尾翼型爆炸成型弹丸的数值模拟及实验研究

林加剑; 任辉启; 沈兆武

doi:10.11858/gywlxb.2009.03.009

尾翼型爆炸成型弹丸的数值模拟及实验研究

doi: 10.11858/gywlxb.2009.03.009

1.
洛阳水利工程技术研究所，河南洛阳 471023；
2.
中国科学技术大学近代力学系，安徽合肥 230026

详细信息

通讯作者:
林加剑

计量
- 文章访问数: 8452
- HTML全文浏览量: 701
- PDF下载量: 734
出版历程
- 收稿日期: 2008-07-31
- 修回日期: 2008-10-12
- 刊出日期: 2009-06-15

Numerical and Experimental Study on Explosively Formed Projectile with Fins

1.
Luoyang Institute of Hydraulic Engineering and Technology, Luoyang 471023, China;
2.
Department of Modern Mechanics, University of Science and Technology of China, Hefei 230026, China

More Information

Corresponding author: LIN Jia-Jian

摘要

摘要: 在药型罩上粘附铝隔板是一种新的形成尾翼型爆炸成型弹丸（Explosively Formed Projectile，EFP）的实验方法。通过实验和数值模拟对该方法进行了分析，探讨了形成尾翼的机理。利用有限元分析软件LS-DYNA，对大锥角型、球缺型和弧锥结合型3种不同药型罩在采用新方法时形成的尾翼型EFP进行了三维数值模拟分析，并将模拟结果与实验结果进行对比。研究结果表明：3种药型罩均能形成比较明显的尾翼，数值计算结果与实验结果较吻合。该研究为设计尾翼型EFP提供了一种新的参考方法。
- 爆炸成型弹丸 /
- 聚能装药 /
- 尾翼 /
- 隔板 /
- 爆炸力学
Abstract: It is a new method to produce an explosively formed projectile (EFP) with fins by attaching aluminum cover on the liner. Experimental and numerical research were performed using this new method. Furthermore, the mechanism of forming fins was discussed. The new method of forming EFP with fins was simulated by LS-DYNA, and a contrastive analysis was carried out on three typical liners, including big-cone shaped, imperfect-sphere shaped and arccone shaped. The results from 3D numerical simulations and experiments were also analysed. Comparison of results show that three kind of liners could form obvious fins by this new method,and the results of numerical simulations are in agreement with the experiment data. The research provides a new reference method for designing EFP with fins.
- explosively formed projectile /
- shaped charge /
- fin /
- cover /
- explosive mechanics
