弹性撞击速度的激光分束测量技术

张光军; 田常津; 何鹏

doi:10.11858/gywlxb.1997.02.014

弹性撞击速度的激光分束测量技术

doi: 10.11858/gywlxb.1997.02.014

中国工程物理研究院结构力学研究所，四川成都 610003

详细信息

通讯作者:
张光军

计量
- 文章访问数: 7004
- HTML全文浏览量: 321
- PDF下载量: 637
出版历程
- 收稿日期: 1996-05-08
- 修回日期: 1996-07-25
- 发布日期: 1997-06-05

The Projectile Impacting Velocity Measurement Technique with Splitting Laser Beams

Southwest Institute of Structural Mechanics, Chengdu 610003, China

More Information

Corresponding author: ZHANG Guang-Jun

摘要

摘要: 研制了一个激光分束测速系统。它由一台4mW He-Ne激光器，一个将单束激光分成10束相互平行的等间距（间距为5 mm）激光的分光器，一个高灵敏度、工作状态自检、可进行波形合成、10路接受、一路输出的光电接收转换装置，一台数字存贮示波器，以及微型计算机组成。可进行弹性撞击速度的测量。
- 激光分束 /
- 速度测量
Abstract: We designed and developed an element, which can split a single laser beam produced by a He-Ne laser device of 4 mV power into ten paralleled laser beams with an equal space-distance of 5 mm between each beam pair. We have developed a photo-electric transformer, which is of high sensitivity, waveform synthesized and has a single output channel. When combined with the digital oscilloscope and personal computer, we have the system can be used to measure the impacting velocity of the projectile launched by a gas gun.
- laser beam splitter /
- velocity measurement

HTML全文

参考文献(4)

王礼立, 等. 冲击动力学进展. 合肥: 中国科学技术大学出版社, 1991: 217-240.

刘振玉. 光电技术. 北京: 北京理工大学出版社, 1992: 85-102.

袁希光. 传感技术应用手册. 北京: 国防工业出版社, 1986: 711-747.

Tian Changjin. Experimental Investigations of the Scaling Laws for Circular Plate Structure by Projectiles. In: Proceedings of Iutam Symposium on Impact Dynamics. Beijing, 1993.
