四层剪切运动间隔靶板对射流干扰的数值模拟

孙立志; 李治源; 吕庆敖

doi:10.11858/gywlxb.2013.03.017

四层剪切运动间隔靶板对射流干扰的数值模拟

doi: 10.11858/gywlxb.2013.03.017

1.
71315部队，河南商丘 476000；
2.
军械工程学院，河北石家庄 050003

详细信息

通讯作者:
孙立志 E-mail:slzh002@126.com

计量
- 文章访问数: 7196
- HTML全文浏览量: 614
- PDF下载量: 446
出版历程
- 收稿日期: 2011-07-31
- 修回日期: 2011-11-11
- 刊出日期: 2013-06-15

Numerical Simulation on Shaped Charge Jet Being Disturbed by Shearing Movement of Four-Layer Spaced Plates

1.
Unit 71315 of PLA, Shangqiu 476000, China;
2.
Ordnance Engineering College, Shijiazhuang 050003, China

摘要

摘要: 利用ANSYS/LS-DYNA程序，对金属射流侵彻4层剪切运动等厚间隔靶板的过程进行了数值模拟研究。从射流破裂形态、能量损失幅值、后效靶板上的穿深形貌等3个角度，分析了运动靶板对射流的干扰特性，得到了靶板的运动速度、射流入射角度对4层剪切运动间隔靶板对射流破甲性能的影响规律。结果表明，在靶板运动速度从零提高至300 m/s的过程中，靶板对射流的干扰能力逐步提高，但运动靶板速度在从零提高到100 m/s时，对射流的干扰程度变化较快，速度再提高时，干扰程度变化较缓。运动靶板对射流的干扰能力随着射流入射角度的增大而呈递增趋势。
- 装甲 /
- 射流 /
- 侵彻 /
- 剪切运动 /
- 数值模拟
Abstract: Numerical simulation with ANSYS/LS-DYNA software was accomplished on metal jet being disturbed by shearing movement of four-layer equivalent spaced plates. Disturbing performance of moving plates was analyzed according to jet rupturing forms, energy losing values, and the penetrating depth in target plate. The effects of the plates-velocity and the impact angle on the disturbing performance were obtained. The obtained results are as follow: the increasing of the plate velocity can improve the disturbing ability on jet; the disturbing efficiency was greater with the plates velocity beneath 100 m/s than over 100 m/s; and the disturbing extent can increase with the increase of the impact angle. All those results are significant for mechanical armoring research.
- armoring /
- shaped-charge jet /
- penetration /
- shearing movement /
- numerical simulation

HTML全文

参考文献(14)

Mao D F, Li X D, Ren D P. Numerical simulation of the disturbance of sandwich explosive on jet [J]. Acta Armamentarii, 2007, 28(11): 1306-1309. (in Chinese)

毛东方, 李向东, 任丹萍. 平面夹层炸药对射流干扰的数值模拟 [J]. 兵工学报, 2007, 28(11): 1306-1309.

Liang Z F, Hu H X, Jiao Y D, et al. Experimental study on the ultimate adverse effect of the space between target plates on jet penetration depth [J]. Chinese Journal of Explosives Propellants, 2003, 26(1): 12-15. (in Chinese)

梁争峰, 胡焕性, 焦育东, 等. 间隔靶对射流侵彻能力影响极限的实验研究 [J]. 火炸药学报, 2003, 26(1): 12-15.

Liang Z F, Hu H X, Sun J, et al. Numerical simulation and experimental study on the effect of jet penetrating into disconnected targets [J]. Explosives and Shock Waves, 2002, 22(4): 381-386. (in Chinese)

梁争峰, 胡焕性, 孙建, 等. 间隔靶对射流侵彻影响的数值模拟和实验研究 [J]. 爆炸与冲击, 2002, 22(4): 381-386.

Livermore Software Technology Corporation. LS-DYNA Keyword User's Manual [Z]. Livermore: Livermore Software Technology Corporation, 2007: 813-816.

Livermore Software Technology Corporation. LS-DYNA Theoretical Manual [Z]. Livermore: Livermore Software Technology Corporation, 1998: 222-224; 311-313.

Mao D F, Li X D, Song L L. Numerical simulation of disturbance by sandwich explosive on jet [J]. Explosives and Shock Waves, 2008, 28(1): 86-91. (in Chinese)

毛东方, 李向东, 宋柳丽. V型夹层炸药对射流干扰的数值模拟 [J]. 爆炸与冲击, 2008, 28(1): 86-91.

Johnson G R, Cook W H. Fracture characteristics of three metals subjected to carious strains, strains rates, temperatures and pressures [J]. Eng Fract Mech, 1985, 21(1): 31-48.

Johnson G R, Cook W H. A Constitutive model and data for metals subjected to large strains, high rates and high temperatures [C]//7th International Symposium on Ballistics. The Netherlands: The Hague, 1983: 541-547.

Zu X D, Huang Z X, Gu X H. Simulation analysis on ploy-rubber resisted jet penetrating [J]. Journal of System Simulation, 2010, 22(1): 56-59. (in Chinese)

祖旭东, 黄正祥, 顾晓辉. 聚乙烯橡胶抗射流侵彻数值仿真研究 [J]. 系统仿真学报, 2010, 22(1): 56-59.
