Calculation of the Angle Deformation in Explosive Welding Based on the Ideal Fluid Model of Symmetrical Colliding
-
摘要: 采用理想流体对称碰撞模型,分析了爆炸焊接流场中沿流线的物理变形,推导出了角变形的理论计算公式,并采用Visual C++语言对其进行了编程计算,获得了驻点近区角变形的大小及变化规律。结果表明,在驻点近区,沿来流至出流方向角变形逐步增大,其变化率在驻点附近最大;沿出流方向,给定碰撞角,角变形随来流速度的增加而增大;给定来流速度,角变形随碰撞角的增大而减小。从理论和实验方面,间接地将计算结果与前人的结论进行了对比验证,结果是一致的,以此为基础配合驻点近区的应变率场,讨论了其对爆炸焊接波状界面形成的影响。Abstract: An ideal fluid model of symmetrical colliding was taken to analyze the physical deformation on streamlines in explosive welding, and a theoretical formula of the angle deformation was deduced. The language of Visual C++ was adopted to make a program to calculate the angle deformation numerically. The size of the angle deformation is obtained as well as the change law of it. The result shows that, near the stagnation point, the angle deformation is always increasing along the coming fluid to the outing fluid, and the changing rate near the stagnation point is maximum. Along the outing fluid the angle deformation increases with the augment of the velocity at given impact angle, and decreases with the increasing of the impact angle at the given velocity. The contrast and verification of the calculated results are in agreement with the theory and the experiment of others' indirectly. Based on it, the influence on the formation of the wavy interface in explosive welding by the strain rate field near the stagnation point was discussed.
-
Key words:
- explosive welding /
- symmetrical colliding /
- near the stagnation point /
- streamline /
- angle deformation
-
Han H, Li J, Jiao L J, et al. Study on the Application of Ceramic-Metal Composite Materials in Bulletproof Field [J]. Mater Rev, 2007, 21(2): 34-37. (in Chinese) 韩辉, 李军, 焦丽娟, 等. 陶瓷-金属复合材料在防弹领域的应用研究 [J]. 材料导报, 2007, 21(2): 34-37. Shao B H, Zhang K. Explosive Welding Principle and Its Application [M]. Dalian: Dalian University of Technology Press, 1987. (in Chinese) 邵丙璜, 张凯. 爆炸焊接原理及其工程应用 [M]. 大连: 大连理工大学出版社, 1987. Dikshit S N, Kutumbarao V V, Sundararajan G. The Influence of Plate Hardness on the Ballistic Penetration of Thick Steel Plates [J]. Inter J Impact Eng, 1995, 16(2): 293-320. Abe A. Numerical Simulation of the Plastic Flow Field near the Bonding Surface of Explosive Welding [J]. J Mater Proc Tech, 1999, 85: 162-165. Yang Y, Li Z H, L P C, et al. A Temperature Distribution Model of Explosive Cladding Interface and Its Application [J]. Rare Metal Mater Eng, 2000, 29(3): 161-163. (in Chinese) 杨扬, 李正华, 吕培成, 等. 爆炸复合界面温度场模型及应用 [J]. 稀有金属材料与工程, 2000, 29(3): 161-163. Li X J. The Upper Limit of Bimetal Explosive Welding Parameters [J]. Explosion and Shock Waves, 1991, 11(2): 134-138. (in Chinese) 李晓杰. 双金属爆炸焊接上限 [J]. 爆炸与冲击, 1991, 11(2): 134-138. Taylor G. Oblique Impact of a Jet on a Plane Surface [J]. Phil Trans Roy Soc, 1966, 260: 96-100. Robinson J L. Mechanics of Wave Formation in Impact Welding [J]. Philos Magazome, 1975, 31(3): 587-597. El-Sobky H, Blazynski T Z. Analysis of the Mechanism of Collision in Multilayered Composites [A]//Proc 7th Int Conf on High Energy Rate Fabrication [C]. Leeds: University of Leeds, 1981: 100-112. Wang L L, Yu T X, Li Y C. Shock Dynamics Progress [M]. Hefei: University of Science and Technology of China Press, 1992: 370. (in Chinese) 王礼立, 余同希, 李永池. 冲击动力学进展 [M]. 合肥: 中国科技大学出版社, 1992: 370. Li X J, Yan H H, Wang J X, et al. Calculation of the Distribution Rule of Strain Rate near the Stagnation Point during Explosive Welding [J]. Explosion and Shock Waves, 2002, 22(4): 315-320. (in Chinese) 李晓杰, 闫鸿浩, 王金相, 等. 爆炸焊接驻点近区应变率分布规律计算 [J]. 爆炸与冲击, 2002, 22(4): 315-320. Li X J, Yan H H, Wang J X, et al. Analysis of Strain Field Near Stagnation Point in Explosive Welding [J]. Rare Metal Materials and Engineering, 2003, 23(9): 699-702. (in Chinese) 李晓杰, 闫鸿浩, 王金相, 等. 爆炸焊驻点近区应变场分析 [J]. 稀有金属材料与工程, 2003, 23(9): 699-702. Yang Y. The Technology of Metallic Explosive Welding and Physical Metallurgy [M]. Beijing: Chemical Industry Press, 2006: 128-137. (in Chinese) 杨扬. 金属爆炸复合技术及物理冶金 [M]. 北京: 化学工业出版社, 2006: 128-137. Chen H J. The Method of Step for Explosion Welding Parameters [A]//Paper Collection of 4th the Whole Country Explosive Process Research Conference [C]. Beijing: Institute of Mechanics, Chinese Academy of Sciences, 1982. (in Chinese) 陈火金. 爆炸焊接参数试验的台阶法 [A]//第四届全国爆炸加工学术会议论文集 [C]. 北京: 中国科学院力学研究所, 1982. Kowalick J F, Hay D R. Mechanism of Explosive Bonding [J]. Met Trans, 1971, 2(7): 1953-1958. Zhang J C. Influences of Collision Angle on the Interface State of Explosive Compound Materials [J]. Journal of Experimental Mechanics, 2007, 22(1): 63-68. (in Chinese) 张建臣. 碰撞角对爆炸复合材料界面状态的影响 [J]. 实验力学, 2007, 22(1): 63-68.
