W过渡层结合界面对金刚石薄膜在WC-6%Co上的附着力的影响

王传新; 汪建华; 满卫东; 马志斌; 王升高; 康志成

doi:10.11858/gywlxb.2004.01.015

W过渡层结合界面对金刚石薄膜在WC-6%Co上的附着力的影响

doi: 10.11858/gywlxb.2004.01.015

1.
武汉化工学院湖北省微波等离子体化学与新材料重点实验室，湖北武汉 430073；
2.
中国科学院等离子体物理研究所，安徽合肥 230031

详细信息

通讯作者:
王传新

计量
- 文章访问数: 8094
- HTML全文浏览量: 470
- PDF下载量: 772
出版历程
- 收稿日期: 2003-03-27
- 修回日期: 2003-10-15
- 刊出日期: 2004-03-05

Effects of W Diffusion Barrier Layer for Diamond Coatings Deposited on WC-Co Substrates

1.
Province Key Laboratory of Plasma Chemical & Advanced Materials, Wuhan Institute of Chemical Technology, Wuhan 430073, China;
2.
Institute of Plasma Physics the Chinese Academy of Sciences, Hefei 230031, China

More Information

Corresponding author: WANG Chuan-Xin

摘要

摘要: 在微波等离子体化学气相沉积装置中，采用负偏压形核等方法，研究两种不同的W过渡层/基体结合界面对金刚石薄膜与WC-6%Co附着力的影响。采用氢等离子体脱碳、磁控溅射镀W、高偏压碳化等方法，在YG6衬底表面形成化学反应型界面，W膜在碳化时和基体WC连为一体，极大地增加了W膜与基体的附着力，明显优于直接镀钨、碳化形成的物理吸附界面。在高负偏压下碳化，能提高表面粗糙度，增加膜与基体机械钳合，而负偏压形核增加核密度，从而增加膜与基体的接触面积，结果极大地提高了金刚石薄膜的附着力。
- 金刚石薄膜 /
- YG6硬质合金 /
- 附着力 /
- 过渡层
Abstract: Two different W interlay/substrate bonding interfaces for the adhesion of diamond film deposited on WC-Co substrate were investigated using bias enhancing nucleation method, in microwave plasma enhanced chemical vapor deposition (MWCVD) device. The results indicate that hydrogen plasma decarburization, W interlayer sputtering, recarburization with negative biasing induce chemical reaction bonding interface formed between the W interlayer and the substrate. Recarburized W interlayer in the initial diamond deposition strongly adhere to WC grains on the surface of WC-Co substrate, and consequently improved the adhesion of diamond film on WC-Co substrate. This pretreatment improved the adhesion of diamond film more obvious, compared with sputtering W interlayer directly on the substrate, in which physical bonding interlayer formed. Carburization with high negative biasing can improve the roughness of the substrate surface, and consequently improve the effect of mechanical interlock. The nucleation density was increased by negative biasing and therefore improved the contact area between the diamond film and the substrate, consequently improved the adhesion of diamond film on WC-Co substrate.
- diamond coatings /
- adhesion /
- cemented carbide /
- WC diffusion barriers

HTML全文

参考文献(18)

Zhou Z J, Li G, Yang Z F, et al. The Effect of c-BN Inclusion on the Densification and Microstructure of Fine-Grained Polycrystalline Diamond Compact [J]. Chinese Journal of High Pressure Physics, 2001, 15(3): 229-234. (in Chinese)

周振君, 李工, 杨正方, 等. 掺杂立方氮化硼对金刚石聚晶致密化和显微结构的影响 [J]. 高压物理学报, 2001, 15(3): 229-234 .

Deng F M. Graphitization Process of Diamond Surfaces during the Sintering of Diamond Cobalt System under High Pressure and Temperature [J]. Chinese Journal of High Pressure Physics, 2001, 15(3): 235-240. (in Chinese)

邓福铭. 超高压高温烧结中金刚石表面石墨化过程再研究 [J]. 高压物理学报, 2001, 15(3): 235-240.

Wen C, Zhou G, Hao Z Y, et al. Study on the Property of Nanometric Diamond Particles under High Temperature and High Pressure [J]. Chinese Journal of High Pressure Physics, 2000, 14(2): 119-124. (in Chinese)

文潮, 周刚, 郝兆印, 等. 高温高压下纳米金刚石粉的特性研究 [J]. 高压物理学报, 2000, 14(2): 119-124.

Polini R, Bravi F, Mattei G, et al. Effect of WC Grain Growth Inhibitors on the Adhesion of Chemical Vapor Deposition Diamond Films on WC-Co Cemented Carbide [J]. Diamond and Related Materials, 2002, 11: 242-248.

Silva S, Mammana V P, Salvadori M C, et al. WC-Co Cutting Tool Insert with Diamond Coatings [J]. Diamond and Related Materials, 1999, 8: 1913-1918.

Buck V, Deuerler F. Enhanced Nucleation of Diamond Films on Pretreated Substrates [J]. Diamond and Related Materials, 1998, 7: 1544-1552.

Vandierendonck K, Nesladek M, Kadlec S, et al. W/WC Diffusion Barrier Layers for CVD Diamond Coatings Deposited on WC-Co: Microstructure and Properties [J]. Surf and Coat Tech, 1998, 98: 1060-1065.

Wang C X, Wang J H, Ma Z B, et al. Brim Effect of Negative Bias-Enhanced Nucleation of Diamond Film on Silicon Substrate [J]. Chinese Journal of High Pressure Physics, 2003, 17(2): 145-148. (in Chinese)

王传新, 汪建华, 马志斌, 等. 金刚石薄膜负偏压形核的边缘效应 [J]. 高压物理学报, 2003, 17(2): 145-148.

Zhang W J, Sun X S, Peng H Y, et al. Diamond Nucleation Enhancement by Direct Low-Energy Ion-Beam Deposition [J]. Phys Rev B, 2000, 61(8): 5579-5586.

Yang G W. Study on Positive Bias Controlled Nucleation of CVD Diamond Thin Films [J]. Vacuum, 1997, 3: 19-22. (in Chinese)

杨国伟. 正偏压控制CVD金刚石薄膜成核的理论研究 [J]. 真空, 1997, 3: 19-22.

Chen Q, Lin Z D. Negative Bias Enhanced Nucleation of Diamond on Si via Hot Filament Chemical Vapor Deposition [J]. Appl Phys Lett, 1996, 68: 2450-2452.

Wang W L, Liao K J, Fang L, et al. Analysis of Diamond Nucleation on Molybdenum by Biased Hot Filament Chemical Vapor Deposition [J]. Diamond and Related Materials, 2001, 10: 383-387.

Malcher V, Mrska A, Kromka A, et al. Diamond Film Coated on WC/Co Tools by Double Bias-Assisted Hot Filament CVD [J]. Current Applied Physics, 2002, 2: 201-204.
