Research on Working Performance of Small Spinning Solid Rocket Motor
-
摘要: 通过建立考虑侵蚀燃烧效应的固体火箭发动机内弹道模型，计算发动机内弹道压力时间曲线，将此压力数据作为初始压力输入值，利用FLUENT仿真软件对带有平直段的喷管内的流场进行仿真计算，确定喷管是否实现超音速流场。最后进行小型旋转固体火箭发动机静态和动态性能测试，测试结果表明，发动机转速达到19 000 r/min，满足工作需要。Abstract: The small spinning solid rocket motor was employed to perform as the power of the radial twice throwing system. Interior ballistic model of spinning solid rocket motor, in which eroding burn effect was considered, was established. The calculated pressure-time curve was set as initial pressure value for subsequent simulations. Fluid field of nozzle with straight segment was simulated by software of Fluent, whether fluid field was supersonic or not can be identified. Finally static and dynamic tests of spinning solid rocket motor were performed. The tested results of spinning solid rocket motor indicate that spinning solid rocket motor works well at 19 000 r/min and meets the working need.
-
Key words:
- small spinning solid rocket motor /
- interior ballistic /
- static test /
- dynamic test
-
Xue H, Jiang C L, Wang Z C. Internal ballistic calculation and test study on spinning solid rocket motor [C]//2009 Second International Conference on Intelligent Computation Technology and Automation. Changsha, Hunan, 2009: 860-863. Cha X Y. Research on radial twice throwing technology [D] Beijing: Beijing Institute of Technology, 2008: 7. (in Chinese) 茶晓燕. 径向二次抛撒技术研究 [D]. 北京: 北京理工大学, 2008: 7. Zhang P, Sun W S, Gui Y. Theory of Solid Rocket Motor [M]. Beijing: Beijing Institute of Technology Press, 1992: 273-283. (in Chinese) 张平, 孙维申, 眭英. 固体火箭发动机原理 [M]. 北京: 北京理工大学出版社, 1992: 273-283. Ye W J, Chang X Q, Cao T Y. Working Process Theory Basic of Solid Rocket Motor [M]. Changsha: NUDT Publish House, 1985: 158-159. (in Chinese) 叶万举, 常显奇, 曹泰岳. 固体火箭发动机工作过程理论基础 [M]. 长沙: 国防科技大学出版社, 1985: 158-159. Cai G B, Tian H. Spinning effect on solid rocket motor [J]. Journal of Propulsion Technology, 1999, 20(1): 11-15. (in Chinese) 蔡国飙, 田辉. 旋转对固体火箭发动机的影响 [J]. 推进技术, 1999, 20(1): 11-15. -
