聚对苯二甲酸乙二醇酯-双酚A型聚碳酸酯共混体系中聚合物伸直链晶体的形态分析

吕军; 黄锐; 李良彬

doi:10.11858/gywlxb.2010.01.002

聚对苯二甲酸乙二醇酯-双酚A型聚碳酸酯共混体系中聚合物伸直链晶体的形态分析

doi: 10.11858/gywlxb.2010.01.002

吕军^1,2,,
黄锐²,
李良彬³

1.
西南交通大学材料科学与工程学院材料先进技术教育部重点实验室，四川成都 610031；
2.
四川大学高分子科学与工程学院，四川成都 610065；
3.
中国科技大学合肥国家同步辐射实验室，安徽合肥 230026

详细信息

通讯作者:
吕军

计量
- 文章访问数: 7864
- HTML全文浏览量: 380
- PDF下载量: 500
出版历程
- 收稿日期: 2009-01-20
- 修回日期: 2009-09-30
- 发布日期: 2010-02-15

Morphology Investigation of the Extended-Chain Crystals in High-Pressure Crystallized Poly (Ethylene Terephthalate)-(Bisphenol-A) Polycarbonate Blends

1.
Key Laboratory of Advanced Technologies of Materials, Ministry of Education, School of Materials Science and Engineering, Southwest Jiaotong University, Chengdu 610031, China;
2.
College of Polymer Materials Science and Engineering, Sichuan University, Chengdu 610065, China;
3.
National Synchrotron Radiation Lab and Department of Polymer Science and Engineering, University of Science and Technology of China, Hefei 230026, China

摘要

摘要: 利用扫描电子显微镜（SEM）和原子力显微镜（AFM）等表征手段，研究了聚对苯二甲酸乙二醇酯-双酚A型聚碳酸酯（PET-PC）共混物的高压结晶样品。研究发现共混体系中存在具备不同形态特征的伸直链晶体，其中包括楔形晶体、弯曲晶体以及楔形弯曲晶体。通过对这些晶体的形态观察，揭示出体系中大尺寸聚酯伸直链单晶体的增厚生长首先要经历形成折叠链晶核的成核阶段，然后才是在酯交换反应和链滑移扩散两种机制共同作用下的等温增厚的链伸展过程。有助于深入理解PET-PC共混物中伸直链单晶体生长过程的本质因素，以便在类似聚合物体系中合成大尺寸的同类晶体。
- 晶体形态 /
- 伸直链晶体 /
- 高压 /
- 熔体生长 /
- 聚合物
Abstract: Morphologies of extended- chain crystals with different characteristics, i.e. wedge-shaped crystals, bent crystals and wedge- shaped bent crystals, were disclosed with scanning electron microscopy (SEM) and atomic force microscope (AFM) in the high-pressure crystallized poly (ethylene terephthalate)/bisphenol-A polycarbonate (PET-PC) blends. The observations revealed that the thickening growth for the large polyester extended-chain single crystals should first undergo the nucleation step leading to the folded-chain nuclei, and then, the chain extension process which is an isothermal thickening resulting from transesterification and sliding diffusion. The morphological structures shed light on the fundamental nature of the large single crystals in the blends, which may be instructive to grow such large crystals in similar polymer systems.
- crystal morphology /
- extended-chain crystal /
- high pressure /
- melt growth /
- polymer

HTML全文

参考文献(31)

Wunderlich B, Arakawa T. Polyethylene Crystallized from the Melt under Elevated Pressure [J]. J Polymer Sci, 1964, A2: 3697-3706.

Wunderlich B, Melillo L. Surface Recrystallization of Polyethylene Extended-Chain Crystals [J]. Sci, 1966, 154: 1329-1330.

Hatakeyama T, Kanetsuna H, Hashimoto T. Large Polyethylene Crystals Formed under High Pressure [J]. J Macromoler Sci-Phys, 1973, B7: 411-415.

Gogolewski S. A Possible Mechanism of Chain Extension in Nylon-6 during Crystallization under Pressure [J]. Polymer, 1977, 18: 63-68.

Miyamoto Y, Nakafuku C, Takemura T. Crystallization of Poly(Chlorotrifluoroethylene) [J]. Polymer J, 1972, 3: 122-128.

Ohigashi H, Hattori T. Improvement of Piezoelectric Properties of Poly(Vinylidene Fluoride) and Its Copolymers by Crystallization under High Pressures [J]. Ferroelectrics, 1995, 171: 11-32.

Hattori T, Hikosaka M, Ohigashi H. The Crystallization Behaviour and Phase Diagram of Extended-Chain Crystals of Poly(Vinylidene Fluoride) under High Pressure [J]. Polymer, 1996, 37: 85-91.

