基于有限元法确立碳化钨顶锤的破裂判据

韩奇钢; 马红安; 李瑞; 张聪; 李战厂; 贾晓鹏

doi:10.11858/gywlxb.2010.01.001

基于有限元法确立碳化钨顶锤的破裂判据

doi: 10.11858/gywlxb.2010.01.001

1.
吉林大学超硬材料国家重点实验室，吉林长春 130012；
2.
长春理工大学材料科学与工程学院，吉林长春 130012

详细信息

通讯作者:
贾晓鹏

计量
- 文章访问数: 8043
- HTML全文浏览量: 339
- PDF下载量: 847
出版历程
- 收稿日期: 2009-11-11
- 修回日期: 2009-12-12
- 发布日期: 2010-02-15

The Criterion for Crack of Tungsten Carbide Anvil Based on Finite Element Method

1.
National Laboratory of Superhard Materials, Jilin University, Changchun 130012, China;
2.
School of Materials Science and Engineering, Changchun University of Science and Technology, Changchun 130012, China

More Information

Corresponding author: JIA Xiao-Peng

摘要

摘要: 以有限元法为理论基础，通过运行大型有限元软件，成功构建了铰链式六面顶压机配套顶锤的有限元理论模型，并确立了碳化钨顶锤的破裂判据。模拟结果表明：以小斜边末尾处为应力参考点，依据第四强度理论，能够对碳化钨顶锤的性能进行更加合理的数值分析。依据此判据可知：在顶锤锤面及小斜边附近，裂纹高发区分布在小斜边附近；在顶锤轴向上，裂纹高发区分布在距离顶锤锤面30 mm处。铰链式六面顶压机配套碳化钨顶锤的有限元模型以及碳化钨顶锤破裂判据的成功构建，为实现新型碳化钨顶锤的设计与研究奠定了基础，对促进实现铰链式六面顶压机腔体大型化具有现实意义。
- 破裂判据 /
- 顶锤 /
- 有限元法 /
- 高压物理
Abstract: Based on finite element method, the model of tungsten carbide (WC) anvil and the criterion for crack of WC anvil used in China-type cubic high pressure apparatus have been founded successfully. The simulation results indicated that the criterion for crack of WC anvil should make the reference point at the end of bevel edge. According to the von Mises criterion, we know that in the area of anvil surface and bevel edge, the cracks are often arising around the bevel edge. In the axis of anvil, the cracks are often arising at the place which is 30 mm below anvil surface. This study may greatly help to design new type WC anvil and improve the large volume cubic anvil type high pressure techniques.
- criterion for crack /
- anvil /
- finite element method /
- high pressure physics

HTML全文

参考文献(17)

Jiang Y P, Jia X P, Ma H A, et al. High Pressure Synthesis and Electric Transport Properties of La-Filled CoSb3 Skutterudite Thermoelectric Materials [J]. Chinese Journal of High Pressure Physics, 2009, 23(2): 87-90. (in Chinese)

姜一平, 贾晓鹏, 马红安, 等. 高压合成La填充型CoSb3方钴矿热电材料及其电输运性能 [J]. 高压物理学报, 2009, 23(2): 87-90.

Li X L, Ma H A, Zuo G H, et al. Low-Temperature Sintering of High-Density Aluminium Nitride Ceramics without Additives at High Pressure [J]. Scripta Materialia, 2007, 56: 1015-1018.

Liang Z Z, Kanda H, Jia X, et al. Synthesis of Diamond with High Nitrogen Concentration from Powder Catalyst-C-Additive Na3N3 by HPHT [J]. Carbon, 2006, 44: 913-917.

Wang G Z, Zhai X Q, Luo M. the High Pressure and High Temperature Apparatus of the Hinge-Type Cubic-Anvil Press [J]. Diamond and Abrasive Tools Engineering, 2000, 120: 34-37. (in Chinese)

王光祖, 翟小青, 罗明. 铰链式六面砧高压高温装置 [J]. 金刚石与磨料磨具工程, 2000, 120: 34-37.

Li Z H, Zhao Q G, Zhao B, et al. The Development of China-Type Cubic High Pressure Apparatus and Man-Made Diamond [J]. Diamond Abrasives News, 2007, 195(1): 1-5. (in Chinese)

李志宏, 赵清国, 赵博, 等. 发展中的中国六面顶压机和人造金刚石 [J]. 磨料磨具通讯, 2007, 195(1): 1-5.

Getting I C, Chen G L, Brown J A. The Strength and Rheology of Commercial Tungsten Carbide Cermets Used in High-Pressure Apparatus [J]. Pure Appl Geophys, 1993, 141(2/3/4): 545-577.

Zhang X Y, Yan S W. Fundamentals of Geotechnic Plasticity [M]. Tianjin: Tianjin University Publishing House, 2004: 76-77. (in Chinese)

张学言, 闫澍旺. 岩土塑性力学基础 [M]. 天津: 天津大学出版社, 2004: 76-77.

Venkateswaran C, Anbukumaran K, Victor J N, et al. Design and Performance of Belt-Type High Pressure High Temperature Apparatus [J]. Rev Sci Instrum, 1997, 68(1): 189-192.

Li S S. Growth of Large High-Quality Type Ⅱa Diamond Crystals and Research of the Mechanism under HPHT [M]. Changchun: Jilin University, 2009: 23-34. (in Chinese)

李尚升. 优质Ⅱa 型宝石级金刚石的高温高压合成及机理研究 [M]. 长春: 吉林大学, 2009: 23-34.

Wang M, Wang S S. the Break Characteristic and Breakdown Factors Analysis of Cement Carbide Anvil and Pressure Die and the Way of Raise Their Service Life [J]. Cemented Carbide, 1994, 11(4): 231-240. (in Chinese)

王民, 王松顺. 硬质合金顶锤和压缸的破裂特征、破坏因素的分析和提高使用寿命的途径 [J]. 硬质合金, 1994, 11(4): 231-240.

Tracy H H . Metallurgy at High Pressures and High Temperatures [M]. New York: Gordon and Breach Science Publishers, 1964: 1-31.
