高压、高应变率与低压、高应变率实验的本构关联性

陈大年; 刘国庆; 俞宇颖; 王焕然; 谢书港

doi:10.11858/gywlxb.2005.03.001

高压、高应变率与低压、高应变率实验的本构关联性

doi: 10.11858/gywlxb.2005.03.001

宁波大学力学与材料科学研究中心，浙江宁波 315211

详细信息

通讯作者:
陈大年

计量
- 文章访问数: 10781
- HTML全文浏览量: 794
- PDF下载量: 1177
出版历程
- 收稿日期: 2004-06-18
- 修回日期: 2005-03-23
- 发布日期: 2005-09-05

The Constitutive Relationship between High Pressure-High Strain Rate and Low Pressure-High Strain Rate Experiment

Mechanics & Materials Science Research Center, Ningbo University, Ningbo 315211, China

More Information

Corresponding author: CHEN Da-Nian

摘要

摘要: 指出Johnson-Cook（J-C）、Zerilli-Armstrong（Z-A）、Bodner-Parton（B-P）本构方程在一定条件下的适用性，表明对于低压、高应变率实验，单一曲线假定似乎可以采用。通过等效应力、等效应变，可以将不同应力状态下的流动应力函数采用统一的方程描述。然而，这些本构方程的确立，并不包括平面冲击波实验。对适合于平面冲击波实验的Steinberg-Cochran-Guinan（SCG）本构方程，讨论了其方程中所包含的高压与高应变率耦合效应。指出，以剪切模量度量的流动应力具有应变率相关性。基于温度效应的新发现以及直接测量平面冲击波流动应力的新进展，分别用J-C本构及SCG本构方程估算了钨材料在高压、高应变率加载下的流动应力。结果表明，采用J-C本构估算的流动应力仅在压力为10 GPa以下才能与实验数据相近，当压力高于10 GPa时，流动应力只能采用SCG本构估算。也指出了高压、高应变率本构方程与低压、高应变率本构方程所对应的不同物理背景。
- 本构方程 /
- 高压 /
- 高应变率
Abstract: It is indicated that the constitutive equations at high strain rates proposed by Johnson-Cook(J-C), Zerilli-Armstrong (Z-A) and Bodner-Parton (B-P) collapse the data of flow stress in compression, tension, torsion, and shear into simple curve with the scalar quatities 'effective' stress and 'effective' strain, however, the collapsed data of flow stress did not include the data in the planar shock wave tests. The SCG constitutive equation proposed by Steinberg et al for the planar shock wave tests is discussed, which describes the coupled high pressure and high strain rate effects on the plastic deformation of materials. Basing on the recent experiments at elevated temperatures and high strain rates and the shear strength measurements during shock loading, the flow stress for tungsten at high pressure and high strain rates is estimated with J-C and SCG constitutive equations, respectively. It is concluded that the J-C, Z-A and B-P constitutive equations may not be appropriate to describe the plastic behavior of materials at high pressure and high strain rates, comparing with SCG constitutive equation. It is emphasized that the physical background of the constitutive equation at high pressure and high strain rates is different from that at low pressure and high strain rates.
- constitutive equation /
- high pressure /
- high strain rate

HTML全文

参考文献(23)

Johnson G R, Cook W H. A Constitutive Model and Data for Metals Subjected to Large Strains, High Strain-Rates and High Temperatures [A]. Porc 7th Int Nat Symposium on Ballistcs [C]. The Hague, The Netherlands, 1983.

Zerilli F J, Armstrong R W. Dislocation-Mechanics-Based Constitutive Relations for Material Dynamics Calculations [J]. J Appl Phys, 1987, 61: 1816.

Bodner S R, Partom Y. Consitutive Equation for Elastic-Viscoplastic Srain-Hardening Materials [J]. J Appl Mech, 1975, 42: 385-389.

Asay J R. Shock Wave Paradigms and New Challenges [A]. Furnish M D, Thadhani N N, Norie Y. Shock Compression of Condensed Mater-2001 [C]. New York: Melville, 2002. 26-35.

Steinberg D J, Cochran S G, Guinan M W. A Constitutive Model for Metals Applicable at High-Strain Rate [J]. J Appl Phys, 1980, 53: 1498-1504.

Steinberg D J, Lund C M. A Constitutive Model for Strain Rates from 10-4 to 106 s-1 [J]. J Appl Phys, 1989, 65: 1526-1533.

Hua J S. Constitutive Equations for 93W at High Temperature and High Pressure [D]. Mianyang: China Academy of Engineering Physics, 1999. (in Chinese)

华劲松. 高温高压下钨合金的本构方程研究 [D]. 绵阳: 中国工程物理研究院, 1999.

Zhang J Y , Tan H, Yu J L. Determination of the Yield Strength of 93W Alloys by Using AC Techniques [J]. Chinese Journal of High Pressure Physics, 1997, 11(4): 254-259. (in Chinese)

张江跃, 谭华, 虞吉林. 双屈服法测定93W合金的屈服强度 [J]. 高压物理学报, 1997, 11(4): 254-259.

Xu B Y, Liu X S. Applied Elastic and Plastic Mechanics [M]. Beijing: Tsinghua University Press, 1995. 112. (in Chinese)

徐秉业, 刘信声. 应用弹塑性力学 [M]. 北京: 清华大学出版社, 1995. 112.

Meyers M A. Dynamic Behavior of Materials [M]. New York, Chichester, Brisbane, Toronto, Singapore: A Wiley-Interscience Publication John Wiley Sons Inc, 1994. 386-387.

Millett J C F, Bourne N K, Rosenberg Z. On the Analysis of Transverse Stress Gauge Data from Shock Loading Experiments [J]. J Phys D: Appl Phys, 1996, 29: 2466-2472.

Greenwood D, Forbes J, Garcia F, et al. Improvements in the Signal Fidelity of the Manganin Stress Gauge [A]. Furnish M D, Thadhani N N, Norie Y. Shock Compression of Condensed Matter-2001 [C]. New York: Melville, 2002. 1157-1159.

Millett J C F, Bourne N K, Rosenberg Z, et al. Shear Strength Measurements in a Tungsten Alloy during Shock Loading [J]. J Appl Phys, 1999, 86: 6707-6709.

Millett J C F, Bourne N K, Graylll G T, et al. The Response of TiAl Based Alloys to One Dimensional Shock Loading [J]. Acta Materiala, 2002, 50: 4801-4811.

Graylll G T, Bourne N K, Millett J C F. Shock Response of Tantalum: Lateral Stress and Shear Strength througth the Front [J]. J Appl Phys, 2003, 94: 6430-6436.

Zhou M, Clifton R J. Dynamic Constitutive and Failure Behavior of a Two-Phase Tungsten Composite [J]. J Appl Mech, 1997, 64: 487.

Clifton R J. Response of Materials under Dynamic Loading [J]. Int J Solids Struct, 2000, 37: 105-113.

Fruschy K J, Clifton R J. High-Temperature Pressure-Shear Plate Impact Experiments on OFHC Copper [J]. J Mech Phys Solids, 1998, 46: 1723-1743.

Kanel G I, Ragorenov S V, Bogatch A A, et al. Spall Fracture Properties of Aluminum and Magnesium at High Temperature [J]. J Appl Phys, 1996, 79: 8310-8317.

Frutschy K J, Clifton R J. High Temperature Pressure Shear Plate Impact Experiments and Results for Pure Tungsten Carbide [J]. Exp Mech, 1998, 38: 116-125.
