摘要: 用一级轻气炮冲击加载装置,对氮化硅陶瓷进行了冲击性能实验研究。发展了一种新的方法用于研究层裂特性,即通过在样品中埋设电磁粒子速度计来记录氮化硅陶瓷内部的层裂特性。该方法不同于常用的VISAR激光干涉法和锰铜计法,记录的是样品内部粒子速度的变化特征,位于层裂面后方的粒子速度计能清晰地表征材料的层裂特性。通过实验,得到了密度为3.12 g/cm3的氮化硅陶瓷的层裂强度为0.73 GPa,和Nahme等得到的强度较为接近,对称碰撞得到的裂片厚度与该次实验的飞片厚度相当。实验表明,电磁粒子速度计的方法可以用于研究非磁屏蔽材料的层裂特性。由于采用多个计进行记录,还得到了材料在弹性区内(1.8~3.6 GPa)的Hugoniot冲击绝热线。
-
关键词:
- 氮化硅 /
- 层裂 /
- 粒子速度计 /
- Hugoniot冲击绝热线
Abstract: Shock behavior of silicon nitride ceramic was investigated by using a onestage light gas gun facility. A new technique is developed to measure the spall characteristics of materials with embedded electro-magnetic particle velocity gauges in the sample. This method measures the particle velocity profiles inner the sample and particularly, the gauge located behind the spalling plane will disclose clearly the message of spallation of the sample, which differs from the usual methods such as VISAR and manganin gauge. By this method, we obtained experimentally the spall strength of silicon nitride ceramic of density 3.12 g/cm3 as 0.73 GPa, which fit the data of Nahme et al. The scab thickness was almost equal to the flyer thickness in the experiments, since the symmetry impact was used. The experimental results indicate that the particle velocity gauge method can be used to study the spllation behavior of non-electromagnetism materials. Since we used three gauges in one shot to record velocity profiles at different locations, so the Hugoniot data up to 3.6 GPa (as in elastic range) was also obtained.-
Key words:
- silicon nitride /
- spalling /
- particle velocity gauge method /
- Hugoniot curve
-
Liu F M, Li Y L, Guo W G, et al. Dynamic Damage Capability Research of the Silicon Nitride [J]. Journal of Xi'an Univ of Arch Tech, 1995, 27(4): 339-441. (in Chinese) 刘发民, 李玉龙, 郭伟国, 等. 氮化硅陶瓷动态损伤性能研究 [J]. 西安建筑科技大学学报, 1995, 27(4): 339-441. Yuan J, Shioya T. Study of Dynamic Behavior of Dense Silicon Nitride Ceramics at Elevated Temperature [J]. J Phys(IV: JP), 1997, 7(2): 367-372. Fujii K, Noma T, Masamura O, et al. Dynamic Mechanical Properties of Materials Measured by Plate Impact Experiments (Si3N4, SiC and TiB2) [J]. JSME Int J(Series A), 2001, 44(2): 251-258. Nahme H, Hohler V, Stilp A. Determination of the Dynamic Material Properties of Shock Loaded Silicon-Nitride [J]. High Pressure Sci and Tech, 1994, 309: 765-768. Rosenberg Z Z, Yaziv D, Bless A. Spall Strength of Shock-Loaded Glass [J]. J Appl Phys, 1985, 58(8): 3249-3251. Zhang W J, Yang Z Z. Studies on the Fracture Behaviour for 93 Tungsten Alloy [J]. Chinese Journal of High Pressure Physics, 1995, 9(4): 279-288. (in Chinese) 张万甲, 杨中正. 93钨合金断裂特性研究 [J]. 高压物理学报, 1995, 9(4): 279-288. Zeng Y J, Jing F Q, Zhang W J. Study on the Spallation Behavior of Tungsten Alloy [J]. Chinese Journal of High Pressure Physics, 1992, 6(1): 58-67. (in Chinese) 曾元金, 经福谦, 张万甲. 钨合金的层裂强度研究 [J]. 高压物理学报, 1992, 6(1): 58-67. Vesser L R, Hixson R S, Vorthman J E, et al. Spall Strength and Shock Release Kinetics Following the Alpha-Epsilon Phase Transition in Iron [R]. California: University of California, 1999-2000. 140-145. Zhang L, Cai L C, Wang W, et al. The Dynamic Mechanic Characteristics of Tantalum under Shock Loading [J]. Chinese Journal of High Pressure Physics, 2001, 15(4): 265-270. (in Chinese) 张林, 蔡灵仓, 王悟, 等. 钽在冲击载荷下的动态力学特性 [J]. 高压物理学报, 2001, 15(4): 265-270. Tang Z P, Hu X J, Liao X L, et al. An Experimental Facility for Measuring Longitudinal and Shear Waves with Dual Magnetic Fields [J]. Journal of Experimental Mechanics, 2000, 15(1): 16-21. (in Chinese) 唐志平, 胡晓军, 廖香丽, 等. 双磁场IMPS粒子速度测试系统 [J]. 实验力学, 2000, 15(1): 16-21.