Siegmann A, Harget P J. Melting and Crystallization of Poly(Ethylene Terephthalate) under Pressure [J]. J Polymer Sci: Polym Phys Edit, 1980, 18: 2181-2196.

Li L, Huang R, Lu A, et al. High Pressure Crystallized Poly (Ethylene Terephthalate): High Crystallinity and Large Extended-Chain Crystals [J]. Polym, 2000, 41: 6943-6947.

Li L, Huang R, Hong S. Sintering Polymer Nano-Crystals at High Pressure [J]. J Mater Sci Lett, 2001, 20: 807-809.

Li L, Huang R, Wang C, et al. The High-Pressure Crystallization and Annealing Behaviors of Polyethylene Terephthalate Oligomer [J]. J Macromoler Sci-Phys, 2001, B40(6): 1169-1178.

Li L, Wang C, Huang R, et al. Morphology of High-Pressure Crystallized Poly (Ethylene 2, 6-Naphthalate) [J]. Polymer, 2001, 42: 8867-8872.

L J, Oh I K, Huang R, et al. Growth of Novel Stereo-Open Spherulites in a Bisphenol-A Polycarbonate/Dioctyl Phthalate Blend at Hydrostatic Pressure [J]. Chemical Journal of Chinese Universities, 2007, 28(2): 385-387. (in Chinese)

吕军, 吴一权, 黄锐, 等. 静高压下邻苯二甲酸二辛酯增塑双酚A型聚碳酸酯体系中立体开放球晶的生长 [J]. 高等学校化学学报, 2007, 28(2): 385-387.

L J, Huang R, Oh I K. Morphology Investigation on High-Pressure Crystallized Bisphenol-A Polycarbonate/Dioctyl Phthalate Blends [J]. J Polymer Sci Part B: Polymer Phys, 2007, 45: 2715-2728.

L J, Huang R, Oh I K. Melt Crystallization and Morphology of Poly (p-Phenylene Sulfide) under High Pressure [J]. Macromolec Chem Phys, 2007, 208: 405-414.

L J, Oh I K, Huang R, et al. Electron Microscopy of High Pressure Crystallised Poly(p-Phenylene Sulfide) [J]. Plast, Rubb Composit, 2008, 37: 263-267.

Keller A, Goldbeck-Wood G, Hikosaka M. Polymer Crystallization: Survey and New Trends with Wider Implications for Phase Transformat [J]. Faraday Discus, 1993, 95: 109-128.

Ward I M. Mechanical Properties of Solid Polymers(2nd ed) [M]. New York: John Wiley Sons, 1983.

de Gennes P G. Scaling Concepts in Polymer Physics [M]. Ithaca: Cornell University Press, 1979.

L J, Huang R, Li L, et al. Growth of Large Polymer Extended-Chain Single Crystals in a Poly(Ethylene Terephthalate)/Bisphenol A Polycarbonate Blend under High Pressure [J]. Macromolec Rapid Communicat, 2005, 26: 1478-1482.

L J, Wang X L, Huang R, et al. Effect of Transesterification on High-Pressure Crystallization Behaviour of PET/PC Blend System [J]. Chemical Journal of Chinese Universities, 2005, 26(8): 1556-1560. (in Chinese)

吕军, 王选伦, 黄锐, 等. PET/PC共混体系的酯交换反应对其高压结晶行为的影响 [J]. 高等学校化学学报, 2005, 26(8): 1556-1560.

L J, Wei G, Huang R, et al. Observation of Novel Spherulitic Morphology Formed in Extended-Chain Crystals in High-Pressure Crystallized PET/PC Blends [J]. Chemical Journal of Chinese Universities, 2005, 26(8): 2391-2393. (in Chinese)

吕军, 魏刚, 黄锐, 等. 高压结晶PET/PC共混体系中生长在伸直链晶体内部球晶形态的观察 [J]. 高等学校化学学报, 2005, 26(12): 2391-2393.

Barford W. Electronic and Optical Properties of Conjugated Polymers [M]. Oxford: Clarendon Press, 2005.

Wunderlich B. Macromolecular Physics(Vol. 1) [M]. New York: Academic Press, 1973.

Li L B, Huang R, Zhang L, et al. A New Mechanism in the Formation of PET Extended-Chain Crystals [J]. Polymer, 2001, 42: 2085-2089.

Bassett D C. Principles of Polymer Morphology [M]. Cambridge: Cambridge University Press, 1981.

Hoffman J D, Miller R L. Kinetics and Crystallization from the Melt and Chain Folding in Polyethylene Fractions Revisited: Theory and Experiment [J]. Polymer, 1997, 38: 3151-3212.

Li L B, Sererro Y, Koch M H, et al. Microphase Separation and Crystallization in an Asymmetric Diblock Copolymer: Coupling and Competition [J]. Macromolecules, 2003, 36: 529-532.
