基于组分Ca2Pr2Cu5O10三元固溶区的范围和晶体结构

宋功保; 韩苍穹; 梁敬魁; 饶光辉

doi:10.11858/gywlxb.2004.01.006

基于组分Ca2Pr2Cu5O10三元固溶区的范围和晶体结构

doi: 10.11858/gywlxb.2004.01.006

1.
西南科技大学材料科学与工程学院，四川绵阳 621002；
2.
中国科学院物理研究所，北京 100080；
3.
中国科学院国际材料物理研究中心，辽宁沈阳 110016

详细信息

通讯作者:
宋功保

计量
- 文章访问数: 8030
- HTML全文浏览量: 445
- PDF下载量: 786
出版历程
- 收稿日期: 2003-05-24
- 修回日期: 2003-09-22
- 刊出日期: 2004-03-05

The Extent and Crystal Structure of the Solid Solution Based on Ca2Pr2Cu5O10

1.
School of Material Science and Engineering, Southwest University of Science and Technology, Mianyang 621002, China;
2.
Institute of Physics and Center for Condensed Matter Physics, Chinese Academy of Sciences, Beijing 100080, China;
3.
International Center for Materials Physics, Chinese Academy of Sciences, Shenyang 110016, China

More Information

Corresponding author: SONG Gong-Bao

摘要

摘要: 利用X射线衍射分析和Rietveld结构精修方法研究了基于组分Ca2Pr2Cu5O10三元固溶区的范围和晶体结构。根据X射线分析结果和相消失法，为了保持Ca2+xPr2-xCu5O10结构单位晶胞中恒定的氧含量和电价平衡，基于组分Ca2Pr2Cu5O10的三元固溶区的范围可确定为：在Ca2+xPr2-xCu5O10固溶区的富Ca区（Ca/Pr1），其表达式仍可以表示为一般的化学计量式Ca2+xPr2-xCu5O10（x=0.4, 0.2, 0）；在富Pr区（Ca/Pr1），其表达式为Ca1.7Pr2.2Cu5O10、Ca1.4Pr2.4Cu5O10，即：Ca2+xPr2-xCu5O10固溶区范围从Ca2.4Pr1.6Cu5O10至Ca1.4Pr2.4Cu5O10。研究表明：基于组分Ca2Pr2Cu5O10的三元固溶体晶体结构可以看作是正交晶系NaCuO2型亚晶胞的无公度相；Ca2.4Pr1.6Cu5O10亚晶胞的点阵常数为a0=0.282 46(7) nm，b0=0.636 93(1) nm，c0=1.067 94(1) nm；其正交超结构的点阵常数为a=5a0，b=b0，c=5c0。Ca2.4Pr1.6Cu5O10的结构也可以用单斜超晶胞来表述，该单斜超晶胞的空间群为P21/c，Z=4，a=5a0，b=b0，c=c0/sin ，=104.79或136.60，V=5a0b0c0。在基于组分Ca2Pr2Cu5O10的三元固溶体晶体结构中，Ca和Pr之间在一定范围内是可以相互替代的，而且它们在结构中的占位是无序的。
- Ca2Pr2Cu5O10 /
- 三元固溶区 /
- X射线衍射 /
- Rietveld结构精修 /
- 晶体结构
Abstract: The extent and crystal structure of the solid solution based on Ca2Pr2Cu5O10 were studied by X-ray diffraction combined with Rietveld structure refinement. According to the principle of valence neutralization and the disappearing-phase method, in the Ca-rich region (i.e. Ca/Pr1) the composition of solid solution can be expressed as the general stoichiometry Ca2+xPr2-xCu5O10, and in the Pr-rich region (i.e. Ca/Pr1) as Ca1.7Pr2.2Cu5O10, Ca1.4Pr2.4Cu5O10, i. e., the solid solubility of the Ca2Pr2Cu5O10-based solid solution can be determined as from Ca2.4Pr1.6Cu5O10 to Ca1.4Pr2.4Cu5O10. The crystal structure of Ca2Pr2Cu5O10 based solid solution is an incommensurate phase based on the orthorhombic NaCuO2-type subcell. The lattice parameters of Ca2.4Pr1.6Cu5O10 subcell are a0=0.282 46(7) nm, b0=0.636 93(1) nm, c0=1.067 94(1) nm, and its orthorhombic superstructure is with a=5a0, b=b0, c=5c0. The Ca2.4Pr1.6Cu5O10 structure is also determined by using a monoclinic supercell with space group P21/c, Z=4, a=5a0, b=b0, c=c0/sin and =104.79or 136.60, V=5a0b0c0. In the structure of the solid solution based on Ca2Pr2Cu5O10, the mutual substitution between Pr and Ca is possible in some bound. Furthermore, they are distributed disorderly in the structure.
- Ca2Pr2Cu5O10 /
- ternary solid solution /
- X-ray diffraction /
- Rietveld refinement /
- crystal structure

HTML全文

参考文献(24)

Che G C, Liang J K, Chen W, et al. Phase Diagram of BaO-Y2O3(La2O3)-CuO Ternary System [J]. Sci Sinica, 1988, 31A: 1079-1092.

