口: 地质出版社, 1985: 14.
