A Diamond Anvil Cell with External Heater and Pressure Measurement by Using Ruby at High Temperature
-
摘要: 本文报导了一种外加热型金刚石对顶压砧装置的高温高压技术,装置的压力可达20 GPa,温度可达350 ℃。采用本装置对六角结构的-LiIO3进行了高温高压X射线衍射实验,获得的四方结构高压相与用淬火卸压所得的相结构一致;建立了高温下的红宝石测试技术。发现可以根据由此法测定的p-T曲线初步判别样品是否存在伴随有体积变化的结构相变,并可估计出该相变的压力、温度范围及相变造成的压力下降值。Abstract: The techniques of diamond anvil cell used in our laboratory with external heater under high pressure and high temperature are described in this paper. The pressure and the temperature can be up to 20 GPa and 350 ℃, respectively. The high pressure phase of LiIO3, phase has been determined in situ by using X-ray diffraction analysis in this device. The pressure measurement with ruby at high temperature in this device is discussed. According to the LiIO3 data of X-ray diffraction analysis, it is shown that the dropping part of p-T curve is corresponding to the occurrence of to phase transition of LiIO3 under high pressure and high temperature. We suppose that one can estimate the phase transition temperature and pressure as well as the decreasing value of pressure caused by phase transition from p-T curve for some materials.
-
沈中毅, 张云. 科学通报, 1981, 26: 913. 胡静竹, 陈良辰, 王莉君, 等. 物理学报, 1987, 36: 1099. Decker D L. J Appl Phys, 1971, 42: 3239. Barnett J D, Bloch S, Piemarini G J. Rev Sci Instrum, 1973, 44: 1. 山冈信夫, 下村理, 福长脩. 第20回高压讨论会讲演要旨集, 119. Wunder S L, Schoen P E. J Appl Phys, 1981, 52: 3772.
