Experimental Study on Phase Transition and Spall Fracture in FeMnNi Alloy under Shock Pressure
-
摘要: 采用激光速度干涉仪(VISAR)、X射线衍射(XRD)和扫描电镜(SEM)联合测试技术,利用等厚对称加载和逆向加载实验,研究了FeMnNi合金的冲击相变和层裂行为。结果发现:加载压力大于6.5 GPa时,FeMnNi合金样品发生相变;中心稀疏波的卸载作用使内压力降至4~5 GPa时,FeMnNi合金样品发生逆相变,并伴有卸载稀疏冲击波形成。分析FeMnNi合金样品中塑性波、相变波、稀疏波和稀疏冲击波的传播作用过程,发现加载压力大于其相变应力时,等厚对称加载下FeMnNi合金存在产生层裂行为的物理机制。Abstract: By means of velocity interferometer system for any reflector (VISAR), X-ray diffraction (XRD) and scanning electron microscope (SEM), phase transition and spalling behavior of the FeMnNi alloy were studied through symmetric impact and reverse impact experiments. The FeMnNi alloy experiences a phase transformation when shocked to the pressure above 6.5 GPa. The FeMnNi alloy produces reverse phase transition and rarefaction shock wave when the pressure reduce to 4~5 GPa due to the rarefaction wave. By analyzing the interaction among plastic wave, phase transition wave, rarefaction wave and rarefaction shock wave, it was found that the FeMnNi alloy has a physical mechanism inducing the formation of spall behavior in symmetric impact experiments as the impact stress exceeds transition threshold.
-
Key words:
- FeMnNi alloy /
- phase transition /
- reverse transition /
- spall /
- rarefaction shock wave
-
Barker L M, Hollenbach R E. Shock Wave Study of the Phase Transition in Iron [J]. J Appl Phys, 1974, 45(11): 4872-4887. Veeser L R, Gray G T, Vorthman J E, et al. High Pressure Response of a High-Purity Iron [A]//Furnish M D, Chhabidas L C, Hixson R S. Shock Compression of Condensed Matter-1999 [C]. Utah: American Institute of Physics, 2000: 73-76. Christophe V, Gilles R. Iron Damage and Spalling Behavior Below and above Induced Phase Transition [A]//Furnish M D, Elert M, Russell T P, et al. Shock Compression of Condensed Matter-2005 [C]. Maryland: American Institute of Physics, 2006: 678-681. Christophe V, Francois B, Gilles R. Study of Spalling for High Purity Iron below and above Induced Phase Transition [A]//Furnish M D, Cupta Y M, Forbes J M. Shock Compression of Condensed Matter-2003 [C]. New York: American Institute of Physics, 2004: 511-514. Gray G T, Hayes D B, Hixson R S. Influence of the Shock-Induced Transition in Fe on Its Post-Shock Substructure Evolution and Mechanical Behavior [J]. Journal de Physique IV, 2000, 10(9): 755-760. Kalantar D H, Belak J F, Collins G W, et al. Direct Observation of the - Transition in Shock-Compressed Iron via Nanosecond X-Ray Diffraction [J]. Phys Rev Lett, 2005, 95(7): 075502. James H, Martin B, Huw D, et al. In-Situ Probing of Lattice Response in Shock Compressed Materials Using X-Ray Diffraction [A]//Elert M, Furnish M D, Chau R, et al. Shock Compression of Condensed Matter-2007 [C]. Hawai: American Institute of Physics, 2008: 1327-1332. Tang Z P, Tang X J, Zhang X H, et al. Abnormal Spall Behavior Observation in Pure Iron and FeMnNi Alloy Undergoing Phase Transition [A]//Furnish M D, Elert M, Russell T P, et al. Shock Compression of Condensed Matter-2005 [C]. Maryland: American Institute of Physics, 2006: 662-665. Zhang X H, Tang Z P. Experimental Study on Characteristics of Shock-Induced Phase Transition and Spallation in FeMnNi Alloy [J]. Explosion and Shock Waves, 2007, 27(2): 103-108. (in Chinese) 张兴华, 唐志平. FeMnNi合金的冲击相变和层裂特性研究 [J]. 爆炸与冲击, 2007, 27(2): 103-108.
