内部短药柱爆炸作用下钢筒破裂特征的数值分析

王新征; 张松林; 邹广平

doi:10.11858/gywlxb.2010.01.011

内部短药柱爆炸作用下钢筒破裂特征的数值分析

doi: 10.11858/gywlxb.2010.01.011

1.
西北核技术研究所，陕西西安 710024；
2.
北京理工大学爆炸科学与技术国家重点实验室，北京 100081；
3.
哈尔滨工程大学航天与建筑工程学院，黑龙江哈尔滨 150001

详细信息

通讯作者:
王新征

计量
- 文章访问数: 7499
- HTML全文浏览量: 262
- PDF下载量: 750
出版历程
- 收稿日期: 2009-05-10
- 修回日期: 2009-09-20
- 发布日期: 2010-02-15

Numerical Analysis on Fragmentation Properties of the Steel Cylinder Subjected to Detonation of Internal Short Cylinderical Explosive Charge

1.
Northwest Institute of Nuclear Technology, Xi'an 710024, China;
2.
State Key Laboratory of Explosion Science and Technology, Beijing Institute of Technology, Beijing 100081, China;
3.
College of Aerospace and Civil Engineering, Harbin Engineering University, Harbin 150001, China

More Information

Corresponding author: WANG Xin-Zheng

摘要

摘要: 采用光滑粒子（SPH）法研究了短药柱在钢筒内爆炸形成破片的特征，采用Grady层裂准则描述钢筒的层裂破坏，破坏模式为随机破坏，服从Mott分布。分析了破片的质量分布和速度，计算结果表明：钢筒经过一定膨胀后，首先在装药端部位置破裂，然后爆心附近的钢筒解体成破片，如果是封闭钢筒，钢筒端部也是形成破片的重要部位。爆心附近的破片质量小、速度高；端部的破片质量较大、速度低；爆心附近的破片相对集中。
- 钢筒 /
- 光滑粒子法 /
- 爆炸 /
- 破片 /
- 数值模拟
Abstract: The characteristics of fragments, which are numerical studied with Smoothed Particle Hydrodynamic (SPH) algorithms, come from the steel cylinder subjected to the detonation of internal short cylinderical explosive charge. Grady spall model is employed to describe the spall failure of the steel cylinder. Stochastic failure is used to define the failure models, in which Mott distribution is used to depict the failure strain. Mass distribution and velocity of fragments are mainly discussed. The results show that the part near the head of explosive begins to fracture after the steel cylinder expands to a certain extent, and then the part around the explosive disaggregates to fragments. For the closed cylinder, the ends are the other weakness position. The fragments around the explosion centre are smaller with high velocity, while the fragments around cylinder ends are larger with low velocity. The fragments near the explosion centre are relatively concentrated in the space.
- steel cylinder /
- Smoothed Particle Hydrodynamic (SPH) /
- explosion /
- fracture /
- numerical simulation

HTML全文

参考文献(24)

Gurney R W. The Initial Velocities of Fragments from Bombs, Shell, Grenades [R]. Aberdeen, Maryland: Ballistic Research Laboratories, 1943.

Mott N F. Fragmentations of Shell Cases [J]. Mathemat Phys Sci, 1947, 189(1018): 300-308.

Grady D E. The Spall Strength of Condensed Matter [J]. J Mech Phys Solids, 1988, 36(3): 353-384.

Grady D E. Local Inertial Effects in Dynamic Fragmentation [J]. J Appl Phys, 1982, 53(1): 322-325.

Grady D E, Kipp M E. Experimental Measurement of Dynamic Failure and Fragmentation Properties of Metals [R]. DE-AC04-76DP00789, 1994.

Kipp M E, Grady D E. Dynamic Fracture Growth and Interaction in One Dimension [J]. J Mech Phys Solids, 1985, 33(4): 399-415.

Grady D E. Fragmentation of Rings and Shells [M]. Berlin: Springer-Verlag, 2006.

Garg S K, Siekmann J. On Fracture of a Thin Spherical Shell under Blast Loading [J]. Exp Mech, 1966, 6(1): 39-44.

Martineau R L, Anderson C A, Smith F W. Expansion of Cylindrical Shells Subjected to Internal Explosive Detonations [J]. Exp Mech, 2000, 40(2): 219-225.

Wilson L T, Reedal D R, Kipp M E. Comparison of Calculated and Experimental Results of Fragmentations Cylinder Experiments [R]. DE-AC04-94AL85000, 2000.

Ivanov A L, Syrunin M A, Fedorenko A G, et al. Fragmentation of Spherical Shells under Internal Blasting Loading [J]. Strength Mater, 2001, 33(2): 150-156.

Elek P, Jaramaz S. Modeling of Fragmentation of Rapidly Expanding Cylinders [J]. Theoret Appl Mech, 2005, 32(2): 113-130.

Zhang T, Yu J, Zhao L J, et al. Spontaneous Fracture of Steel Cylinder under Internal Explosion Load [J]. Journal of Northeastern University (Natural Science), 2006, 27(s1): 159-160. (in Chinese)

张陶, 於津, 赵利军, 等. 内部爆炸载荷作用下金属柱壳的自然破碎过程研究 [J]. 东北大学学报(自然科学版), 2006, 27(s1): 159-160.

Li Y C, Zhang W, Huang C Y, et al. Thermo Plastic Constitutive Relation of Damaged Materials and Its Applications to Cylinder Fractures [J]. Journal of China University of Science and Technology, 1999, 29(3): 260-268. (in Chinese)

李永池, 张伟, 黄承义, 等. 损伤材料的热塑性本构关系及对柱壳破裂问题的应用 [J]. 中国科学技术大学学报, 1999, 29(3): 260-268.

Li Y C, Li D H, Wei Z G, et al. Research on the Deformation, Damage and Fracture Rules of Circular Tubes under Inside-Explosive Loading [J]. Acta Mechanica Sinica, 1999, 31(4): 442-449. (in Chinese)

李永池, 李大红, 魏志刚, 等. 内爆炸载荷下圆管变形、损伤和破坏规律的研究 [J]. 力学学报, 1999, 31(4): 442-449.

Li Y C, Wang H W, Jiang S Q, et al. Research on the Thermal-Viscoplastic Constitutive Relation of Damaged Materials and Numerical Simulation of Circular Tubes Fracture [J]. Explosion and Shock Waves, 2001, 21(2): 105-110. (in Chinese)

李永池, 王红五, 江松青, 等. 含损伤材料的热粘塑性本构关系和柱壳破裂研究 [J]. 爆炸与冲击, 2001, 21(2): 105-110.

Tang T G, Gu Y, Li Q Z, et al. Expanding Fracture of Steel Cylinder Shell by Detonation Driving [J]. Explosion and Shock Waves, 2003, 23(6): 529-533. (in Chinese)

汤铁钢, 谷岩, 李庆忠, 等. 爆轰加载下金属柱壳膨胀破裂过程研究 [J]. 爆炸与冲击, 2003, 23(6): 529-533.

Hu B Y, Dong Q D, Han C S, et al. Studies of Explosion and Fracture of Explosive-Filled Steel Cylinders [J]. Explosion and Shock Waves, 1993, 13(1): 49-54. (in Chinese)

胡八一, 董庆东, 韩长生, 等. 内部爆轰加载下的钢管膨胀断裂研究 [J]. 爆炸与冲击, 1993, 13(1): 49-54.
