SEM Observation of Large Polymer Extended-Chain Crystals in High-Pressure Crystallized PET/PC Blends
-
摘要: 大尺寸聚合物伸直链晶体在低维体系物理学的研究中具有不可替代的重要作用。但以往高压合成的聚合物伸直链晶体,尺寸较小且合成时间过长,使其作用至今未能显现。加入10%(质量分数)聚碳酸酯(PC)于聚对苯二甲酸乙二醇酯(PET)中,在研究PET/PC共混体系高压结晶行为的过程中快速合成了大量生长厚度超过100 m 的聚合物伸直链晶体,并采用扫描电子显微镜对其进行了深入研究。研究表明,高压结晶PET/PC共混体系中存在不同类型的大尺寸伸直链晶体:完善的伸直链晶体、沿平行或垂直于C轴方向发生断裂的伸直链晶体、内聚能密度较大而发生内聚破裂的伸直链晶体、不同断裂方式下呈不同形态的楔形状伸直链晶体以及弯曲的伸直链晶体。同时对不同形态伸直链晶体的形成机理作了阐述。
-
关键词:
- 聚对苯二甲酸乙二醇酯 /
- 聚碳酸酯 /
- 高压结晶 /
- 伸直链晶体
Abstract: Large polymer extended-chain crystals have an important role that cannot be replaced in the study on low dimensional systems of physics. However, the small size of polymer extended-chain crystals that formerly had to be obtained through a long time confined their effect. Adding 10% (mass fraction) PC to PET, we obtained plenty of polymer extended-chain single crystals with C axis thickness exceeding 100 m during the study on the high-pressure crystallization behaviors of PET/PC blends with a self-made piston-cylinder apparatus. For the first time, scanning electron microscope was employed to analyze them in a deep-going way. Large extended-chain crystals with various morphologies were observed by SEM, i. e. perfect extended-chain crystals, extended-chain crystals fractured along or perpendicular to C axis, extended-chain crystals with cohesive fracture surfaces, different wedge-shaped extended-chain crystals on different fracture surfaces and bending extended-chain crystals. Some mechanisms were also put forward for the formation of the observed large crystals. -
Wunderlich B, Arakawa T. Polyethylene Crystallized from the Melt under Elevated Pressure [J]. Journal of Polymer Science, 1964, A2: 3697-3706. Wunderlich B, Melillo L. Surface Recrystallization of Polyethylene Extended-Chain Crystals [J]. Science, 1966, 154: 1329-1330. Hatakeyama T, Kanetsuna H, Hashimoto T. Large Polyethylene Crystals Formed under High Pressure [J]. Journal of Macromolecular Science-Physics, 1973, B7: 411-415. Gogolewski S. A Possible Mechanism of Chain Extension in Nylon-6 during Crystallization under Pressure [J]. Polymer, 1977, 18: 63-68. Miyamoto Y, Nakafuku C, Takemura T. Crystallization of Poly(Chlorotrifluoroethylene) [J]. Polymer Journal, 1972, 3: 122-128. Ohigashi H, Hattori T. Improvement of Piezoelectric Properties of Poly(Vinylidene Fluoride) and Its Copolymers by Crystallization under High Pressures [J]. Ferroelectrics, 1995, 171: 11-32. Hattori T, Hikosaka M, Ohigashi H. The Crystallization Behaviour and Phase Diagram of Extended-Chain Crystals of Poly(Vinylidene Fluoride) under High Pressure [J]. Polymer, 1996, 37: 85-91. Siegmann A, Harget P J. Melting and Crystallization of Poly(Ethylene Terephthalate) under Pressure [J]. Journal of Polymer Science: Polymer Physics Edition, 1980, 18: 2181-2196. Li L, Huang R, Lu A, et al. High Pressure Crystallized Poly(Ethylene Terephthalate): High Crystallinity and Large Extended-Chain Crystals [J]. Polymer, 2000, 41: 6943-6947. Li L, Huang R, Hong S. Sintering Polymer Nano-Crystals at High Pressure [J]. Journal of Materials Science Letters, 2001, 20: 807-809. Li L, Huang R, Wang C, et al. The High-Pressure Crystallization and Annealing Behaviors of Polyethylene Terephthalate Oligomer [J]. Journal of Macromolecular Science-Physics, 2001, B40(6): 1169-1178. Li L, Wang C, Huang R, et al. Morphology of High-Pressure Crystallized Poly(Ethylene 2, 6-Naphthalate) [J]. Polymer, 2001, 42: 8867-8872. L J, Huang R, Li L, et al. Growth of Large Polymer Extended-Chain Single Crystals in a Poly (Ethylene Terephthalate)/Bisphenol a Polycarbonate Blend under High Pressure [J]. Macromolecular Rapid Communications, 2005, 26: 1478-1482. L J, Wang X L, Huang R, et al. Effect of Transesterification on High-Pressure Crystallization Behaviour of PET/PC Blend System [J]. Chemical Journal of Chinese Universities, 2005, 26(8): 1556-1560. (in Chinese) 吕军, 王选伦, 黄锐, 等. PET/PC共混体系的酯交换反应对其高压结晶行为的影响 [J]. 高等学校化学学报, 2005, 26(8): 1556-1560. L J, Wei G, Huang R, et al. Observation of Novel Spherulitic Morphology Formed in Extended-Chain Crystals in High-Pressure Crystallized PET/PC Blends [J]. Chemical Journal of Chinese Universities, 2005, 26(12): 2391-2393. (in Chinese) 吕军, 魏刚, 黄锐, 等. 高压结晶PET/PC共混体系中生长在伸直链晶体内部球晶形态的观察 [J]. 高等学校化学学报, 2005, 26(12): 2391-2393. L J, Huang R, Chen Y, et al. Extended-Chain Crystals in High-Pressure Crystallized Poly(Ethylene Terephthalate)/Bisphenol a Polycarbonate Blends [J]. Journal of Polymer Science Part B: Polymer Physics, 2006, 44: 3148-3156. Keller A, Goldbeck-Wood G, Hikosaka M. PolymerCrystallization: Survey and New Trends with Wider Implications for Phase Transformation [J]. Faraday Discussions, 1993, 95: 109-128. Wunderlich B. Macromolecular Physics(1)-Crystal Structure, Morphology, Defects [M]. New York: Academic Press, 1973. Liangbin L, Rui H, Ling Z, et al. A New Mechanism in the Formation of PET Extended-Chain Crystals [J]. Polymer, 2001, 42: 2085-2089.
