摘要: 运用金刚石对顶砧(Diamond Anvil Cell,DAC)技术,以液氩作为传压介质,在最高压力为67 GPa的压力范围内对NiO进行了原位的同步辐射X射线衍射研究。在整个实验过程中,并未发现第一类结构相变,也没有发现T.Sasaki等预测的在60 GPa左右轴比c/a随压力的变化率而突然增大的现象,且此压力范围内NiO的结构畸变程度随压力的变化趋势相比以前的研究结果要平缓一些。用三阶的Brich-Murnaghan方程对实验数据进行拟合,得到的体弹模量及其对压力的一阶导数分别为B0=195(4) GPa和B0=5.3(2)。Abstract: The high-pressure structure and isothermal equation of state of NiO were investigated up to 67 GPa by in situ synchrotron X-ray diffraction in a diamond anvil cell using argon as the pressure medium. No phase transition was found in this pressure range, nor the the pressure coefficient of axial ratio c/a became larger suddenly at about 60 GPa which was predicted by T.Sasaki. Our experiments showed that the distortion of the structure under pressure was slacker than previous results. We fit the data points to the three-order Brich-Murnaghan EOS, which resulted in a bulk modulus of B0=195(4) GPa with its pressure derivative B0=5.3(2).
-
Key words:
- NiO /
- diamond anvil cell /
- X-ray diffraction /
- crystal structure /
- EOS
-
Cohen R E, Mazin I I, Issak D G. Magnetic Collapse in Transition Metal Oxides at High Pressure: Implications for the Earth [J]. Science, 1997, 275: 654-657. Fang Z, Terakura K, Sawada H, et al. Inverse versus Normal NiAs Structures as High-Pressure Phases of FeO and MnO [J]. Phys Rev Lett, 1998, 81: 1027-1030. Yoo C S, Maddox B, Klepeis J H P, et al. First-Order Isostructural Mott Transition in Highly Compressed MnO [J]. Phys Rev Lett, 2005, 94: 115502-(1)-115502-(7). Cheetham A K, Hope D A O. Magnetic Ordering and Exchange Effects in the Antiferromagnetic Solid Solution MnxNi1-xO [J]. Phys Rev B, 1983, 27: 6964-6967. Svane A, Gunnarsson O. Transition-Metal Oxides in the Self-Interaction-Corrected Density-Functional Formalism [J]. Phys Rev Lett, 1990, 65: 1148-1151. Anisimov V I, Zaanen J, Ansersen O K. Band Theory and Mott Insulators: Hubbard U Instead of Stoner I [J]. Phys Rev B, 1991, 44: 943-954. Aryasetiawan A F, Gunnarsson O. Electronic Structure of NiO in the GW Approximation [J]. Phys Rev Lett, 1995, 74: 3221-3324. Dudarev S L, Botton G A, Savrasov S Y, et al. Electron-Energy-Loss Spectra and the Structural Stability of Nickel Oxide: An LSDA+U Study [J]. Phys Rev B, 1998, 57: 1505-1509. Rohrbach A, Hanner J, Kresse G. Molecular Adsorption on the Surface of Strongly Correlated Transition-Metal Oxides: A Case Study for CO/NiO(100) [J]. Phys Rev B, 2004, 69: 075413-(1)-075413-(13). Schuler T M, Ederer D L, Itza-Ortiz S, et al. Character of the Insulating State in NiO: A Mixture of Charge-Transfer and Mott-Hubbard Character [J]. Phys Rev B, 2005, 71: 115113-(1)-115113-(7). Huang E. Compression Behavior of NiO in a Diamond Cell [J]. High Pressure Res, 1995, 13: 307-319. Noguchi Y, Uchino M, Hikosaka H, et al. Equation of State of NiO Studied by Shock Compression [J]. J Phys Chem Solids, 1999, 60: 509-514. Eto T, Endo S, Imai M, et al. Crystal Structure of NiO under High Pressure [J]. Phys Rev B, 2000, 61: 14984-14988. Sasaki T. Lattice Distortion of NiO under High Pressure [J]. Phys Rev B, 1996, 54: R9581-R9584. Zhang W B, Hu Y L, Han K L, et al. Structural Distortion and Electronic Properties of NiO under High Pressure: An ab initio GGA+U Study [J]. J Phys: Condens Matter, 2006, 18: 9691-9701. Zhang W B, Hu Y L, Han K L, et al. Pressure Dependence of Exchange Interactions in NiO [J]. Phys Rev B, 2006, 74: 054421-(1)-054421-(5). Dubrovinsky L S, Belonoshko A B. Pressure-Induced Phase Transition and Structural Changes under Deviatoric Stress of Stishovite to CaCl2-Like Structure [J]. Geochimica et Cosmochimica Acta, 1996, 60: 3657-3663. Cao W, Krumhansl J A. Continuum Theory of 4 mm~2 mm Proper Ferroelastic Transformation under Inhomogeneous Stress [J]. Phys Rev B, 1990, 42: 4334-4340. Mao H K, Xu J, Bell P. Calibration of the Ruby Pressure Gauge to 800 kbar under Quasi-Hydrostatic Conditions [J]. J Geophys Res, 1986, 91: 4673-4676. Marsh S P. Los Alamos Shock Hugoniot Data [Z]. California: University of California Press, 1979. Yang H B, Li M H, Wang L Z. et al. High Pressure X-Ray Study on NiO Isothermal Equation of State up to 50 GPa [J]. Chinese Journal of High Pressure Physics, 1990, 4(4): 241-245. (in Chinese) 杨海滨, 李明辉, 王立中, 等. 50 GPa下NiO等温状态方程的高压X光研究 [J]. 高压物理学报, 1990, 4(4): 241-245. Clendenen R L, Drickamer H G. Lattice Parameters of Nine Oxides and Sulfides as a Function of Pressure [J]. J Chem Phys, 1965, 44: 4223-4338. Fei Y, Mao H K. In Situ Determination of the NiAs Phase of FeO at High Pressure and Temperature [J]. Science, 1994, 266: 1678-1680. Kondo T, Yagi T, Syono Y, et al. Phase Transitions of MnO under Static Compression [J]. Rev High Pressure Sci Technol, 1998, 7: 148.
