金刚石膜厚度尺寸对热残余应力的影响

唐达培; 高庆; 吴兰鹰

doi:10.11858/gywlxb.2007.03.017

金刚石膜厚度尺寸对热残余应力的影响

doi: 10.11858/gywlxb.2007.03.017

1.
西南交通大学应用力学与工程系，四川成都 610031；
2.
北京科技大学应用学院，北京 100083

详细信息

通讯作者:
唐达培

计量
- 文章访问数: 7862
- HTML全文浏览量: 347
- PDF下载量: 877
出版历程
- 收稿日期: 2006-10-26
- 修回日期: 2007-01-15
- 刊出日期: 2007-09-05

Effect of Diamond Films Thickness on Thermal Residual Stress

1.
Department of Applied Mechanics and Engineering, Southwest Jiaotong University, Chengdu 610031, China;
2.
School of Applied Science, Beijing University of Science and Technology, Beijing 100083, China

More Information

Corresponding author: TANG Da-Pei

摘要

摘要: 采用有限元方法对钼基体上不同厚度（20~1 000 m）金刚石膜的热残余应力进行了全面的模拟与分析，得出了它们在膜内分布的等值线图，研究了金刚石膜厚度尺寸对整个膜内的最大主拉应力和界面处每个应力分量最大值的影响。结果表明：在整个膜内，最大主拉应力的位置出现在膜的表面、界面或侧面，其值随膜厚度的增加而增大；在界面处，最大轴向应力随膜厚度的增加而增大，而最大径向压应力、最大周向压应力和最大剪应力则随膜厚度的增加而减小，其中最大剪应力减幅较小；膜厚度越大时，以上各量随厚度增（减）的速度越慢。其结论对于在金刚石膜的制备中合理地选择厚度、有效地进行应力控制有一定的参考价值。
- 金刚石膜 /
- 厚度 /
- 残余应力 /
- 有限元主应力 /
- 界面
Abstract: Each component of thermal residual stress in diamond films deposited onto Mo substrate was simulated and analyzed comprehensively by using the finite element method, and the different thickness (20~1 000 m) of the films was used during the simulation. The contour plots of these components distribution were obtained. In addition, the effect of the films thickness on the maximum tensile principal stress in films and on the maximum of every stress component at interface between films and substrate was investigated. The results show that the location of maximum tensile principal stress in the films is at the upward face or side face of the films or the interface, and the magnitude of it increases when the films become thicker. Also, the maximum axial stress at the interface increases when the films become thicker whereas the maximum compressive radial stress, maximum compressive circular stress and maximum shear stress at the interface are in reverse, and the reduction extent of the maximum shear stress is small. The increase or reduction rate of each stress mentioned above is slower when the films thickness becomes larger. These conclusions are useful to choose rationally films thickness and to control effectively the stresses during preparation of diamond films.
- diamond films /
- thickness /
- residual stresses /
- finite element /
- principal stress

HTML全文

参考文献(18)

Tang B Y, Jin J Ch, Li Sh L, et al. Study on Stress in Chemical Vapor Deposited(CVD) Diamond Films [J]. Chinese Journal of High Pressure Physics, 1997, 11(1): 56-59. (in Chinese)

唐壁玉, 靳九成, 李绍绿, 等. CVD金刚石薄膜的应力研究 [J]. 高压物理学报, 1997, 11(1): 56-59.

Chen G Ch, Li Ch M, Zhang H D, et al. Structural Analysis of Cracked Diamond Films Grown by DC Plasma Jet during Detachment [J]. Journal of Synthetic Crystals, 2003, 32(5): 518-523. (in Chinese)

陈广超, 李成明, 张恒大, 等. 直流等离子体法中脱膜开裂的金刚石膜组织结构分析 [J]. 人工晶体学报, 2003, 32(5): 518-523.

Kosky P G, Anthony T R. Fracture-Free Release of CVD Diamond [J]. Diamond and Related Materials, 1996, 5: 1313-1357.

Nakamura Y. Measurement of Internal Stress in CVD Diamond Films [J]. Thin Solid Films, 1997, 308-309: 249-253.

Kim J G, Jin Y. Characterisation of CVD Grown Diamond and Its Residual Stress State [J]. Mater Sci Eng, 1998, B57: 24-27.

Baik Y J, Lee J K, Lee W S, et al. Large Area Deposition of Thick Diamond Film by Direct-Current PACVD [J]. Thin Solid Films, 1999, 341: 202-206.

Huang T B, Liu J M, Zhong G F, et al. Preparation of Large Area Free Standing Thick Diamond Wafers [J]. Journal of University of Science and Technology Beijing, 2000, 22(3): 234-237 (in Chinese)

黄天斌, 刘敬明, 钟国仿, 等. 大面积无衬底自支撑金刚石厚膜沉积 [J]. 北京科技大学学报, 2000, 22(3): 234-237.

Jeong J H, Lee S Y, Lee W S, et al. Mechanical Analysis for Crack-Free Release of Chemical-Vapor-Deposited Diamond Wafers [J]. Diamond and Related Materials, 2002, 11: 1597-1605.

Fu Y, Du H, Sun C Q. Interfacial Structure, Residual Stress and Adhesion of Diamond Coatings Deposited on Titanium [J]. Thin Solid Films, 2003, 424: 107-114.

Windischmann H, Gray K J. Stress Measurement of CVD Diamond Films [J]. Diamond and Related Materials, 1995, 4: 837-842.

Slack G A, Bartram S F. Thermal Expansion of Some Diamond-Like Crystals [J]. J Appl Phys, 1975, 46: 89-98.

Ager Ⅲ J W, Drory M D. Quantitative Measurement of Residual Biaxial Stress by Raman Spectroscopy in Diamond Grown on a Ti Alloy by Chemical Vapor Deposition [J]. Phys Rev B, 1993, 48: 2601.

Yang J X, Li C M, Chen G C, et al. Analysis of Residual Stress Distribution in DC Arc Plasma Jet CVD High Quality Diamond Films by Raman Spectroscopy [J]. Journal of Synthetic Crystals. 2004, 33(4): 674-678.

Ma B X, Yao N, Jia Y, et al. Influence of Structure on Adhesion of Grains in CVD Diamond Films [J]. Acta Physica Sinica, 2005, 54(6): 2853-2858. (in Chinese)

马丙现, 姚宁, 贾瑜, 等. 金刚石薄膜的结构特征对薄膜附着性能的影响 [J]. 物理学报, 2005, 54(6): 2853-2858.
