PDC材料烧结过程中钴在金刚石层中的扩散熔渗迁移机制

邓福铭; 陈启武

doi:10.11858/gywlxb.2004.01.010

PDC材料烧结过程中钴在金刚石层中的扩散熔渗迁移机制

doi: 10.11858/gywlxb.2004.01.010

邓福铭^1,,
陈启武^1,2

1.
中国矿业大学（北京校区）材料科学与工程系，北京 100083；
2.
长沙矿冶研究院，湖南长沙 410012

详细信息

通讯作者:
邓福铭

计量
- 文章访问数: 7670
- HTML全文浏览量: 323
- PDF下载量: 927
出版历程
- 收稿日期: 2003-04-30
- 修回日期: 2003-09-08
- 发布日期: 2004-03-05

Diffusion and Infiltration Mechanisms of Cobalt through Diamond Layer during the Sintering of Polycrystalline Diamond Compacts

DENG Fu-Ming^1
,,
CHEN Qi-Wu^1,2

1.
Department of Materials Science and Engineering, Beijing Campus, China University of Mining and Technology, Beijing 100083, China;
2.
Changsha Institute of Mining and Metallurgy, Changsha 410012, China

More Information

Corresponding author: DENG Fu-Ming

摘要

摘要: 讨论了PDC材料烧结过程中钴在金刚石层中的固相扩散、钴液熔渗、两次钴高浓度峰的波浪式迁移过程中的运动规律及其作用机制，并根据实验观测的数据进行了有关计算。结果表明：在5.8 GPa、1 300 ℃条件下，钴的扩散系数D1.610-7 cm2/s，是一般常压及相同温度条件下钴固相扩散系数（310-10 cm2/s）和相同压力条件下钴的液相扩散系数（510-5 cm2/s）的中间值；对于粒度W10 m的金刚石烧结体系，钴液熔渗作用时间非常短暂，略大于0.5 s，而对于W1 m的超细金刚石烧结体系而言，钴熔渗作用时间为28 s，比粒度W10 m的金刚石烧结要长得多；两次钴高浓度峰的迁移速度分别约为50 m/s和100 m/s。
- 聚晶金刚石复合片（PDC） /
- 烧结 /
- 扩散 /
- 熔渗
Abstract: The mechanisms of solid cobalt diffusion, molten cobalt infiltration and two wave-like cobalt peaks movement through diamond layer during the sintering process were discussed theoretically according to the experiment data. Results show that the solid cobalt diffusion coefficient under 5.8 GPa and at 1 300 ℃ is about 1.610-7 cm2/s, which is almost the mean value between the solid cobalt diffusion coefficient (310-10 cm2/s) at the same temperature under atmospheric pressure and the liquid cobalt diffusion coefficient (510-5 cm2/s) under 5.8 GPa and at 1 300 ℃. It also shows that the infiltration time of molten cobalt through diamond layer for diamond grain size 10 m and 1 m are about 0.5 s and 28 s respectively, and the moving velocity of the two wave-like cobalt peaks were about 50 m/s and 100 m/s, respectively.
- polycrystalline diamond compacts (PDC) /
- sintering /
- diffusion /
- infiltration

HTML全文

参考文献(16)

Katzman H, Libby W F. Sintered Diamond Compacts with a Cobalt Binder [J]. Science, 1971, 172: 1132-1134.

Wentorf R H. Diamond Tools for Machining [P]. USP3, 745, 623.

Gigl P D. Sweep through Process for Making Polycrystalline Diamond Compacts [P]. USP 4, 518, 659.

Deng F M, Ma F, Chen Q W. Diffusion and Infiltration Process of Cobalt through Diamond Layer during the Sintering of Polycrystalline Diamond Compact [J]. Journal of Synthetic Crystals, 2003, 32(4): 185-189. (in Chinese)

邓福铭, 马峰, 陈启武. PDC 材料烧结中钴在金刚石层中的扩散熔渗迁移过程研究 [J]. 人工晶体学报, 2003, 32(4): 185-189.

Smithells. Metals Reference Book, Vol. 1(2nd ed) [Z]. Pittsburgh: Carnegie Press, 1985. 422.

Ding L Y, Luo X J, Wakatsuki M, et al. Transportation of Carbon in High Pressure Flux and Its Effect on Diamond Growth [J]. Chinese Journal of High Pressure Physics, 1994, 8(2): 146-152. (in Chinese)

丁立业, 罗湘捷, 若木规雅男, 等. 金刚石生长的高压溶剂中碳的运输及其影响 [J]. 高压物理学报, 1994, 8(2): 146-152.

Hou Z S, Lu G X. Principles of Metals and Alloys [M]. Shanghai: Shanghai Science and Technology Press, 1993. 118. (in Chinese).

候增寿, 卢关熙. 金属学原理 [M]. 上海: 上海科学技术出版社, 1993. 118.

Deng F M, Chen Q W, Huang P Y. On the Crushing Rules of Diamond Powders under Ultra High Pressure [J]. Superhard Material Science and Engineering, 1998, 4: 9-15(in Chinese).

邓福铭, 陈启武, 黄培云. 金刚石粉末超高压挤压破碎规律研究 [J]. 超硬材料与工程, 1998, 4: 9-15.

Елютин В Л, Поляков ВЛ, Шалимов М Д, н　бр. Исследование Процесса Образования　Поликристаллических　Алмазов[J]. Химическая　Технология, 1984, 275(1): 135-139.

Наёдич Ю В, Колесниченко Г А. The Interaction between Molten Metals and Diamond or Graphite(translated by Lu Z T) [J]. Journal of Synthetic Crystals, 1978, 11(1): 15-71 (in Chinese). 奈基奇 Ю В, 科列斯尼钦科 Г А. 熔融金属与金刚石和石墨表面的相互作用(续)(卢照田译) [J]. 人工晶体, 1978, 11(1): 15-71.

Xu J A, Zhao Y X. On Machanism of the Movement of Metallic Catalyst during the Growth Process of Polycrystalline Diamond [J]. Physics, 1976, 18(5): 479-482. (in Chinese).

徐济安, 赵有祥．多晶金刚石生长中金属触媒推移现象的机制 [J]. 物理, 1976, 18(5): 479-482.
