钽的层裂实验数值模拟

江松青; 刘文韬

doi:10.11858/gywlxb.2007.02.001

钽的层裂实验数值模拟

doi: 10.11858/gywlxb.2007.02.001

北京应用物理与计算数学研究所，北京 100088

详细信息

通讯作者:
江松青

计量
- 文章访问数: 7331
- HTML全文浏览量: 265
- PDF下载量: 619
出版历程
- 收稿日期: 2006-05-29
- 修回日期: 2006-06-29
- 发布日期: 2007-06-05

Numerical Modeling of Spallation Experiments of Tantalum

Beijing Institute of Applied Physics and Computational Mathematics, Beijing 100088, China

More Information

Corresponding author: JIANG Song-Qing

摘要

摘要: 采用连续介质力学基唯象模型模拟分析了钽的平板撞击层裂行为。该模型包括了材料的非线性弹性（状态方程）、率相关塑性和孔洞的形核及生长等多种效应，并且采用一种对角隐式Runge-Kutta方法来求解本构率方程组，提高了热粘塑性本构关系计算的稳定性及精度。将数值模拟结果和相关实验数据进行了对比分析，结果表明，对于样品中的拉应力峰值明显高于材料层裂强度的实验（中、高速平板撞击实验），理论模型具有较好的预估能力，但对于临界层裂问题（低速平板撞击实验），该模型对材料损伤与失效过程的描述可能不够准确，需要进一步改进。
- 钽 /
- 层裂 /
- 率相关塑性 /
- 孔洞 /
- 对角隐式Runge-Kutta法 /
- 热粘塑性本构关系 /
- 临界层裂
Abstract: A phenomenological model, which includes nonlinear elasticity (equation of state), rate-dependent plasticity, and void nucleation and growth, is provided for modeling the spallation behavior of tantalum. An implicit numerical technique, diagonally implicit Runge-Kutta method, is used to solve the constitutive rate-equations, and some improvements to the stability and accuracy of the solution are obtained. The model developed is used to simulate the plate impact experiments on tantalum. Comparisons are made between the model and the experimental data. Results show that close agreement between model predictions and experimental results is obtained for moderate or high velocity plate impact experiments, but some improvements in the model are necessary to predict the damage evolution and failure in incipient spall fracture of tantalum.
- tantalum /
- spallation /
- rate-dependent plasticity /
- void /
- diagonally implicit Runge-Kutta method /
- thermoviscoplastic constitutive relation /
- incipient spall fracture

HTML全文

参考文献(17)

Qu N Q, Chen J L. The Application of Ta and Ta Alloys [J]. World Nonferrous Metal, 1999, 5: 37-41. (in Chinese)

屈乃琴, 陈久录. 钽及钽合金的应用 [J]. 世界有色金属, 1999, 5: 37-41.

Zerilli F J, Armstrong R W. Dislocation-Mechanics-Based Constitutive Relations for Material Dynamics Calculations [J]. J Appl Phys, 1987, 61(5): 1816-1825.

Meyers M A, Chen Y J, Marquis F D S, et al. High-Strain, High-Strain-Rate Behavior of Tantalum [J]. Metall Trans A, 1995, 26A: 2493.

Chen S R, Gray G T Ⅲ, Bingert S R. Mechanical Properties and Constitutive Relations for Tantalum and Tantalum Alloys under High-Rate Deformation [R]. LA-UR-96-0602, 1996.

Gourdin W H. Constitutive Properties of Copper and Tantalum at High Rates of Tensile Strain: Expanding Ring Results [R]. UCRL-98812, 1998.

Duprey K E, Clifton R J. Dynamic Constitutive Response of Tantalum at High Strain Rates [A]//Schmidt S C, Dandekar D P, Forbes J W. Shock Compression of Condensed Matter-1997 [C]. New York: American Institute of Physics, 1998: 475-478.

Duprey K E, Clifton R J. Pressure-Shear Response of Thin Tantalum Foils [A]//Furnish M D, Chhabildas L C, Hixson R S. Shock Compression of Condensed Matter-1999 [C]. New York: American Institute of Physics, 2000: 447-450.

Thissell W R, Zurek A K, Tonks D L, et al. Experimental Quantitative Damage Measurements and Void Growth Model Predictions in The Spallation of Tantalum [A]. //Furnish M D, Chhabildas L C, Hixson R S. Shock Compression of Condensed Matter-1999 [C]. New York: American Institute of Physics, 2000: 451-454.

Tonks D L, Zurek A K, Thissell W R. Spallation Modeling in Pure commercially Tantalum [A]//Staudhammer K P, Murr L E, Meyers M A. Proceedings of International Conference on Fundamental Issues and Applications of Shock-Wave and High-Strain- Rate Phenomena (EXPLOMET 2000) [C]. Albuquerque, USA: Elsevier, 2001: 517-523.

Zurek A K, Thissell W R, Trujillo C P, et al. Damage Evoluton in Ductile Metals [J]. Los Alamos Science, 2003, 28: 111-113.

Thissell W R, Tonks D L, Schwartz D S, et al. Dynamic Failure Resistance of Two Tantalum Materials with Different Melt Practice Sequences [A]//Furnish M D, Gupta Y M, Forbes J W. Shock Compression of Condensed Matter-2003 [C]. New York: American Institute of Physics, 2004: 495-498.

Zhang L. The Responses of Ductile Materials to Shock Wave Loadings: A New Model for Prediction of Dynamic Damage, Fracture and Structure Phase Transition [D]. Beijing: Beijing Institute of Applied Physics and Computational Mathematics, 2005. (in Chinese)

张林. 延性材料冲击响应: 动态损伤与断裂、结构相变的新模型 [D]. 北京: 北京应用物理与计算数学研究所, 2005.

Liu H F. A Handbook on Equations of State for Variuos Materials [Z]. Beijing: Beijing Institute of Applied Physics and Computational Mathematics, 2003. (in Chinese)

刘海风. 状态方程手册 [Z]. 北京: 北京应用物理与计算数学研究所, 2003.

Rajendran A M, Grove D J. A Dynamic Failure Model for Ductile Materials [R]. AFATL-TR-90-84, 1991.
