摘要: 通过高速录像对3种量级(5、20、50 kg)FAE装置的静爆实验进行了现场记录,通过对燃料爆炸抛撒形成云雾的成长过程的实时记录结果,把燃料的爆炸抛撒过程分为3个阶段:喷出阶段、过渡阶段和膨胀阶段,其依据是爆炸驱动力和气动阻力的相互作用而导致的云雾径向膨胀速度的变化;对于结构相似的FAE装置,爆炸抛撒各阶段结束时刻及最终的云雾直径与装填燃料量的立方根成正比,说明小型装置可以模拟大型FAE武器;此外对应于不同阶段结束时刻的云雾直径与装置直径的比值分别为5.5、30和45。Abstract: Local records of static explosion were taken by the high-speed video for the 3 kinds of FAE devices. On the analysis of experimental data, the process of fuel explosive dispersion was divided into three regimes: Ejection stage, transition stage and expansion stage, based on the radical expanded velocity caused by explosion acting force and aerodynamic force. For FAE devices with similar structure, according to the experiment data obtained from high-speed video, we got that end-time of different stages and cloud diameters before detonation were proportional to the cube root of fuel quantity, which illuminated that small device can simulate big FAE device. The ratios of cloud diameter to device diameter were 5.5, 30 and 45 at the end moment of different stages, respectively.
-
Key words:
- high speed video /
- fuel /
- explosive dispersion /
- experimental study
-
Borisov A A. Research on the Explosive Dispersion of FAE [R]. Report in NUST, 1995. Gardner D R. Near-Field Dispersal Modeling for Liguid Fuel-Air Explosives [R]. SAND90-0686, 1990. Glass M W. Far-Field Dispersal Modeling for Liquid Fuel-Air Explosive [R]. SAND90-0687, 1991. McGlaun J M. CTH Manual [R]. SAND88-0523, 1988. Ding J, Liu J C, Peng J H. Numerical Study on the Explosively Dispersed Liquid Fuel in the Near-Field [J]. Explosion and Shock Waves, 2000, 20(3): 215-220. ( in Chinese) 丁珏, 刘家骢, 彭金华. 液体燃料爆炸抛撒近场阶段的数值研究 [J]. 爆炸与冲击, 2000, 20(3): 215-220. Xue S S, Liu J C, Qin C S, et al. Experimental and Numerical Investigation on Explosive Dispersal and Cloud Forming [J]. Explosion and Shock Waves, 2001, 21(4): 272-276. ( in Chinese) 薛社生, 刘家骢, 秦承森, 等. 燃料爆炸抛撒成雾的实验与数值研究 [J]. 爆炸与冲击, 2001, 21(4): 272-276. Guo X Y, Hui J M. Influence on the Ratio of Height to Diameter on FAE Cloud Status [J]. Chinese Journal of Explosives and Propellants, 2002, 25(4): 8-10. ( in Chinese) 郭学永, 惠君明. 长径比对FAE云雾状态的影响研究 [J]. 火炸药学报, 2002, 25(4): 8-10. Guo X Y, Hui J M. Influence of Equipment Parameters on FAE Cloud Status [J]. Energetic Materials, 2002, 10(4): 161-164. (in Chinese ) 郭学永, 惠君明. 装置参数对FAE云雾状态的影响 [J]. 含能材料, 2002, 10(4): 161-164. Zabelka R J, Smith L H. Explosively Dispersal Liquids [R]. AD-863268, 1969. Xie S S. Liu J C, Peng J H. Study on the Explosively Dispersed Liquid Fuel in the Near-Field [J]. Journal of Nanjing University of Science and Technology, 1997, 21(4): 333-336. (in Chinese ) 薛社生, 刘家骢, 彭金华. 液体燃料爆炸抛撒的近场阶段研究 [J]. 南京理工大学学报, 1997, 21(4): 333-336. Feng W. Numerical Simulation in the Near-Field of FAE [D]. Nanjing: NUST, 2000. (in Chinese ) 冯伟. 燃料空气炸药近场抛撒数值模拟 [D]. 南京: 南京理工大学, 2000.
