粉末药型罩的材料密度对聚能射流性能的影响

高永宏; 顾晓辉; 王凤英

doi:10.11858/gywlxb.2013.04.014

粉末药型罩的材料密度对聚能射流性能的影响

doi: 10.11858/gywlxb.2013.04.014

1.
南京理工大学机械工程学院，江苏南京 210094；
2.
中北大学化工与环境学院，山西太原 030051

详细信息

通讯作者:
高永宏 E-mail:gyh54gyh@163.com

计量
- 文章访问数: 6382
- HTML全文浏览量: 419
- PDF下载量: 427
出版历程
- 收稿日期: 2012-03-14
- 修回日期: 2012-06-06
- 刊出日期: 2013-08-15

Powder Liner Density Effect on the Performance of Shaped Charge Jet

1.
School of Mechanical Engineering, Nanjing University of Science and Technology, Nanjing 210094, China;
2.
Department of Chemical Engineering and Environment, North University of China, Taiyuan 030051, China

摘要

摘要: 为研究粉末药型罩的材料密度对其所形成的聚能射流的影响，借助Birkhoff定常模型和Gurney压垮速度理论，计算了相同装药条件下药型罩密度与其所形成的聚能射流速度、射流微粒动量与动能的关系曲线。在相同装药结构下，对W、Cu质量配比分别为0.5∶0.5和0.4∶0.6的两种W-Cu粉末药型罩，进行了射流速度测定和破甲威力实验研究。计算结果与实验结果吻合较好，表明借助Birkhoff定常模型和Gurney压垮速度理论所计算的射流密度、射流微粒动量及动能与药型罩密度的关系曲线具有一定的参考价值，增大粉末药型罩密度可有效提高聚能射流的破甲威力。
- 粉末药型罩 /
- 聚能射流 /
- 破甲威力 /
- 密度
Abstract: In order to study the relation of powder liner material density and performance of the shaped charge jet, the curves of shaped jet velocity, jet particle momentum and jet particle kinetic energy with respect to the liner density were calculated under the same charge conditions, according to the Birkhoffs steady theory and Gurneys formula of crushed speed. In the same charge structure, the jet velocity and penetration power of two kinds of powder liner were tested, whose mass ratios of W to Cu were 0.5∶0.5 and 0.4∶0.6 respectively. It is found that the experimental results are well in agreement with the calculation results. Therefore, it is considered that the calculated curves have certain reference values, and the penetration power can be increased effectively by improving the density of powder liner.
- powder liner /
- shaped charge jet /
- penetration power /
- density

HTML全文

参考文献(20)

Azharonok V V, Krat'ko L E, Goncharik S V, et al. Character of the fast jet efflux upon detonation of shaped charges [J]. J Eng Phys Thermophys, 2008, 81(3): 494-498.

Lei F B, Cao D L. Numerical simulation of the shaped charge jet from tungsten-copper powder liner [J]. Chinese Journal of Explosives Propellants, 2010, 33(6): 73-75. (in Chinese)

雷锋斌, 曹端林. 钨铜粉末药型罩形成聚能射流的数值模拟 [J]. 火炸药学报, 2010, 33(6): 73-75.

Yu R, Li F J, Xue X Y, et al. Study on the influence of rate of liner thickness change on the penetration [J]. Journal of Projectiles, Rockets, Missiles and Guidance, 2010, 30(1): 134-136. (in Chinese)

郁锐, 李福金, 薛鑫莹, 等. 药型罩壁厚变化率对破甲威力影响的研究 [J]. 弹箭与制导学报, 2010, 30(1): 134-136.

Wang C, Fu X L, Ning J G. Numerical simulation of shaped charge jet formation under different ways of initiation [J]. Transactions of Beijing Institute of Technology, 2006, 26(5): 401-404. (in Chinese)

王成, 付晓磊, 宁建国. 起爆方式对聚能射流性能影响的数值分析 [J]. 北京理工大学学报, 2006, 26(5): 401-404.

Jing Q B, Jing Z Y, Shi J. The influence of metal particles arrangement of powder shaped charge liner and its thermal treatment on performance of jet [J]. Chinese Journal of Explosives Propellants, 2008, 31(1): 42-44. (in Chinese)

景青波, 景振禹, 石健. 粉末药型罩金属粒度级配及热处理对聚能射流性能的影响 [J]. 火炸药学报, 2008, 31(1): 42-44.

Zhang X R, Wu C, Huang F L. Penetration of shaped charge jets with tungsten-copper and copper liners at the same explosive-to-liner mass ratio into water [J]. Shock Waves, 2010, 20(3): 263-267.

Zygmunt B, Wilk Z. Formation of jets by shaped charges with metal powder liners [J]. Propell Explos Pyrot, 2008, 33(6): 482-487.

Proskuryakov E V, Sorokin M V, Fomin V M. Rebounding of a shaped-charge jet [J]. J Appl Mech Tech Phys, 2007, 48(5): 633-635.

Chen W G, Zhang Y. Influence of liner with different material model on simulation results [J]. Science Technology and Engineering, 2010, 10(13): 3227-3229. (in Chinese)

陈文刚, 张越. 不同材料模型的药型罩对仿真结果的影响 [J]. 科学技术与工程, 2010, 10(13): 3227-3229.

Hirsch E. Scaling of the shaped charge jet break-up time [J]. Propell Explos Pyrot, 2006, 31(3): 230-233.

Jackowski A, Wlodarczyk E. The influence of repressing liners made from sintered copper on jet formation [J]. J Mater Process Technol, 2006, 171(1): 21-26.

Chen X L, Hang Y H, Fan Z B, et al. A coupling computation method for penetration of shaped charge jet [J]. Explosion and Shock Waves, 1998, 18(4): 317-322. (in Chinese)

陈贤林, 杭义洪, 范中波, 等. 聚能射流侵彻的一种耦合算法 [J]. 爆炸与冲击, 1998, 18(4): 317-322.

Nagao Y, Kibe S, Shimizu T, et al. Improvement of conical shaped charge system and comparison of the test result between CSC and gas gun [J]. Acta Astronaut, 2007, 60(8/9): 763-769.

Held M. Predominance of shaped charge diameter to performance quality against special targets [J]. Propell Explos Pyrot, 2005, 30(6): 435-437.
