光滑粒子流体动力学有限元法接触算法研究

张志春; 强洪夫; 高巍然

doi:10.11858/gywlxb.2011.02.001

光滑粒子流体动力学有限元法接触算法研究

doi: 10.11858/gywlxb.2011.02.001

1.
第二炮兵工程学院，陕西西安 710025；
2.
第二炮兵装备研究院，北京 100085

详细信息

通讯作者:
强洪夫

计量
- 文章访问数: 8564
- HTML全文浏览量: 497
- PDF下载量: 671
出版历程
- 收稿日期: 2010-01-31
- 修回日期: 2010-04-22
- 刊出日期: 2011-04-15

Research on Contact Algorithm between Smoothed Particle Hydrodynamics and Finite Element Method

1.
Xi'an Hi-Tech Institute, Xi'an 710025, China;
2.
The Second Artillery Equipment Academy, Beijing 100085, China

More Information

Corresponding author: QIANG Hong-Fu

摘要

摘要: 耦合光滑粒子流体动力学（SPH）方法和有限元法（FEM），是研究冲击动力学问题的一种有效途径。为解决SPH粒子和有限单元间的接触问题，提出了SPH-FEM接触算法。该算法是在有限元节点处设置背景粒子，采用SPH接触算法的思想，计算施加在SPH粒子和有限元节点上的接触力，并且以外力的形式分别加入到SPH动量方程和有限元动力学方程中。利用SPH-FEM接触算法，对两杆撞击以及圆柱形钢弹正冲击钢板发生的冲塞破坏过程进行了三维数值模拟，靶板采用含损伤的Johnson-Cook模型和Grneisen状态方程，模拟结果与实验结果吻合较好。
- 光滑粒子流体动力学方法 /
- 有限元法 /
- 接触 /
- 背景粒子 /
- 冲击
Abstract: The coupling between smoothed particle hydrodynamics (SPH) and finite element method (FEM) is an effective approach for the simulation of impact dynamics. An alternative algorithm for the treatment of contact problem between SPH particles and finite elements was employed. Background particles were assigned in the position of finite element nodes, and the contact forces on SPH particles and finite element nodes were calculated with the same approach as SPH particles to particle contact algorithm. The contact force was added to the momentum equation for SPH and dynamic equation for FEM respectively. Using the SPH-FEM contact algorithm, the axial impact between two bars and the perforation of a cylindrical steel projectile impacting a plate target were simulated, where the Johnson-Cook material model with damage effect and Grneisen equation of state were employed. The computed results showed good agreement with the experimental data.
- smoothed particle hydrodynamics /
- finite element method /
- contact /
- background particle /
- impact

HTML全文

参考文献(16)

Belytschko T, Liu W K, Moran B. Nonlinear Finite Elements for Continua and Structures [M]. New York: John Wiley Sons, 2000: 23-88.

Lucy L B. A Numerical Approach to the Testing the Fission Hypothesis [J]. Astron J, 1977, 82: 1013-1024.

Gingold R A, Monaghan J J. Smoothed Particle Hydrodynamics: Theory and Application to Non-Spherical Stars [J]. Mon Not R Astr Soc, 1977, 181: 375-389.

Monaghan J J. SPH without a Tensile Instability [J]. J Comput Phys, 2000, 159(2): 290-311.

Monaghan J J. Smoothed Particle Hydrodynamics [J]. Rep Prog Phys, 2005, 68: 1703-1759.

Attaway S W, Heinstein M W, Swegle J W. Coupling of Smoothed Particle Hydrodynamics with the Finite Element Method [J]. Nucl Eng Des, 1994, 150: 199-205.

Johnson G R. Linking of Lagrangian Particle Methods to Standard Finite Element Methods for High Velocity Impact Computations [J]. Nucl Eng Des, 1994, 150(2-3): 265-274.

Johnson G R, Stryk R A, Beissel S R. SPH for High Velocity Impact Computations [J]. Comput Methods Appl Mech Eng, 1996, 139(1-4): 347-373.

Wang J, Wang X J, Bian L. Linking of Smoothed Particle Hydrodynamics Method to Standard Finite Element Method and Its Application in Impact Dynamics [J]. Explosion and Shock Waves, 2007, 27(6): 522-528. (in Chinese)

王吉, 王肖钧, 卞梁. 光滑粒子法与有限元的耦合算法及其在冲击动力学中的应用 [J]. 爆炸与冲击, 2007, 27(6): 522-528.

Vignjevic R, de Vuyst T, Campbell J C. A Frictionless Contact Algorithm for Meshless Methods [A]//International Conference on Computational Experimental Engineering and Sciences [C]. Miami, USA, 2007, 3(2): 107-112.

Qiang H F, Gao W R. SPH Method with Fully Variable Smoothing Lengths and Implementation [J]. Chinese Journal of Computational Physics, 2008, 25(5): 569-575. (in Chinese)

强洪夫, 高巍然. 完全变光滑长度SPH法及其实现 [J]. 计算物理, 2008, 25(5): 569-575.

Zhang Z C, Qiang H F, Gao W R. Coupling of Smoothed Particle Hydrodynamics with Finite Element Method Using Attachment Algorithm [A]//International Symposium on Meshfree, Particle and Extended Finite Element Methods [C]. Nanjing, 2009: 146-154.

Borvik T, Langseth M, Hopperstad O S, et al. Ballistic Penetration of Steel Plates [J]. Int J Impact Eng, 1999, 22(9-10): 855-886.

Johnson G R, Cook W H. Fracture Characteristics of Three Metals Subjected to Various Strains, Strain Rates, Temperatures and Pressures [J]. Eng Fract Mech, 1985, 21(1): 31-48.
