Study on the Physical Explosion Character and Ejection Effect of the High-Pressurized Hydrogen Transport Device
-
摘要: 由于输运装置突然失效而引发的高压氢气喷射,能够在流场中造成超压和足以引发爆炸的扩散。运用数值计算方法,建立可用于计算的物理和数学模型对发生泄漏后有、无障碍物两种情况下的外部流场进行分析,可得到外部流场中的气体泄漏压力和浓度的分布等值线图。从计算结果可以得出氢气发生爆炸事故后的危险区域,障碍物对氢气的喷射泄漏以及爆炸所产生的影响,从而可为预防和处理氢气爆炸事故提供参考依据。Abstract: High-pressured hydrogen's ejection caused by the structural failure of transport device could result in overpressure and mass fraction within the explosion limits. External flow field characters, hydrogen jet pressure, and mass fraction in the field were numerically simulated by using physical and calculation model in case of external flow field with or without obstacle. Hazardous area after hydrogen explosion and effect of obstacle on preventing hydrogen leakage and diffusion were obtained. The drawn conclusion could be the reference for prevention and treatment of hydrogen explosion accidents.
-
Key words:
- high-pressurized hydrogen /
- transport device /
- physical explosion
-
Hashimoto A, Matsuo A. Numerical Analysis of Gas Explosion Inside Two Rooms Connected by Ducts [J]. Journal of Loss Prevention in the Process Industries, 2007, 20(4-6): 455-461. Chernyshev A P, Lukyanchikov L A, Lyakhov N Z, et al. Physical-Chemical Model of Nanodiamand Formation at Explosion [J]. Nuclear Instruments and Methods in Physics Research, 2007, 575(1-2): 72-74. Liu N S, Lu X Y, Zhuang L X. Numerical Study on Hydrogen Injection in Supersonic Flow [J]. Journal of China University of Science and Technology, 1999, 29(5): 551-559. (in Chinese) 刘难生, 陆夕云, 庄礼贤. 超声速气流中氢气燃料喷流的数值模拟研究 [J]. 中国科学技术大学学报, 1999, 29(5): 551-559. Yang Z, Lai J B, Han J L. Study on Hazardous Area of Hole Leakage of Gas Pipelines [J]. Natural Gas Industry, 2006, 26(1): 156-159. (in Chinese) 杨昭, 赖建波, 韩金丽. 天然气管道空口泄漏危险区域的研究 [J]. 天然气工业, 2006, 26(1): 156-159. Groethe M, Merilo E, Colton J, et al. Large-Scale Hydrogen Deflagrations and Detonations [J]. Int J Hydrogen Eng, 2007, 32(13): 2125-2133. Yu D M. Studies on the Major Source Risk Assessment and Fire Severity of Explosion [D]. Beijing: Beijing Institute of Technology, 1996. (in Chinese) 宇德明. 重大危险源评价及火灾爆炸事故严重度的若干研究 [D]. 北京: 北京理工大学, 1996. Yang Z H, Wang Z G, Tang C G, et al. Critical Estimation of the Internal Organ Injury in Human Being Subjected to Weak Blast Waves [J]. Explosion and Shock Waves, 1992, 12(1): 83-88. (in Chinese) 杨志焕, 王正国, 唐承功, 等. 弱冲击波对人员内脏损伤的危险性的估计 [J]. 爆炸与冲击, 1992, 12(1): 83-88. Lobato J, Canizares P, Rodriqo M A, et al. A Comparison of Hydrogen Cloud Explosion Models and the Study of the Vulnerability of the Damage Caused by an Explosion of H2 〖KG1mm〗[J]. Int J Hydrogen Eng, 2006, 31(12): 1780-1790.