Dong C, Liang J K, Che G C, et al. Superconductivity and Crystal Structure in the La-Ba-Cu-O System [J]. Phys Rev B, 1988, 37: 5182-5185.

Che G C, Liang J K , Chen W, et al. Phase Diagram of the BaO-CuO-Y2O3 System and the Relationship between Composition and Superconductivity [J]. J Less-Commom Met, 1988, 138: 137-142.

Hinks D G, Soderholm L, Caponell D W, et al. Phase Diagram and Superconductivity in the Y-Ba-Cu-O System [J]. Appl Phys Lett, 1987, 50: 1688-1690.

DeLeeuw D M, Mutsaers C A H A, Langereis C, et al. Compounds and Phase Compatibilities in the System Y2O3-BaO-CuO at 950 ℃ [J]. Physica C, 1988, 152: 39-49.

Liang J K, Xu X T, Rao G H, et al. Subsolidus Phase Relationships and Superconductivity in the Gd2O3-BaO-CuO System [J]. J Phys D: Appl Phys, 1987, 20: 1324-1326.

Fu S J, Xie S S, Liang J K, et al. Subsolidus Phase Relations of Nd2O3-BaO-CuO System and Superconductivity of Nd1+xBa2-xCu3Oy(0x1)[J]. Mod Phys Lett B, 1988, 2: 1073-1078.

Zhang Y L, Liang J K, Cheng X R, et al. Study of the Phase Relations and Superconductivity in the Ho2O3-BaO-CuO Ternary System [J]. J Less-Commom Met, 1989, 146: 121-125.

Smith M G, Goodenough J B, Manthiram A, et al. Tin and Antimony Valence States in BaSn0. 85Sb0. 15O3 [J]. J Solid State Chem, 1992, 98: 181-186.

Liang J K, Chen X L, Wu S L, et al. The Crystal Structure and Property of Ternary Compounds and Phase Relations in the System Yb2O3-BaO-CuO at 950 ℃ [J]. Solid State Commoun, 1990, 74: 509-516.

Liang J K, Chen X L, Wang X T, et al. The Crystal Structure and Property of Ternary Compound and Phase Relations in the System Pr6O11-BaO-CuO Sintered at 920 ℃ [J]. Solid State Commoun, 1990, 76: 903-910.

Qiao Z Y, Xing X R, Yuan W X, et al. Phase Relations and Compounds in the Sm2O3-BaO-CuO System at 950 ℃ in Air [J]. J Alloys and Compounds, 1993, 202: 77-80.

Yao Y S, Xiong Y F, Jin D, et al. The High-Pressure Synthesis and Superconductivity of Pr0. 5Ca0. 5Ba2Cu3Oz [J]. Physica C, 1997, 282-287: 49-52.

Li K Q, Yao Y S, Cao D H, et al. High Pressure Synthesis of Ca-Doped Pr-123 Superconductors [J]. Physic C, 2000, 341-348: 583-584.

Liang J K, Chen X L, Che G C. Phase Diagram and Phase Structure [M]. Beijing: Science Press, 1993: 1-30. (in Chinese)

梁敬魁, 陈小龙, 车光灿. 相图与相结构 [M]. 北京: 科学出版社, 1993: 1-30.

Klug H P, Alexander L E. X-Ray Diffraction Procedures for Polycrystaline and Amorphous Materials(2nd ed) [M]. New York: John Wiley Sons Inc, 1974. 102-130.

Xu S S. X-Ray Crystallography [M]. Shanghai: Shanghai Press of Science and Technology, 1962: 47-52. (in Chinese)

许顺生. X射线晶体学 [M]. 上海: 上海科技出版社, 1962: 47-52.

Jeniyer A. X-Ray Crystallography [M]. Beijing: Science Press, 1959: 23-30. (in Chinese)

纪尼叶 A. X射线晶体学 [M]. 北京: 科学出版社, 1959: 23-30.

Davis P K. Studies of Rare Earth Curates with Structures Related to NdCuO2 [J]. J Solid State Chem, 1991, 95: 365-387.

Werner P-E. On the Determination of Unit-Cell Dimensions from Inaccurate Powder Diffraction Data [J]. J Appl Cryst, 1976, 9: 216-219; Werner P-E, Eriksson L, Westdahl M. A Semi-Exhaustive Trial-and-Trror Powder Indexing Program for All Symmetries [J]. TREOR, 1985, 18: 367-370.

Young R A, Sakthivel A, Moss T S, et al. DBWS-9411-An Upgrade of the DBWS** Programs for Rietveld Refinement with PC and Mainframe Computers [J]. J Appl Cryst, 1995, 28: 366-367.
