摘要: 从声速的定义出发,由热力学基本关系给出了声速温度系数(偏微商)的一种计算方法,以顽火辉石为例,计算结果显示,在40~140 GPa压力范围内,其纵波、剪切波和体波的温度系数随压力的增大而逐渐减小,分别由40 GPa时的-0.386、-0.251、-0.255 m/(sK)降至80 GPa时的-0.298、-0.188、-0.204 m/(sK),120 GPa时的-0.244、-0.148、-0.175 m/(sK)和140 GPa时的-0.197、-0.131、-0.162 m/(sK)。将这一规律内推至零压得到(dK/dT)0=-0.027 9 GPaK-1,与静高压下的实验值吻合很好。Abstract: A method to calculate the temperature coefficients of sound velocity at high pressure were given, in terms of the definition of sound velocity and thermodynamics. For perovskite-enstatite, the calculated temperature coefficients of compression, shear and bulk wave velocities decease from 0.386, 0.251, 0.255 m/(s#8226;K) at 40 GPa to 0.298, 0.188, 0.204 m/(s#8226;K) at 80 GPa, 0.244, 0.148, 0.175 m/(s#8226;K) at 120 GPa and 0.197, 0.131, 0.162 m/(s#8226;K) at 140 GPa, respectively. Extrapolating these to zero pressure gives (dK/dT)0=-0.027 9 GPaK-1,which is consistent well with the value from hydrostatic experiment.
-
Duffy T S, Ahrens T J. Sound Velocities at High Pressure and Temperature and Their Geophysical Implications [J]. J Geophys Res, 1992, 97(B4): 4503-4520. Duffy T S, Ahrens T J. The Temperature Sensitivity of Elastic Wave Velocity at High Pressure: New Results for Molybdenum [J]. Geophys Res Lett, 1994, 21: 473-476. Anderson O L, Masuda K, Isaak D G. A New Thermodynamic Approach for High Pressure Physics [J]. Phys Earth Planet Inter, 1995, 89: 35-45. Anderson O L, Chopelas A, Boehler R. Thermal Expansion versus Pressure at Constant Temperature [J]. Geophys Res Lett, 1990, 17: 685-688. Anderson O L, Masuda K, Isaak D G. Limits on the Value of T and for MgSiO3 Perovskite [J]. Phys Earth Planet Inter, 1996, 98: 31-46. 经福谦. 实验物态方程导引 [M]. 北京: 科学出版社, 1986: 323. Liu L G. Orthorhomic Perovskite Phases Observed in Olivine, Pyroxene, and Garnet at High Pressures and Temperatures [J]. Phys Earth Planet Inter, 1976, 11: 289-298. Knittle EJeanloz R. Synthesis and Equation of State of(Mg, Fe)SiO3 Perovskite to over 100 GPa [J]. Science, 1987, 235: 668-670. Watt J P, Ahrens T J. Shock Wave Equation of State of Enstatite [J]. J Geophys Res, 1986, 91(B7): 7495. Stixrud L, Hemley R J, Fei Y, et al. Thermoelasticity of Silicate Perovskite and Magnesiowustite and Stratification of the Earth's Mantle [J]. Science, 1992, 257: 1099-1101. Wang Yan-bin, Weidner D J, Liebermann R C, et al. p-K-T Equation of State of (Mg, Fe)SiO3 Perovskite: Constraints on Composition of the Lower Mantle [J]. Phys Earth Planet Inter, 1994, 83: 13-40. Funamori N, Yagi T, Utsami W, et al. Thermoelastic Properties of MgSiO3 Perovskite Determined by Insitu X-Ray Observations up to 30 GPa and 1000 K [J]. J Geophys Res, 1996, 101: 8257-8269. Utsami W, Funamori N, Yagi T, et al. Thermal Expansitivity of MgSiO3 Perovskite under High Pressure up to 20GPa [J]. Geophys Res Lett, 1995, 22: 1005-1008. Guillaume Fiquet, Andrault D, Dewaele A, et al. p-V-T Equation of State of MgSiO3 Perovskite [J]. Phys Earth Planet Inter, 1998, 105: 21-31. Gong Zi-zheng, Xie Hong-sen, Jing Fu-qian, et al, High-Pressure Sound Velocity of Perovskite-Enstatite and Possible Composition of Earth's Lower Mantle [J]. Chin Phys Lett, 1999, 16(9): 696-697. Hama J, Suito K. Equation of State of MgSiO3 Perovskite and Its Thermoeiastic Properties under Lower Mantle Conditions [J]. J Geophys Res, 1998, 103(B4): 7443-7462. Anderson O L, Koji Masuda, Guo Dawei. Pure Silicate Perovskite and the PREM Lower Mantle Model: A Thermodynamic Analysis [J]. Phys Earth Planet Inter, 1995, 89: 35-49.
