电火花放电通道蚀除绝缘工程陶瓷的热力学特性研究

刘永红; 于丽丽; 徐玉龙; 纪仁杰; 李庆云

doi:10.11858/gywlxb.2009.02.003

电火花放电通道蚀除绝缘工程陶瓷的热力学特性研究

doi: 10.11858/gywlxb.2009.02.003

中国石油大学（华东）机电工程学院，山东东营 257061

详细信息

通讯作者:
刘永红

计量
- 文章访问数: 8017
- HTML全文浏览量: 340
- PDF下载量: 839
出版历程
- 收稿日期: 2008-07-08
- 修回日期: 2008-10-15
- 刊出日期: 2009-04-15

Thermodynamic Characteristics of Machining Insulating Engineering Ceramics with Electrical Discharge Channel

School of Electromechanical Engineering, China University of Petroleum, Dongying 257061, China

More Information

Corresponding author: LIU Yong-Hong

摘要

摘要: 研究开发出一种绝缘工程陶瓷电火花加工新技术，它是利用电火花放电通道流经绝缘工程陶瓷表面时产生的瞬时高温作用进行蚀除加工的。建立了电火花放电通道热蚀除加工绝缘工程陶瓷的温度场和热应力场数学模型，对绝缘工程陶瓷表面上的温度梯度和热应力场进行了数值模拟，给出了火花放电通道在绝缘工程陶瓷表面上形成的温度梯度和热应力分布规律。模拟结果为揭示绝缘工程陶瓷的电火花微观去除机理、预测绝缘工程陶瓷表面的微观形貌和电加工参数的选择等奠定了理论基础。
- 绝缘工程陶瓷 /
- 电火花加工 /
- 温度梯度 /
- 热应力 /
- 数值模拟
Abstract: A new technique of machining insulating engineering ceramics with instantaneous high temperature produced by electrical discharge channel (EDC) flowing insulating engineering ceramic surface is developed. The mathematical models for the temperature and thermal stress of machining insulating ceramics with EDC are established. The numerical simulation on the temperature gradient and thermal stress of electrical discharge machining insulating engineering ceramics are done. The distribution of the temperature gradient and thermal stress produced by EDC on the insulating engineering ceramic surface are given. The simulation results give the theoretic foundation for revealing the micro-scale mechanism of removing insulating engineering ceramics with EDC, predicting the microcosmic profile of insulating engineering ceramic surface machined by EDC, and selecting the electrical parameter for the new process.
- insulating engineering ceramics /
- electrical discharge machining /
- temperature gradient /
- thermal stress /
- numerical simulation

HTML全文

参考文献(23)

Pavese M, Fino P, Ortona A, et al. Potential of SiC Multilayer Ceramics for High Temperature Applications in Oxidising Environment [J]. Ceramics International, 2008, 34(1): 197-203.

Malzbender J, Steinbrech R W. Threshold Fracture Stress of Thin Ceramic Components [J]. Journal of the European Ceramic Society, 2008, 28(1): 247-252.

Kiyoshi S, Tetsutaro U, Manabu I, et al. A New Complex Grinding Method for Ceramic Materials Combined with Ultrasonic Vibration and Electrodischarge Machining [J]. Key Engineering Materials, 2007, 329: 439-444.

Zheng L, Yuan J T, Li S H. Drilling Hole Mechanisms of Ceramic Composite Armors [J]. Journal of the Chinese Ceramic Society, 2007, 35(5): 568-573. (in Chinese)

郑雷, 袁军堂, 李少华. 陶瓷复合装甲的孔加工及机理 [J]. 硅酸盐学报, 2007, 35(5): 568-573.

Li X P, Liu Y H, Ji R J, et al. Non-Traditional Machining Technique for Insulting Engineering Ceramics [J]. Electromachining Mould, 2006, (5): 6-9. (in Chinese)

李小朋, 刘永红, 纪仁杰, 等. 绝缘工程陶瓷的特种加工技术 [J]. 电加工与模具, 2006, (5): 6-9.

Chang C W, Kuo C P. An Investigation of Laser-Assisted Machining of Al2O3 Ceramics Planning [J]. International Journal of Machine Tools and Manufacture, 2007, 47(3-4): 452-461.

Chak S K, Venkateswara R V. Trepanning of Al2O3 by Electro-Chemical Discharge Machining (ECDM) Process Using Abrasive Electrode with Pulsed DC Supply [J]. International Journal of Machine Tools and Manufacture, 2007, 47(14): 2061-2070.

Ji R J, Liu Y H, Yu L L, et al. Research on Mechanism of Ultra-Precision Electrical Discharge and Mechanical Grinding for Nonconductive Engineering Ceramics [A]//Proceedings of the International Conference on Integration and Commercialization of Micro and Nanosystems 2007 [C]. Sanya, 2007: 1445-1448.

Guo Y F, Bai J C, Deng G Q, et al. High Speed Wire Electrical Discharge Machining (HS-WEDM) Phenomena of Insulating Si3N4 Ceramics with Assisting Electrode [J]. Key Engineering Materials, 2007, 339: 281-285.

Tani T, Fukuzawa Y, Mohri N, et al. Machining Phenomena in WEDM of Insulating Ceramics [J]. Journal of Materials Processing Technology, 2004, 149(1-3): 124-128.

Fukuzawa Y, Gotoh H, Mohri N, et al. Line Swept Surface Generation on Insulating Ceramics by Wire Electrical Discharge Machining [J]. Journal of the Australasian Ceramic Society, 2005, 4(1): 17-21.

Liu Y H, Ji R J, Li X P, et al. Electric Discharge Milling of Insulating Ceramics [J]. Proceedings of the Institution of Mechanical Engineers, Part B: Journal of Engineering Manufacture, 2008, 222(B2): 361-366.

Liu Y H, Ji R J, Li X P, et al. Effect of Machining Fluid on the Process Performance for Electric Discharge Milling of Insulating Al2O3 Ceramic [J]. International Journal of Machine Tools Manufacture, 2008, 48: 1030-1035.

Yadava V, Jain V K, Dixit P M. Temperature Distribution during Electro-Discharge Abrasive Grinding [J]. Machining Science and Technology, 2002, 6(1): 97-127.

Yadava V, Jain V K, Dixit P M. Thermal Stresses Due to Electrical Discharge Machining [J]. International Journal of Machine Tools Manufacture, 2002, 42(8): 877-888.

Yadava V, Jain V K, Dixit P M. Theoretical Analysis of Thermal Stresses in Electro-Discharge Diamond Grinding [J]. Machining Science and Technology, 2004, 8(1): 119-140.

Shankar P, Jain V K, Sundarajan T. Analysis of Spark Profiles during EDM Process [J]. Machining Science and Technology, 1997, 1(2): 195-217.

Yang S M. Basis of Heat Transfer [M]. Beijing: High Education Press, 1991: 198-202. (in Chinese)

杨世铭. 传热学基础 [M]. 北京: 高等教育出版社, 1991: 198-202.

Liu H L, Jin Z H, Hao Z B, et al. Design, Fabrication and Properties of Carbon/Carbon/Al2O3 Ceramic Functionally Gradient Materials [J]. Journal of Functional Materials and Devices, 2004, 10(1): 123-127. (in Chinese)

刘红林, 金志浩, 郝志彪, 等. 碳/碳/Al2O3陶瓷功能梯度材料的制备与研究 [J]. 功能材料与器件学报, 2004, 10(1): 123-127.
