3 GPa熔融盐固体介质三轴高温压力容器的轴压摩擦力标定

刘照星; 周永胜; 刘贵; 何昌荣; 钟柯; 姚文明; 韩亮; 党嘉祥

doi:10.11858/gywlxb.2013.01.002

3 GPa熔融盐固体介质三轴高温压力容器的轴压摩擦力标定

doi: 10.11858/gywlxb.2013.01.002

1.
中国地震局地质研究所地震动力学国家重点实验室，北京 100029；
2.
中国地质大学（北京），北京 100083

详细信息

通讯作者:
周永胜 E-mail:zhouysh@ies.ac.cn

计量
- 文章访问数: 7410
- HTML全文浏览量: 496
- PDF下载量: 708
出版历程
- 收稿日期: 2011-05-19
- 修回日期: 2012-01-16
- 刊出日期: 2013-02-15

Axial Friction Calibration for 3 GPa Molten Salt Medium Triaxial Pressure Vessel under High Pressure and High Temperature

1.
State Key Laboratory of Earthquake Dynamics, Institute of Geology, China Earthquake Administration, Beijing 100029, China;
2.
China University of Geosciences (Beijing), Beijing 100083, China

摘要

摘要: 在温度标定和围压标定的基础上，采用轴压循环方法，对3 GPa固体介质三轴高温高压实验系统的轴压摩擦力进行了标定，分析了围压、温度、轴向位移速率、装样方式（盐套类型）等实验条件对轴压摩擦力的影响。结果表明：静摩擦力、挤压摩擦力和滑动摩擦力3种轴压摩擦力对轴向应力的影响不同，其中静摩擦力和挤压摩擦力对轴向应力的影响很小，影响应力精度的主要是滑动摩擦力。静摩擦力及滑动摩擦力与围压正相关；静摩擦力与轴向位移速率正相关，但受其影响较小，滑动摩擦力不受其影响；静摩擦力和滑动摩擦力与温度负相关，并且受其影响较显著；盐套类型对轴压摩擦力的影响较大，当实验条件接近盐套熔点时，轴压摩擦力显著降低，当样品周围的盐套处于熔融状态时，轴压摩擦力最小。基于此，确定了标定轴压摩擦力的具体步骤，并对角闪岩的应力-应变曲线进行了轴压摩擦力标定。对比轴压摩擦力校正前、后的应力-应变曲线发现，经过轴压摩擦力校正的应力-应变曲线能更好地反映样品的实际变形情况。
- 摩擦力标定 /
- 压力容器 /
- 熔融盐 /
- 高温高压 /
- 轴压摩擦力
Abstract: The axial friction calibration of 3 GPa molten salt medium triaxial pressure vessel under high pressure and high temperature is performed based on the calibration of the temperature and confining pressure of the apparatus, which mainly analyses the effects from different experimental conditions, such as the confining pressure, the temperature, and type of salt cell used around the sample. The results show that the axial friction includes static friction, squeezing friction and sliding friction between the piston and the surrounding material. Three types of friction play different roles in axial stress, in which sliding friction is the main factor that affects axial stress precision, while static fiction and squeezing friction have little effects on axial stress. The static and sliding frictional force has a positive correlation to the confining pressure. The axial piston velocity has a positive effect on static friction, too, but the effect is not significant, while it has no effect on sliding friction. Both static and sliding friction has a negative correlation to the experimental temperature, and the effect of temperature is significant. The type of salt cell has a great effect on axial friction. The axial friction drops dramatically as the experimental temperature approaches the melting point of the salt. The procedure of calibrating axial friction is made based on the results, and the axial friction calibration is applied to stress-strain curves for deformation experiments of amphibole. It is found that it is more reliable that the deformation curve with the calibration of axial friction than the curve without calibration.
- friction calibration /
- pressure vessel /
- molten salt /
- high temperature and high pressure /
- axial friction

HTML全文

参考文献(21)

Rybacki E, Renner J, Konrad K, et al. A servohydraulically-controlled deformation apparatus for rock deformation under conditions of ultra-high pressure metamorphism [J]. Pure Appl Geophys, 1998, 152(3): 579-606.

