水中障碍物爆炸毁伤效应的二维数值模拟

郝莉; 宁建国; 王成

doi:10.11858/gywlxb.2006.01.009

水中障碍物爆炸毁伤效应的二维数值模拟

doi: 10.11858/gywlxb.2006.01.009

1.
北京建筑工程学院基础部，北京 100044；
2.
北京理工大学爆炸科学与技术国家重点实验室，北京 100081

详细信息

通讯作者:
郝莉

计量
- 文章访问数: 7332
- HTML全文浏览量: 336
- PDF下载量: 927
出版历程
- 收稿日期: 2004-11-16
- 修回日期: 2005-01-11
- 发布日期: 2006-03-05

2D Numerical Simulation of Explosive Damage Effect on Obstacles in Water

1.
Beijing Institute of Civil Engineering and Architecture, Beijing 100044, China;
2.
State Key Laboratory of Explosion Science and Technology, Beijing Institute of Technology, Beijing 100081, China

More Information

Corresponding author: HAO Li

摘要

摘要: 建立了水下障碍物的爆炸毁伤效应的物理模型和计算模型。建立了守恒方程组、混凝土的动态弹塑性本构关系和破坏准则，并确定了其在大应变、高应变率及高压条件下的的屈服准则。基于多物质流体的Euler算法，用面向对象的C++语言自行编制了NM-MMIC通用多物质二维流体弹塑性程序，对不同炸点位置、不同炸药量对轨条砦爆炸破坏过程进行数值模拟，并采用自行开发的后处理软件VISC2D实现了可视化，定量地反应了障碍物迎爆面所承受的压力变化过程，确定了轨条砦毁伤的最佳药量，并对毁伤程度进行了评价，得到了爆炸破障的毁伤规律。研究结果对设计和评价反水中障碍物的弹药具有一定的参考价值。
- 爆炸力学 /
- 毁伤效应 /
- 数值模拟
Abstract: The physical and computational models of explosive damage effect of obstacles in water are proposed. The conservation equations, the dynamic elastic-plastic constitutive relation and damaging criterion of concrete are established, together with the yielding criterion subjected to large strains, high strain rates and high pressures. Meanwhile, based on the multi-material Eulerian algorithm, the NM-MMIC code, which is a general 2D multi-material elastic-plastic hydrodynamics code with C++ language, is applied to simulate the damaging effects of obstacles in water by explosion with different charges and at different positions. The whole process of underwater explosion are visualized by VISC2D code. The pressure variation of the side of the obstacle facing to the explosive are demonstrated quantitatively. The optimum damage charge is obtained. The damaging degree, and the damage laws of the obstacle in water are evaluated. These results are valuable in designing and estimating ammunitions against obstacles in water.
- explosion mechanics /
- damaging effect /
- numerical simulation

HTML全文

参考文献(12)

Hao L. Theoretical Foundation and Its Application of Two Dimension Hydro-Elastoplastic Code in Multi-Material [D]. Beijing: Beijing Institute of Technology, 2003. (in Chinese)

郝莉. 多物质二维流体弹塑性程序的理论基础及其应用研究 [D]. 北京: 北京理工大学, 2003.

Ning J G, Chen L W. Fuzzy Interface Treatment in Eulerian Method [J]. Science in China, Ser E, Engineering ＆ Materials Science, 2004, 47(5): 550-568.

Hao L, Ma T B, Ning J G. Numerical Simulation of a Shaped Charge Jet [J]. Transactions of Beijing Institute of Technology, 2003, 23(1): 19-22. (in Chinese)

郝莉, 马天宝, 宁建国. 聚能射流问题的数值模拟 [J]. 北京理工大学学报, 2003, 23(1): 19-22.

Xu X Sh, Zhang W X. Theoretical Introduction to Equation of State [M]. Beijing: Science Press, 1986: 405-408. (in Chinese)

徐锡申, 张万箱. 实用物态方程理论导引 [M]. 北京: 科学出版社, 1986: 405-408.

Henrych J. Explosion Dynamics and Its Applications [M]. Beijing: Science Press, 1987: 154.

Henrych J. 爆炸动力学及其应用 [M]. 北京: 科学出版社, 1987: 154.

Holmquist T J, Johnson G R. A Computational Constitutive Model for Concrete Subjected to Large Strains, High Strain Rates and High Pressures [A]. //14th International Symposium on Ballistics [C]. Quebec, Canada, 1993: 591-600.

Guo W Zh. Study on Damage Effect of Underwater Obstruct by Blasting [R]. Beijing: Beijing Institute of Technology, 2000. (in Chinese)

郭文章. 水中障碍的爆炸毁伤效应研究 [R]. 北京: 北京理工大学, 2000.
