Numerical Simulation of Hypervelocity Launch of Flier Plate with Gradual Change Impedance
-
摘要: 为在轻气炮上实现二级飞片的超高速发射,设计了波阻抗连续变化的渐变阻抗飞片。变阻抗飞片撞击面为镁,底面为钨,中间为镁、铜和钨的掺合材料。建立了变阻抗飞片超高速发射的计算模型,采用分成单元层描述阻抗变化。对变阻抗飞片超高速发射二级飞片过程进行了数值模拟计算,分析了阻抗分布、二级飞片直径和缓冲层厚度对二级飞片速度的影响。结果表明:在优化阻抗分布、二级飞片直径和缓冲层厚度的条件下,二级飞片的最大速度能够达到16 km/s以上。Abstract: A graded density flier plate with gradual change impedance was designed to launch the secondary flier plate in hypervelocity on a light gas gun. The impact surface of graded-density flier plate was made of magnesium, the base surface was made of tungsten, and the middle part was made of the mixture of magnesium, copper and tungsten. A calculating model of hypervelocity launch was developed. The numerical simulations of hypervelocity launch with graded density flier plate were conducted.The effects of change law of impedance, diameter of secondary flier plate and thickness of buffer on the secondary flier plate velocity were analyzed. The calculated results indicated that the maximum velocity of the secondary flier plate exceeded 16 km/s in the condition of optimizing the change law of impedance of graded density flier plate, diameter of secondary flier plate, and thickness of buffer.
-
Timothy G, Trucano T C, Chhabildas L C. Computational Design of Hypervelocity Launchers [J]. Int J Impact Eng, 1995, 17: 849-860. Hua J S, Tan H, Dong Y B, et al. Theoretical Design of Hypervelocity Launcher [J]. Chinese Journal of High Pressure Physics, 1999, 13(4): 277-282. (in Chinese) 华劲松, 谭华, 董玉斌, 等. 超高速发射器的理论设计 [J]. 高压物理学报, 1999, 13(4): 277-282. Lin S M, Xu N X, Chen D Q. Numerical Simulation of Hypervelocity Launchers [J]. Chinese Journal of High Pressure Physics, 2000, 14(2): 139-145. (in Chinese) 林绍明, 徐南仙, 陈栋泉. 超高速发射装置数值模拟 [J]. 高压物理学报, 2000, 14(2): 139-145. Bai J S, Tan H, Li P, et al. Numerical Simulation Method for 2D Hypervelocity Launcher under the Graded Density Impactor Drives [J]. Chinese Journal of Computational Physics, 2004, 21(7): 305-310. (in Chinese) 柏劲松, 谭华, 李平, 等. 阻抗梯度飞片加载下的超高速发射二维数值模拟方法 [J]. 计算物理, 2004, 21(7): 305-310. Shen Q, Zhang L M, Wang C B, et al. Design and Optimization of Wave Impedance Distribution for Flyer Materials [J]. Acta Physica Sinica, 2003, 52(7): 1663-1667. (in Chinese) 沈强, 张联盟, 王传彬, 等. 梯度飞片材料的波阻抗分布设计与优化 [J]. 物理学报, 2003, 52(7): 1663-1667. Lawrence Livermore National Laboratory. LS-DYNA User's Manual (Nonlinear Dynamic Analysis of Structures in Three Dimensions) [Z]. California: University of California, Lawrence Livermore National Laboratory, 2001.