Tullis T E, Tullis J. Experimental rock deformation techniques [J]. Geophys Monogr Ser, 1986, 36: 297-324.

Green H W, Borch R S. A new molten salt cell for precision stress measurement at high pressures [J]. Eur J Mineral, 1989, 1(2): 213-219.

Tingle T N, Green H W, Young T E, et al. Improvements to Griggs-type apparatus for mechanical testing at high pressures and temperatures [J]. Pure Appl Geophys, 1993, 141(2/3/4): 523-543.

Ingrin J, Doukhan J C. A Griggs deformation apparatus set up at Lille [J]. Terra Nova, 1991, 3(6): 603-606.

Gleason G C, Tullis J. A flow law for dislocation creep of quartz aggregates determined with the molten salt cell [J]. Tectonophysics, 1995, 247(1/2/3/4): 1-23.

Gleason G C, Tullis J. Improving flow laws and piezometers for quartz and feldspar aggregates [J]. Geophys Res Lett, 1993, 20(19): 2111-2114.

Holyoke I C W, Kronenberg A K. Accurate differential stress measurement using the molten salt cell and solid salt assemblies in the Griggs apparatus with applications to strength, piezometers and rheology [J]. Tectonophysics, 2010, 494(1/2): 17-31.

Zhou Y S, He C R, Song J, et al. An experiment study of quartz-coesite transition at differential stress [J]. Chinese Science Bulletin, 2005, 50(5): 446-451.

Han L, Zhou Y S, Dang J X, et al. Temperature calibration for 3 GPa molten salt medium triaxial pressure vessel [J]. Chinese Journal of High Pressure Physics, 2009, 23(6): 407-414. (in Chinese)

韩亮, 周永胜, 党嘉祥, 等. 3 GPa熔融盐固体介质高温高压三轴压力容器的温度标定 [J]. 高压物理学报, 2009, 23(6): 407-414.

Han L, Zhou Y S, He C R, et al. Confined pressure calibration for 3 GPa molten salt medium triaxial pressure vessel under high pressure and temperature [J]. Chinese Journal of High Pressure Physics, 2011, 25(3): 213-220. (in Chinese)

韩亮, 周永胜, 何昌荣, 等. 3 GPa熔融盐固体介质高温高压三轴压力容器的围压标定 [J]. 高压物理学报, 2011, 25(3): 213-220.

Dang J X, Zhou Y S, He C R. Pressure calibration for the solid medium vessel of piston-cylinder apparatus under high pressure and high temperature [J]. Seismology and Geology, 2007, 29(1): 133-143. (in Chinese)

党嘉祥, 周永胜, 何昌荣. 活塞-圆桶式固体介质高温高压实验容器的压力标定方法 [J]. 地震地质, 2007, 29(1): 133-143.

Liu P, Tong Y X, Yang Q Q. Molten salt systems and the new developments for the application of molten salts [J]. Electrochemistry, 2007, 13(4): 351-359. (in Chinese)

刘鹏, 童叶翔, 杨绮琴. 熔盐体系及有关应用的新进展 [J]. 电化学, 2007, 13(4): 351-359.

Stipp M, Tullis J. The recrystallized grain size piezometer for quartz [J]. Geophys Res Lett, 2003, 30(21): 2088.

Zhou Y S, Jiang H K, He C R. Experiments of brittle-plastic transition and instability modes of Juyongguan granite at different temperatures and pressures [J]. Earthquake Research In China, 2003, 17(2): 169-182.

Jiang H K, Zhang L, Zhou Y S. Correction of stress-strain relationship in triaxial compression tests with solid confining pressure medium [J]. Seismology and Geology, 2001, 23(3): 471-474. (in Chinese)

蒋海昆, 张流, 周永胜. 固体介质三轴实验中样品半延性-延性变形对应力曲线影响的修正 [J]. 地震地质, 2001, 23(3): 471-474.
